Valley Fabrication Inc. products

Rear Axle to King pin on tractor, approximately 35 feet 8 inches; Width within 120 inches; Telescoping SS wings to cover 19, 40 inch beds; 4 packing stations; 2 cauliflower spary nozzles where the wing meets the main conveyor; 32 inch crop clearance; 1 inch thick bar grading flooring; Main Belt 34 inches from the floor; Auxiliary hydraulic tank with oil cooler; All belts and conveyors on machine will be powered by a pressure compensated pump off the tractor PTO.

14 bed or 16 bed stainless steel wings. 16″ wing conveyor with RMV belting, hydraulically driven. Fold out shade structures for workers on wings. Set up trays clip onto wing.

Machine Features: Stainless Steel Chassis construction with aluminum wings. Tricycle 3-wheel design: 1 front steering wheel and 2 rear diving wheels. Two speed gearbox. Parking break on front wheel. A 1500 lb. pallet forklift assembly for on board palatalization. Hydraulic power unit to power the forklift. Four solar panels and charge controller. Four 6VDC deep cycle batteries. Bi-folding aluminum wings. Rear wheel supports can be moved to 48″, 52″, 64″ and 68″ beds.

Designed for 12 Double electric stripper heads, supplied by customer. Space behind last stripper station to inspect the product with a clip on ladder/platform. Machine under 12 feet wide. Machine aproximatly 128 inches tall. Chassis and undercarriage mild steel. Conveyors and structure above main frame all stainless steel. Aluminum diamond floor plate for flooring.
