Garlic Clove Separating and Peeling Production Line - Food and Beverage

Consisted of two sets of elevators, garlic separator, picking line for separated garlic cloves, garlic peeling machine, picking line for finally peeled garlic cloves, and other required garlic deep management equipment. Link: http://vegetable-machine.com/project/garlic-breaking-peeling-machines-line.html Email: info@amisymachine.com

Independent Machines and Facilities of the Garlic Clove Separating and Peeling Production Line
? This garlic processing line consists of elevator (to deliver whole garlic to the garlic clove separator), garlic clove separator, picking line for separated garlic cloves, elevator (to send separated garlic cloves to the garlic peeling machine), garlic peeling machine, picking line for finally peeled garlic cloves, etc.
? The line also can be equipped with bubble cleaning machine, dewatering machine, garlic slicing machine, garlic paste making machine, garlic slice fryer machine, and garlic drying machine, packing machine, etc. other equipment as per different production requirements, for garlic deep processing.

Garlic Processing Line Technical Parameter
We have two kinds of optional outputs: 300kg/h, 600kg/h
♦ 300kg/h Production Line

Production Name
Voltage
Power
Dimension
elevator 1
380v/50Hz
0.75kw
2400x670x1250mm
separator
380v/50Hz
1.1kw
690x710x1050mm
picking line 1
380v/50Hz
0.75kw
4000x700x700mm
elevator 2
380v/50Hz
0.75kw
2400x670x1885mm
peeler
380v/50Hz
0.2kw
740x740x1685mm
picking line 2
380v/50Hz
0.75kw
3000x700x700mm

♦ 600kg/h Production Line

Production Name
Voltage
Power
Dimension
elevator 1
380v/50Hz
0.75kw
2400x670x2150mm
separator
380v/50Hz
1.1kw
1200x800x1630mm
picking line 1
380v/50Hz
0.75kw
4000x700x700mm
elevator 2
380v/50Hz
0.75kw
2400x670x2150mm
peeler
380v/50Hz
0.2kw
1010x900x1830mm
picking line 2
380v/50Hz
0.75kw
4000x700x700mm
