Zhejiang Changheng Machinery Co., Ltd. products

PTO Shaft

Plain Bore Yoke

Triangular Tube/Lemon Tube/Star Tube. Series 1- Series 8. Cross to Cross: 610mm/810mm/1010mm/1210mm... or as your requirements. Plastic Shield: Black/Yellow. Connection Method: Pin connected. Tractor Part: Splined yoke. Implement Part: Plain Bore Yoke/Clutch.

Agricultural Gearbox

1.Speed Ratio:1:1.93. Input:1000RPM; 30KW; 40HP-CV; 286NM. Output:1930RPM; 148NM. 2.Speed Ratio:1:1.47. Input:1000RPM; 30KW; 40HP-CV;286NM. Output:1470RPM; 194NM.

Agricultural Gearbox

Speed Ratio: 1:2.83.Input:540RPM; 33KW; 45HP-CV; 583NM.Output:1528RPM; 206NM.

Agricultural Gearbox

Speed Ratio: 1:1.46. Input: 540RPM; 13KW; 17.5HP-CV;230NM. Output: 788RPM; 158NM.

Agricultural Gearbox

Speed Ratio: 3:1. Input: 540RPM; 44KW; 60HP-CV; 778NM. Output: 180RPM; 2334NM.

Plain Bore Yoke

Implement part.Plain bore yoke A - pin hole.series 1 - series 8.

Plain Bore Yoke

Implement part. Plain bore yoke B - keyway. Series 1- series 8.

Plain Bore Yoke

Implement part. Plain bore yoke C - keyway & threaded hole. Series 1- series 8.
