Big John Trailers products

Bolsters: 4" x 10" rectangular tubing. Landing Gear: Standard Winch-Back. Length: 40 ft. / 42 ft.. Paint: Customer`s choice. Standards: 5" x 5" square tubing. Axles: 25,000 lbs ea., 5" round. Tires: 11R 24.5 Radials. Rims: Unimount Steel. Suspension: Hutchens Model 9700 with four H.D. 3-leaf springs. Lights: D.O.T. Spec Sealed with Harness.

Bolsters: 6"x 8" Rectangular Tubing. Landing Gear: Standard Winch-Back. Length: 40 ft. / 42 ft.. Paint: Customer`s choice. Standards: 6"x 6" Square Tubing. Axles: 25,000 lbs Capacity. Tires: 11R- 24.5 Radials. Rims: Unimount Steel. Suspension: Hutch 9700 with four H.D. 3-leaf springs. Lights: D.O.T. Specs Sealed with Harness.

Bolsters: 4x10 Rectangular Tubing. Bumber: Push Style. Landing Gear: Single Drop Leg. Length: 23 ft.. Standards: 5x5 Square Tubing. Axles: 25,000 lbs each. Tires: 11R- 22.5 / 11R-24.5. Rims: Unimount Steel. Suspension: Hutch 9700 . Lights: DOT Specs.

Frame: WF I-beam or Fabricated Frame. Bolsters: 4" x 10" rectangular tubing. Landing Gear: Standard Winch-Back. Length: 40 ft. - 45 ft.. Paint: Customer`s choice. Standards: 5" x 5" square tubing. Axles: 25,000 lbs ea., 5" round. Tires: 11R 24.5 Radials. Rims: Unimount Steel. Suspension: Hutchens Model 9700 with four H.D. 3-leaf springs. Lights: D.O.T. Spec Sealed with Harness.

Bolsters: 6 x 8 tubing. Bumper: Push Style. Landing Gear: Winch Back Type. Length: 40 ft.- 42 ft.. Main Rails: Mill Rolled WF beam. Paint: Customer`s Choice. Standards: 6" square tubing.

Length: 46 ft. - 51 ft. Landing Gear: Hydraulic Elevator Style. Bumper: Reinforced. Paint: Black. Axles: 25,000 lb. rated. Tires: 11-22.5 bias. Rims: Unimount. Lights: D.O.T. Specs.

Length: 45 ft. - 51 ft. Bumper: Reinforced. Paint: Black. Axles: 25,000 lb. rated. Tires: 11-22.5 bias. Rims: Unimount. Lights: D.O.T. Specs.

Length: 38-47 ft. Main Rails: 16" WF beam. Paint: Black. Axles: 25,000 lb. rated. Tires: 11-22.5 bias. Lights: D.O.T. specs. Brakes: Air. Frame: 34 1/4" wide x 41" high.

For 20,000 and 30,000 lbs. class loader. Rear Axles: 38-44,000 lbs.(reconditioned). Front Axles: 12,000 lbs. (on oscillating cradle). Hydraulic Power Drive: Charlynn 10,000 series. Steering: Hydraulic. Transmission: Fuller 10-speed  (reconditioned). Brakes: Air for highway service. Options available upon request.
