2IE Irrigation Systems products

Linear machine ONE SPAN composed of a cart 2 wheels, one span and and overhang and an endgun at each end of the machine. It irrigates in linear.  The guidance using a furrow or by an overhead cable parallel with the way of the cart. The water supply of the linear machine is made either from a cannal or by a soft hose connected to the hydrants, spaced from each other according to the hose diameter, length and flow rate..

25m, 31m ou 37m  fixed on the last span and can be equipped with a endgun at the end. It swivels of 90° when an obstacle is on the zone to irrigate. The swing boom overhang (PAFE) is controled by the AGS panel.

The fixed pivot can be electric, diesel or solar. The center pivot is anchored to a concrete slab and the spans swivel around this one. The pivot can be in full circle or sector. The center pivot is the central point by which water is conveyed in the span (s). It is provided with a collector when in full circle, when the pivot is in sector it doesn’t need collector,  but a safety stop and a safety barricade at both end. Solar powered, the pivot can be 100% autonomous.

The towable pivot can be on skis or wheels, pulled by a tractor. The pivot is towable in the length direction. The wheels of each span are rotated 90 ° using a jack or with the aid of an electric control (optional). The displacement of the pivot is carried out with a tractor connected by a holding cable between the center and the first tower. Possibility to move the pivot point to point automatically (option).

The linear machine can irrigate linear or linear / circular with an automatic double sprinkler package. The alignment of the spans is managed by the cams, assisted double action cable system and by a coder located on the cart for the management of the angles with a precision of 0.1°. The water supply of the linear machine is made either from a canal or by a soft hose connected to the hydrants, spaced from each other according to the hose diameter, length and flow rate. For flow rates less than 150m3 / h our machines are equipped with soft hose automatic and motorized device. The guidance is carried out using a furrow or by an overhead cable parallel
to the way of the cart. The alignment by double action cable system, optimizes the perpendicularity of the spans with the cart.

Linear machine RAIN LINER VV2 WINGS composed of a 2 wheels cart and several spans on both side. It irrigates in linear. The guidance using a furrow or by an overhead cable parallel to the way of the cart. The alignment by double action cable system, optimizes the perpendicularity of the spans with the cart. The water supply of the linear machine is made either from a canal or by a soft hose connected to the hydrants, spaced from each other according to the hose diameter, length and flow rate.

Linear machine VV 2 wheels composed of one or several spans, can be electric or diesel. It irrigates in linear. The guidance using a furrow or by an overhead cable parallel with the way of the cart. The alignment by double action cable system, optimizes the perpendicularity of the spans with the cart. The water supply of the linear machine is made either from a canal or by a soft hose connected to the hydrants, spaced from each other according to the hose diameter, length and flow rate.bit.
