10 Series - Tractors Brochure

10 SERIES• #1 Selling Tractor in the World• 5-year Powertrain Warranty• 97% Customer Satisfaction Rating• 98% Customer Loyalty RatingJAPAN QUALITY MEDAL 2007DEMING PRIZE 2003• Smooth, quiet running, 3 & 4 cylinder• Easy access to service items• Heavy duty design • Powerful 3-point lift • Standard rear remote - excluding 4010• Comfortable operator station• Simple to operate• Rubber floor mat• Attractive, easy to read gauges• Easy to use push button controls• Tilt steeringEngine – left side view 3-point hitch Platform Dash panelECONOMY - 10 SeriesThe Mahindra 10 series tractors are rugged, hard-working and economical 4WD utility tractors designed for light- to medium-duty applications. These practical, no-nonsense models are available from 38 to 59 HP with a wide range of choices – open station or cab, heavy-duty loaders, heavy-duty backhoes, Ag or Industrial tires and with a wide range of available implements that provides you with everything you need to get your work done.Key Features:• Fuel efficient 3 & 4 cylinder engines• Larger tires for better traction and stability• Choice of Industrial or Ag tires• Best-in-class loader lift capacities• Spacious full flat operator’s platform• Hydrostatic power steering and tilt• Independent 540 rpm PTO• STANDARD adjustable suspension seat• STANDARD rear remote valve (excluding 4010)• STANDARD 5-year limited warranty - Industry’s BestIdeal For:• Speciality / Hobby Farming• Grounds Maintenance / Municipal• Material Handling• Livestock• Dairy• Rural Lifestyle• Hay• Equine• HomeSUPERIOR PERFORMANCE. GREATER VALUE.• Superior lift capacity = Lift heavier loads• 5 year warranty = Peace of mind• Professional grade construction = Bigger, thicker, more solid components• Heavier, sturdier chassis = Greater traction, stability & safetySteel hoodConvenient push button controlsWide-open, easy access platformModern stylish grille and headlight assemblyTilt steeringStandard rear remote (excluding 4010)Adjustable suspension seatHeavy built rugged design4010 50106010 HST CabMahindra offers a huge selection of implements to help you accomplish whatever task you wish to tackle and provide a complete Mahindra experience.• Wide array of implements (186 variations)• Competitive financing terms• Standard-, Medium-, and Heavy-Duty implements to meet your needs• Implements feature rugged construction with heavy-duty components• 5 year gearbox limited warranty• SNOW BLOWERS and SNOW REMOVAL equipment to meet cold-weather needs• BEST VALUE in the market todayAVAILABLE IMPLEMENTSTRACTOR 4010 4WD Gear 4010 4WD HST 5010 4WD Gear 5010 Gear Cab 5010 HST Cab 6010 HST Cab 6110 Shuttle CabLOADER ML140 ML141 ML151 ML156 ML161Maximum Lift Height 101.9” 102.2” 115.4” 115.4” 115.4”Clearance with Attachment Dumped 73” 73.4” 82.3” 82.3” 82.3”Reach at Maximum Height 21.9” 21.8” 23” 23” 23”Maximum Dump Angle 42° 42° 69° 69° 69°Attachment Rollback Angle 35° 35° 39° 39° 39°Digging Depth Below Grade 4.8” 4.4” 5.2” 5.2” 5.2”Lift Capacity to Full Height @ Pivot Pins 2041 2041 3122 3122 3122Breakout Force @ Pivot Pins 3430 3430 5225 5225 5225Rated Flow (Tractor System) 8.2 gpm 8.2 gpm 9.5 gpm 9.5 gpm 9.5 gpmAttachment Width 66” 66” 72” 72” 72”Attachment Rated Capacity 10.8 ft3 10.8 ft3 11.2 ft3 11.2 ft3 12.8 ft3Cycle Times @ rpm 2600 2600 2600 2600 2600Raise Boom (seconds) 4.3 4.3 6.0 6.0 6.0Lower Boom (seconds) 3 3 4.0 4.0 4.0Dump Attachment (seconds) 3.5 3.5 4.9 4.9 4.9Retract Attachment (seconds) 2.6 