Forigo Roteritalia products

Universal 3 point linkage Cat. 2 Single speed gearbox 540 rpm PTO Compact low encumber machine Front section composed by power harrow with 200 mm centre-to-centre rotors Special Tine system bi-directional "ZEUS" ideal for a low power absorption Tine length 280 mm Rear section composed by crumbling rotor Ø360 mm with high resistance and wearing steel spikes Rear rotor mounted on parallelogram adjustable in height Independent hydraulic plant for rear roller management from 0 to 350 rpm Pair of front discs adjustable in width and height Ø 360 mm Rear adjustable hood Working depth adjustable by crank handles Cardan shaft with shear bolt torque limiter SB type (1”3/8 Z=6 tractor side yoke)

Universal 3 point linkage Cat. 2. Single speed gearbox 540 rpm PTO. Front tilling rotor Ø370 mm. Tilling rotor transmission chain in oil bath. Removable flanged rotors. Automatic chain tensioner on spring. Rear crumbling rotor Ø360 mm with high resistance and wearing steel spikes. Rear rotor transmission chain in oil bath. Front dual metal face seals in oil bath on rotors 4x blades per flange, length 245 mm. Pair of front adjustable lateral discs adjustable in width and height Ø 460 mm. Rear adjustable hood. Working depth adjustable by crank handles. Pair of wearing round rod on side pannels. Cardan shaft with shear bolt torque limiter SB type (1”3/8 Z=6 tractor side yoke).

Basic machine: Universal 3 point linkage Cat. 1 & 1s. Single speed gearbox 540 rpm PTO. Rear PTO connection (From mod. 130 to 210). Rotor 290 rpm. Monobloc tine-holder shaft hot-forged. 2x Tines per rotor. Special Tine system bi-directional "ZEUS" ideal for a low power absorption. Cylindrical anti-flood tine-holder shaft. Adjustable side plates. Working depth adjustable by crank handles. Safety front bar. Cardan shaft with shear bolt torque limiter SB type (1”3/8 Z=6 tractor side yoke).

Basic machine: Universal 3 point linkage Cat. 1 (up to 150 model). Universal 3 point linkage Cat. 2 (from mod. 180 to 250). Tractor linkage swinging arms from mod. 180 to 250. Single speed gearbox 540 rpm PTO. Rear PTO connection. Rotor 290 rpm. Monobloc tine-holder shaft hot-forged. 2x Tines per rotor. Special Tine system bi-directional "ZEUS" ideal for a low power absorption. Cylindrical anti-flood tine-holder shaft. Adjustable side plates on springs. Working depth adjustable by lateral pins regulators on rollers. Safety front bar. Cardan shaft with shear bolt torque limiter SB type (1”3/8 Z=6 tractor side yoke).

Basic machine: Universal 3 point linkage Cat. 1 & 1s. Single speed gearbox 540 rpm PTO. Lateral transmission driven by chain in oil bath. Automatic chain tensioner on spring. 4x Spade blades per flange. Wearing steel protection counter-flanges. Rear selector rake mounted on lateral springs. Rear adjustable hood. Working depth adjustable by crank handle. Cardan shaft with shear bolt torque limiter SB type (1”3/8 Z=6 tractor side yoke).

Basic machine: Universal 3 point linkage Cat. 1 & 1s. Single speed gearbox 540 rpm PTO. Lateral transmission driven by chain in oil bath. Automatic chain tensioner on spring. Removable flanged rotor. 4x Spade blades per flange. Wearing steel protection counter-flanges. Working depth adjustable by crank handle. Rear selector rake mounted on lateral springs. Cardan shaft with shear bolt torque limiter SB type (1”3/8 Z=6 tractor side yoke).

Basic machine: Bed former not using PTO. Compact low encumber structure. Universal 3 point linkage Cat. 2. Adjustable bed former hood for SINGLE bed. Pair of front lateral discs adjustable in width and height Ø 460 mm. HP 50-100, kW 37-74.

Basic machine: Universal 3 point linkage Cat. 2. Machine with reversible option predisposition. Gearbox 540-1000 rpm PTO with overrun clutch. Automatic belt tensioner on spring. Transmission driven by toothed belts. Rotor fitting Potatoes Blades. Stand feet. Easy access greasing points. Opening hoods for inspection. Pair of rear wheels adjustable by crank handles. Front and rear shaped protections. HP 80-140, kW 60-105.

Category 2 universal 3-point hitch. Folding frame with hydraulic device for. opening and closing. Multiplier for PTO 1000 rpm. 2 large diameter rotors complete with knives with. oscillating vane with shaped profile. Ball bearing rotor bearings. Deflectors inside the frame. Double lateral belt drive with. automatic belt tensioners. 2 pairs of rear wheels with. crank-operated depth adjustment. Opening hoods for inspection. Molded rubber front guards and chains. Rear guards. Rear light bar.
