Geoflow products

Miniature economical CAS dripper to maintain uniform flow rate at wide range of working pressures and various topography.Anti-siphon mechanism to prevent aspiration through dripper outlet. Prevents sa nd and soil penetration into dripper. Ideal for use in SDI  (Subsurface Drip Irrigation). Contains the most reliable and proven PC mechanism by regulating labyrinth of ADI and VERED drippers. Dripper flow rates:  0.9, 1.2 , 1.6, 2.1, 3.4 l/h. ASSIF dripline available in wide range of wall thicknesses between 0.4 to 1.2 mm. ASSIF dripline available in wide range of lateral diameters: 16, 17, 20, 22 and 25 mm. Rootguard® configuration available for extra root protection in SDI. Filtration system should be at least 120 mesh.

Miniature economical CND dripper to maintain uniform flow rate at wide range of working pressures and various topography. Dripper shuts down at low pressure (< 0.14 bar) to keep lateral full of water between irrigation intervals for precise and uniform irrigation along the dripline, simultaneously with next irrigation cycle. Anti-siphon mechanism prevents aspiration of soil particles through dripper outlet, ideal for use in SDI (Subsurface Drip Irrigation). Contains the most reliable and proven PC mechanism by regulating labyrinth of ADI and VERED drippers. Dripper flow rates: 0.9, 1.2 , 1.6, 2.1, 3.4 l/h. INBAR dripline available in wide range of wall thickness between 0.4 to 1.2 mm. INBAR dripline available in wide range of lateral diameters: 16, 17, 20, 22 and 25 mm. Rootguard configuration available for extra root protection in SDI. Filtration system should be at least 120 mesh.

A light flat integral dripper manufactured under Metzerplas novel insertion technology. Large inlet filter and turbulent flow pattern designed for clog resistance. Available in wide range of wall thickness between 0.2 mm – 1.2 mm. Drippers flow rates: 0.8, 1.2, 1.6, 2.0 and 4.0 l/hr. LIN dripline available in wide range of wall thickness between 0.2 - 1.2 mm. LIN dripline available in wide range of lateral diameters: 12, 16, 17, 20 and 22 mm. Rootguard® configuration available for extra root protection in SDI. Filtration system should be at least 120 mesh.

Miniature economical PC dripper to maintain uniform flow rate at wide range of working pressures and variable topography.Expanded inlet filter and wide water passages for clog resistance. Contains the most reliable and proven PC mechanism by regulating labyrinth of ADI and VERED drippers. Suitable for effluent and recycled water. Dripper flow rates: 0.9, 1.2, 1.6, 2.1, 3.4 l/h. VARDIT dripline available in wide range of wall thickness between 0.3 to 1.2 mm. VARDIT dripline available in wide range of lateral diameters: 16, 17, 20, 22 and 25 mm. Filtration system should be at least 120 mesh.

Flat PC dripper, unique with regulating labyrinth. Contains unique PC mechanism of ADI dripper by regulating labyrinth with self-flushing operation at the beginning and the end of each irrigation cycle. Flat PC dripper with the largest inlet filter for clog resistance. Drippers flow rates: 1.2, 1.6, 2.1 and 3.5 l/h. VERED dripline available in wide range of wall thickness between 0.4 to 1.25 mm. VERED dripline lateral diameter: 16, 17, 20, and 22 mm. Rootguard® configuration available for extra root protection in SDI. Filtration system should be at least 120 mesh.

Highly reliable dripper. Unique and accurate regulating labyrinth mechanism. Wide water passages along the labyrinth. Self-flushing operation at the beginning and at the end of each irrigation cycle. Compact multi-optional button dripper. Accommodates 1, 2, and 4 outlet adapters. Filtration system should be at least 120 mesh.