2.6 3.2 3.2 3.2BACKHOE MODEL ANBH76 595 595TRANSPORTTransport Height 75” 94” 94”Transport Overhang 45” 56.50” 56.50”OPERATIONALMaximum Digging Depth 92” 115” 115”Digging Depth (2 Ft.) Flat Bottom 90” 114” 114”Overall Operating Height - Fully Raised 122” 146” 146”Loading Height (bucket @ 60°) 68” 82” 82”Loading Reach (bucket @ 60°) 63” 53” 53”Reach From Swing Post 112” 154” 154”Bucket Rotation 140° 180° 180°Swing Arc 180° 180° 180°Stabilizer Spread Operating Position 91” 127” 127”Stabilizer Down Below Grade 10” 10” 10”System Relief Valve Setting (psi) 2248 2750 2750Digging Force - Bucket (lbs.) 3080 5710 5710Digging Force - Dipper (lbs.) 2160 3188 3188Cab Featuresincluding, but not limited to -• HVAC• Wide opening doors• Work Lights• Large glass surface area (clear 360° view)• Excellent headroom and visibilityTRACTOR ATTACHMENTSTRACTOR 4010 4WD 4010 4WD 5010 4WD 5010 Cab 5010 Cab 6010 Cab 6110 CabENGINE Gear HST Gear Gear HST HST ShuttleType 3B183LW Indirect injection Indirect injection Turbo-charged, indirect injectionCylinders 3 4 4Engine HP (kW) @ rpm 38 (28.3) @ 2600 49 (36.5) @ 2500 49 (36.5) @ 2600 59 (44) @ 2600Compression Ratio 22:1 22:1Displacement cubic inch3 (cc) 111.4 (1826) 148.6 (2435) 148.6 (2435)Fuel Tank Capacity 9.0 gallons 16 gallons 16 gallons 18.5 gallonsELECTRICALBattery Capacity 12 volt, 80 amp hours 12 volt, 80 amp hoursAlternator 12 volt, 50 amps 12 volt, 50 ampsCLUTCHType Single plate, dry N/A Single plate, dry Single plate, dry N/A Single plate, dryTRANSMISSIONType Mechanical (Constant mesh)3 ranges Constant mesh Constant mesh 3 ranges Sync, shuttle w/ part synchromeshNumber of Gears / Speeds 9F / 3R Infinite 9F / 3R 9F / 3R Infinite 12F / 12RMax Speed Forward / Reverse mph (kmph) 12.9 (20.8) / 8.4 (13.5)N/A 15.3 (24.7) / 9.2 (14.8)15.3 (24.7) / 9.2 (14.8)17.7 (28.4) / 17.7 (28.4) 20.0 (32.2) / 20.5 (33.0)STEERINGType Hydrostatic/ Tiltable Hydrostatic/ TiltablePump Output (gallons per minute) 4.5 5 5 5.4BRAKESType Wet Disc Wet DiscHYDRAULIC SYSTEMType Open Center with position control Open Center with position control Open Center with position and draft controlPump Output (gallons per minute) 8.2 9.5 9.5 113-Point Linkage Category 1 with check chains Category 1 with check chains Category 1, with telescopic check chainsCategory 2, with telescopic check chainsLift Capacity (lbs.) 2646 3314 3314 3527Rear Auxiliary Remote Valves 2 spool optional 1 spool optional 1 Standard, 3 optional1 Standard, 3 optionalPTOType Independent IndependentPTO RPM (engine rpm) 540 @ 2650 540 @ 2600 540 @ 2600PTO HP (kW) 31 (23.1) 29 (21.6) 41.5 (31) 41.5 (31) 38 (28.5) 44 (33.5) 48.5 (36.2)OPERATING WEIGHTTotal (lbs.) 3065 3836 4078 4144 4850DIMENSIONS with Industrial TiresOverall Length Inches (mm) 119.3 (3030) 134 (3406) 134 (3406) 135.3 (3436) 141.3 (3590)Overall Width Inches (mm) 59.8 (1520) 71.1 (1807) 71.5 (1816) 71.1 (1807) 71.5 (1817)Turning Radius Minimum Feet (meters) 7.87 (2.4) 11 (3.36) 11 (3.36) 12.5 (3.81)Overall Height Inches (mm) 94.4 (2400) 101 (2565) 98.4 (2500) 99.2 (2520)TIRES Sizes and OptionsAg (Front / Rear) 8.3x16 / 12.4x24 9.5x16 / 14.9x24 9.5x16 / 14.9x24 9.5x20 / 14.9x28Industrial (Front / Rear) 10-16.5 / 43x16-20 12x16.5 / 16.9x24 12x16.5 / 16.9x24 10.5/80x18 / 18.4x24Golf Tires N/A LSW305-521 / LSW570-648 6PRLSW305-521 / LSW570-648 6PRTRACTOR SPECIFICATIONS9020 JACKRABBIT RD., Suite 600 • Houston, Texas 77095 • 877-449-7771MahindraUSA.com • MahindraCanada.ca© 2014 Mahindra USA MAH-0114 MAH5410
