11 products found

Products

  • Combine Reels

  • Combine Reels

    Combine Reels

    HCC Combine Reels improve performance and reduce downtime. We’ve improved on the reel with fewer parts, stronger components, 35-40% greater visibility, and lighter weight.

  • Combine Reel Enhancements

  • Orbit - Model Trac II - Combine Reel-Auger Gap

    Orbit - Model Trac II - Combine Reel-Auger Gap

    Anyone who has harvested with a grain or flex header has seen crop hesitate in front of the auger, resulting in slugging, reel carry-over, and slower harvest speeds. HCC has closed that gap with the Orbit™ Trac II Combine Reel. This attachment for HCC combine reels has a revolutionary reel design that brings the tines right up to the auger to positively place crop into the auger, providing true continuous crop flow.

  • Flip Combine Reel Kit

    Flip Combine Reel Kit

    The Flip Combine Reel Kit enhances reel performance with its tine flipping action that feeds heavy-duty crops, like canola, into the header. Keep your crops moving with the HCC Flip Combine Reel Kit. HCC’s Flip Combine Reel Kit is designed to prevent crops from wrapping around bat tubes and offers the durability needed to harvest tough crops including canola.

  • Paddle Tines

    Paddle Tines

    The Paddle has earned rave reviews from across the country. It’s the cost effective alternative to standard pickup combine tines when crop conditions make harvesting difficult and inefficient.

  • 52” Combine Reel Conversion Kit

    52” Combine Reel Conversion Kit

    An HCC 52' combine reel conversion kit improves your combine's performance. Ten inches larger than the industry standard, the 52' combine reel sits about five inches farther forward on the header and therefore reaches farther into your crop. Combine reel speeds are slower for the same bat speed, and there is less need for fore and aft height adjustments. The combine reel conversion kit can be installed on the farm in about two to...

  • Gateway - Combine Sieves and Combine Chaffers

  • Gateway - Combine Sieves and Combine Chaffers

    Gateway - Combine Sieves and Combine Chaffers

    The patented design of the Gateway® combine sieve and combine chaffer system utilizes aluminum and plastic modular construction to provide optimized combine performance and improved grain cleaning. The construction of the Gateway makes it significantly lighter than standard combine sieves and combine chaffers, reducing the wear on cleaning shoe bushings and bearings, extending their life, and reducing combine downtime.

  • Reel Tines

  • Polytine Reels

    Polytine Reels

    Polytine Reels have a teardrop shaped metal bat with notches spaced 4-1/2' (114 mm) apart. The tines fit into notches and are fastened to the back of the metal bat approximately 3' (76 mm) above the notch.

  • Sheet Metal Bat Reel

    Sheet Metal Bat Reel

    The Love Reel has a sheet metal bat, and the tine fastens over the bottom edge. There is a projection that fits into a hole on the front of the bat approximately 2-1/2' (64 mm) above the edge.

  • Model ML - Reels

    Model ML - Reels

    ML Reels have a 1-3/8' (35 mm) tube with 3/8' (10 mm) round holes spaced approximately 4-1/2' (114 mm) apart. The tines have a round nub that fits into a round hole in the tube.

  • Model II  - Level Reel

    Model II - Level Reel

    Level II Reels have a 1-3/8' (35 mm) tube with 1/2' (12.7 mm) hex holes spaced 6' (152 mm) apart. The tines have a hex nub that fits into a hex hole in the tube.

  • Wood Bat Reels

    Wood Bat Reels

    Wood Bat Reels have a wood bat with steel tines spaced approximately 4-1/2' (114 mm) apart. The tines are pressed into the bat, and there is a metal clip riveted to the bat to provide support to the tine
