10 products found
F.H. Schule Mühlenbau GmbH Products
-
Processing of Cereals and Legumes - Oats Processing Plant
-
F-H-Schule - Cleaning Screen with Aspiration Channel
While the coarse impurities remain on the surface of the upper screen, the product flow passes through the screen. The small impurities pass through the lower screen and are discharged separately, just like the coarse ...
-
FH Schule - Dry Stoner
The product which is full of stones falls through a feeding flap and is distributed uniformly on the working surface of the machine, which is provided with an optimum air flow by its own fan. The oscillating movement in combination with the air flow ensures a separation of the light and heavy particles. The cleaned product and the stones are discharged via two separate outlets. The dry stoner is available in two types and several sizes. It is equipped ...
-
Processing of Cereals and Legumes - Rice Processing Plant
-
FH Schule - Rubber Roll Sheller
Today, the rubber roll sheller is indispensable if paddy is to be shelled carefully at high capacities. Once there is paddy on the vibrating channel, the channel is activated by a photocell and conveys the product via a chute to the rubber rolls. The diagonally mounted rubber rolls are brought pneumatically into working position. While the paddy is transported through the gap between the rubber rolls, the rolls are cooled by a fan. This ensures a long ...
-
F-H-Schule - Model FHS03-HUS1260-9e - High Capacity Closed Circuit Husk Separator
Via a screw in the inlet, the product is uniformly distributed over the entire width of the machine and transported into the separation chamber. As an internal cross-flow fan generates a circulating air flow, the machine does not require a filter and fan connected ...
-
Oilseed Processing Plants - Processing Plants for Sunflower Seeds
-
F-H-Schule - Model FHS07 - Impact Huller
Via an immersion pipe, which regulates the throughput, the product is fed to the rotating centrifugal wheel. Inside the centrifugal wheel, the product is aligned and thrown by means of centrifugal forces caused by rotation against an impact ...
-
F-H-Schule - Model FHS12-TH3-9e - Table Separator
The SCHULE table separator, invented in 1892 by Friedrich Hermann SCHULE, is unsurpassed until today worldwide in quality and sorting capacity. The table separator is always particularly successful when conventional separating methods ...
-
Oilseed Processing Plants - Soybean Shelling Plant
-
FH Schule - Conical Cup Shelling Machines
A high shelling degree in conjunction with a high throughput - both points are united in the conical shelling machine. Via a feed screw, the product is fed into the working chamber of the machine where a conical stone set on a hollow shaft is surrounded by a conical screen basket. The outlet of the working chamber is completed by a plate the counter-pressure of which can be variably adjusted by springs. One special aspect worth mentioning is the gap ...
-
F-H-Schule - Plansifter
When it comes to precise sizing on a small area, a plansifter is used. The product to be sorted is fed to the plansifter through the inlet funnel and the flexible inlet fabric tube. The product is often screened by several screens within the plansifter, until the desired separation is reached. Several fractions with different grain sizes are produced. These are collected separately from each other and discharged via corresponding channels in the ...
-
Hydrothermal Processes - Hydrothermal Cooking Plants
-
FH Schule - Model FHS46 - Horizontal Belt Cooker
Within various hydrothermal processes, the horizontal belt cooker provides the opportunity of processing products, which make complex demands on the cooker, in an optimum way. Encapsulated by a feeding and discharge device, the product can be treated with steam under overpressure in the belt ...
-
Tea and Spices - Tea and Spice Plants
-
FH Schule - Aspiration Channel
The aspiration channel is used to separate products with different specific gravities. Primarily the aspiration channel is used for cleaning products or downstream of a shelling machine for separating the kernel and ...
