Log Max AB products

Log Max 928A is a small and light head specifically designed for thinning. The compact format makes it the obvious choice for small-sized wheel and track-based harvesters in the 7 to 15 ton range.

Log Max 3000T is a new generation thinning head best suited for long reach booms. This head features a new frame geometry, bringing forward the top part of the frame to bark from clogging the measuring wheel.

The Log Max 4000T, our latest thinning head has impressive pulling force and high speed feeding. This head has an entirely new frame construction where the saw box has been moved backwards and outwards, the higher part of the frame inched forward reducing friction and clogging in the measuring wheel. The new hydraulics layout greatly improves power and feeding speed making this 833 kg* harvesting head the ultimate choice for thinning and lighter final cuts. This powerful thinning head comes equipped with the first-generation Log Max 218 and 318 True-Cut saw units with up to 58 cm of cut capacity. All these features combined with Log Max patented knife control system, which minimizes feed friction, provides outstanding stem coverage and increased log quality.

Log Max heads are designed for installation on various types of Carriers.For this reason, low weight is essential in our state-of-the-art design, given the fact that the CTL-method mostly uses wheeled pulling force to weight ratio. Log Max 5000D is a versatile head for harvesting, ranging from thinning to medium final cut. Well placed guards and heavy-duty covers protect internal components and hoses from damage. High performance saw hydraulics provide full flow to the bottom saw for fast cutting. Log Max 5000D is an updated version of our previous big seller. The Log Max 5000D can be equipped with an Accumulation Kit for multi-stemming and a Hultdins Supercut saw.

Log Max 6000B is a light-weight head suitable for final felling. This head combines low weight with high power and is especially designed for large wheeled carriers. The Log Max 6000B is built on well proven hydraulics with a maximum hydraulic pressure of 260 bar (3,771 psi) and max flow of 280 l/min (74 gpm). The feed rollers always work perpendicular to the tree which has for benefit to minimize friction losses and roller penetration. This geometry also ensures accurate length and measuring for high quality timber. Well placed guards and heavy-duty covers protect internal components and hoses from damage. High performance saw hydraulics provide full flow to the bottom saw for fast cutting. Log Max 6000B can be equipped with a Hultdins Supercut saw..

6000V is a versatile head which has a wide range of applications, mainly focused on final felling. The unit is a further development of our great seller 6000B with improvements and updates to work even better in today’s modern forestry. The length measurement function of the 6000V has been optimized to create the very best conditions for delivering optimal measurement results. we have made changes in several areas in order for measuring wheel to better follow the contour of the trunk. Modifications and reinforcements to the new frame improve the the reliability and lifetime of the head. The unit is also equipped with our new, smart saw True-Cut that provides fast and controlled cutting.

Log Max 6000Twin is a light-weight head suitable for “low branches” featuring a twin bottom knife for optimal delimbing from the lowest part of the trunk to the top. This head combines low weight with high power and is especially designed for large wheeled carriers.

The Log Max 7000C harvesting head is built on a tough frame and combines high drive power and high speed. This head performs very well in heavy and branchy trunks. Log Max 7000C is a large head for the really heavy timber. The head combines high power and high speed, and performs very well in heavy and branchy trunks. Variable displacement feed roller motors provide fast speed in smaller wood and automatically regulate to provide more power in tougher limbed trees. Well placed guards and heavy-duty covers protect internal components and hoses from damage. High performance saw hydraulics provide full flow to the bottom saw for fast cutting in all timber sizes.

The all new Log Max 7000Twin, following the success of the 6000Twin, is a new heavy-duty head specifically engineered for low branched trees. High power is one of the heads main feature, able the deliver up to 41.7kN and weighing in at only 1889 kg. Log Max 7000Twin, featuring twin bottom delimbing knives, is made for the really heavy branched timber. The new cast felling link makes it the ideal choice for large tracked carriers. The 7000Twin is the first Log Max head to feature a new wiring optimized for Log Mate 500. This improved wiring eliminates the need for the lower junction box. Variable displacement feed roller motors provide fast speed in smaller wood and automatically regulate to provide more power in heavy limbed trees. Well placed guards and heavy-duty covers protect internal components and hoses from damage.

With its large, high-torque feed motors, the 7000XT gives you up to 45kN / 11,600-lb. of feed force and delimbing power. High-flow hydraulics provide increased performance in any application and the toughest conditions. The new XTreme series from Log Max are heavy-duty harvesting heads specifically designed for tracked carriers. With a choice of harvester or dedicated processor configuration, the Log Max XTreme Series meets the demands of the toughest operations. The XT Series has been developed to provide the logging industry with a productive and durable head for the most extreme applications and to produce wood at the lowest cost per tonne possible.
