Fish feed drifting pellet making maker offer for sale
The major feature of the fish feed floating pellet making maker is to directly extrude puffed food. Normally, cereals, potatoes or beans are used as the main raw materials.
Related post: Fish Feed Extruder
After being extruded by thefloating fish feed making maker, under the problems of high temperature as well as high pressure, the item is puffed by utilizing the pressure distinction inside and also outside the maker
The direct extrusion type blew food generally does not contain lead, and currently the fish feed floating pellet making device is commonly used in the food industry. So just how much do you find out about the floating fish feed extruder? The fish feed floating pellet making device has a pair of screws as well as a screw sleeve, which have the features of mixing and also working.
After the raw material gets in the squeezing out tooth cavity, the material undergoes extrusion, rubbing and also shearing between the screw sleeves, and also the inner stress remains to increase, as much as 4Mpa, and the temperature level remains to increase, as much as 140 ℃.
Related post: https://www.richipelletmachine.com/fish-feed-extruder-machine/
Within 3-7s, the temperature level as well as stress of fish feed floating pellet making machine surge sharply, and also the tissue framework of the product modifications, which even more gelatinizes the starch, denatures the healthy protein, ruins the unrefined fiber, as well as eliminates unsafe germs such as Salmonella.
The high-temperature and also high-pressure product appears of the discharge port, as well as its stress is all of a sudden released in an split second, and the wetness is partially blinked.
Related post: 1.5-2T/H Fish Feed Processing Line
1. The structure of drifting pellet making device.
The feeder is to make certain consistent and stable feeding, and also readjust the feeding quantity according to the ranked present value of the electric motor of fish feed floating pellet making maker. Normally, an electro-magnetic speed-regulating motor or a regularity converter is made use of to adjust the speed, and also the feeding quantity of the feeder is altered.
Development cavity of fish feed drifting pellet making equipment is made up of screw, screw sleeve, design template, card bone and so on. The screw as well as screw sleeve are incorporated in sections, the compression degree can be adjusted according to the type and requirements of the extruded feed, as well as the extruded level of the extruded feed can be transformed;
Related post: 3-4T/H Floating Fish Feed Production Line
The fish feed floating pellet making equipment is split right into three areas in regards to collapse degree according to function and also place:
① Feeding section: This section of drifting fish feed equipment has a huge screw pitch, and generally shares as well as compresses the material to make sure that the material fills the spiral groove;
② Compression section: The screw groove of this area changes from deep to superficial along the material relocating instructions to press the material;
③ Extrusion area: the screw groove is shallower, the pitch gradually lessens, the extrusion force can get to 3.0-10Mpa, as well as the temperature can reach 120-150 levels Celsius. This section has the highest possible pressure as well as greatest temperature, so the wear of the screw as well as screw sleeve is also the most significant.
The outlet of the extrusion section is a design template, the form of the theme is designed with various die holes according to the requirements of different feeds, the material is extruded from the die hole of the layout as well as gets in the atmosphere, the stress and also temperature level drop sharply, and also its volume increases rapidly, the water swiftly evaporates, dries out and solidifies to come to be an extruded product.
Related post: 4-5T/H Floating Fish Feed Plant
2. Repair of fish feed drifting pellet making device
Transform the fish feed floating pellet making device on-site control switch to the quit state during upkeep;
The within and also beyond the fish feed floating pellet making maker ought to be cleansed after each shift, specifically the product should not be preserved in the puffing chamber, so regarding prevent it being challenging to clean up after cooling as well as cluster;
The huge wheel of the primary shaft of the puffing chamber ought to be cleansed regularly, and not way too much dust, or else the sheave will certainly be unbalanced as well as the puffing chamber will shake;
The primary bearing of the growth chamber is lubricated with lubricating oil, as well as the bearing of the fish feed drifting pellet making maker conditioner and also its transmission device and various other bearing parts are lubricated with grease;
The main bearing needs to be replaced with new oil consistently. After 250 hrs of job, all brand-new oil should be replaced;
Related post: Floating Fish Feed Extruder
Various other bearing components, every two days of job, grease is injected as soon as;
The chain transmission system on the vapor conditioner must be oiled regularly;
The oil in the reducer of fish feed drifting pellet making equipment needs to be controlled at the adjusted oil degree, and the brand-new oil needs to be replaced after 250 hrs of procedure;
When eliminating the screw head, do not knock it hard;
Always keep the fish feed floating pellet making device and its environments clean.
For details please contact: Richi Machinery
WhatsApp:86 138 3838 9622
Email:enquiry@richipelletmachine.com
