Gooseneck Trailer Mfg, Co., Inc. products

Custom Built Truck Beds to Fit Your Truck are Available at Special Pricing

16′, 20′, 24′, 28′, 32′, 36′, and 40′ Lengths. 5′, 6′, 6’6″, 6’8″, 7′, and 7’6″ Widths. 6’6″ Bow Height Bartop. 3-Plank Spaced Sides. 3/16′ or 7-Gauge Steel Body and Brush Fender. Schedule 40 1¼” Bow Pipes on 4′ Centers. 4″ Channel Cross Members on 4′ Centers. 2″ x 2″ x 3/16″ Angle Iron Floor Runners Full-Length of Trailer. Double T-Braces. 3/16″ Formed Neck Gusset. 8″ Channel Iron Neck Up to 28′ and 10″ Channel Iron Neck on 32′ and Up.

16′, 20′, 24′, 28′, and 32′ Lengths. 6’8″ Width Up to 32′. 7’6″ Width Up to 28′. 6’6″ Bow Height. Bartop on 6’8″. Aluminum Top on 7’6”. Open Vertical ¾” Pipe Front From Neck Down. 3-Plank Spaced Sides. 3/16″ Aluminum Brush Fender Material (16′, 20′, and 24′ Lengths). 1/4” Aluminum Brush Fender Material (28′ and 32′ Lengths). Schedule 40 1¼” Bow Pipes on 2′ Centers. Double Bows at Crossgates and Tailgates.

16′-Long, 6′-Wide, 6’2″ Tall. Wood Floor. 2–6K Axles. Electric Brakes on Both Axles. 8-Hole 16″ Wheels. 235 85 R16 Radial Tires. Full Aluminum Font. 2′ Front Section. 1 Crossgate. Split Tailgate. 2 5/16″ V-Coupler. Bartop. Spare Tire, Rack, and Wheel. 3-Plank Sides. Brush Fenders. Rubber Dock Bumper. 5-Year Limited Warranty.

16′, 20′, 24′, and 28′ Lengths. 5′, 6′, 6’6″, and 6’8″ Widths. 6’6″ Bow Height. Bartop. 3-Plank Spaced Sides. 3/16″ or 7-Gauge Steel Body and Brush Fender Material. Schedule 40 1¼” Bow Pipes on 4′ Centers. 4″ Channel Crossmembers on 4′ Centers. 2” x 2” x 3/16″ Angle Iron Floor Runners Full Length of Trailer. Double T-Braces. 8″ Channel Iron Neck. Adjustable 2–5/16″ (25K) Ball Coupler (Hitch).

For private or commercial hauling, the BIG HAUL is one of the handiest trailers you can own. It loads from the ground with no chute needed. The BIG HAUL also has maximum maneuverability.

This is a little package that delivers big results. Don`t settle for less than the original Gooseneck brand. We have built your trailers for more than 40 years.

Tough jobs demand a tough trailer, and that`s what you get with our rugged commercially designed dump trailer. A strong frame, matched hydraulics, and the more reliable scissor lift give you all you need for the toughest jobs. A wide range of payload capabilities is available. Don`t settle for less than the original Gooseneck brand. We have built your trailers for more than 40 years.
