Gamberini srl products

Gardening Fertilizer Spreaders

Gamberini - Gardening Fertilizer Spreaders

Tubular steel frame light and sturdy construction. Painted cone shaped hopper single. piece without welding. Painted spreading disc with 4 AISI304. stainless steel adjustable vanes. AISI 304 stainless steel flow control, manually operated. Cast iron gearbox with gears lubricated in grease-oil bath. Standard agitator. Height adjustable draw bar with eye Øi 25 mm. Wheels size 13x5.00-6. Fertilizer spreader suitable for use in narrow areas as garden or where bigger machines cannot enter.

Gamberini - Gardening Fertilizer Spreaders

Tubular steel frame light and sturdy construction with standing support. Hopper double cone shaped: F 80 painted steel , F 80 inox stainless steel AISI 304. Painted spreading disc with 4 stainless steel adjustable vanes. AISI 304 stainless steel flow control, manually operated. Cast iron gearbox with gears lubricated in grease-oil bath. Standard agitator. Wheels size 4.10x3.50x4 with metal rim. Professional fertilizer/seed spreader suitable in narrow areas as garden or where bigger machines cannot enter.

Trailers for Spreaders

Gamberin - Trailers for Spreaders

N° 4 tires size 205 / 65 R15. Adjustable trailer track 1,45 ÷1,8 m. Machine mass ( empty ) 398 kg. Max. payload 1200 kg. Width 1,85÷2,2 m. Lenght 2,65 m. Height adjustable eye Øi 40 mm and pivoting for tractor hooking. Spreader fixing system to trailer with 3 point attak, all adjustable. Adjustable, rotating and dismountable bar support. Ladder and platfom for spreader inspection. Cardan shaft L = 800 mm , Ia Cat. Max. speed 15 km/h.

Mounted Spreader Single Disc

Gamberini - Mounted Spreader Single Disc

Tubular steel frame light construction cold galvanized. Double cone shaped hopper construction, hot galvanized. Aluminium gear box with gears in oil bath lubricated . Spreading disc with 4 adjustable vanes. Standard agitator. Filtering grill. Cardan shaft supplied on demand. Manual lever to operate flow control opening. Manual lever for RH / LH spreading selection. Hopper capacity 280 kg.

Mounted Spreader Double Spinner Disc

Gamberini - Mounted Spreader Double Spinner Disc

Steel frame 4 mm thick, sturdy contruction. Painted, rectangular fixed steel hopper. N°3 Aluminium gearbox with gears lubricated in oil bath. N°2 AISI 304 stainless steel spreading discs with 4 adjustable vanes. N°2 AISI 304 stainless steel flow controls with 2 adjustable openings. N°2 indipendent extensible levers to operate each single flow control opening. Standard spring agitators. Filtering grill. 3 points linkage, 1st, 2nd Cat. Cardan shaft L = 700 mm.
