bema Snow Plough Serie 700-Technical Data Sheet

SNOW CHAMPIONSTO COMBAT WINTER SNOWTEAM WINTERbema snow plough serie 1100 bema snow plough serie 700bema snow plough serie 550bema V-plough V800 A clean product line.®SNOW CHAMPIONS – Features at a glanceSpecial featuresTechnical detailsThe bema SNOW CHAMPIONS were developed for use on civic vehicles, tractors and loaders for winter road service. Durable Polyurethan-skirting protects the road surface during snow removal through an optimal fit to the ground.• Optimum adaptation to ground contours through spring apron segments and hard wearing Polyurethan trim prevents damage to the road surface during snow removal.• Flexible edge protectors avoid damage to curbs and edges of buildings.• Two continuously height adjustable wheels ensure the exact alignment of the entire clearing strip.• Swivelling by 30° via two hydraulic cylinders.• Continuous adjustment of the wheels by hand wheels.• Level adjustment compensates for vertical movement as well as tilt of the machine.bema V800• Mounting: Compact and close to the vehicle.• Variable application due to different positions of the plough blade. www.kehrmaschine.deinfo@kehrmaschine.deRecker Straße 16D-49599 Voltlage-Weesebema GmbH MaschinenfabrikTel. +49 (0) 5467 . 92 09 - 0Fax +49 (0) 5467 . 92 09 - 20Our company is certi? edSerie /SNOW CHAMPIONSTEAM WINTER• New alternatives:• Basic configuration - Polyurethan strips• Option 1 - Spring apron/Wheels• Option 2 - Spring apron/Galvanised skid plates• Stability of the plough by lateral and upper folded edges• Edge protectors flexibleAttaches to:• Wheel loader• Yard loader• Forklift• Tractor• Municipal vehicle• Special vehicleSnow ploughTechnische DatenBasic configurationBasic configuration - Polyurethan strips: • Snow plough with Polyurethan trim 30 x 200 mm• Swivelling mechanically• Edge protectors flexible, for protection against damage from curbs and walls• Parking supports (sides) with quick locking• Series two component painting orange RAL 2011• CE certification and operating manualOption 1 - Spring apron/Wheels: Basic configuration with• Spring apron segments with Polyurethan trim 20 x 150 mm• Wheels Ø 200 x 50 mm step less height adjustment by crank or heavy duty wheels Ø 200 x 50 mm step less height adjustment by crankOption 2 - Spring apron/Galvanised skid plates: Basic configuration with• Spring apron segments with Polyurethan trim 20 x 150 mm• Galvanised skid plates Ø 180 mm, adjustable by crankbema reserves the right to change the technical data at any time.Optional extra equipment• Attaches to:• Municipal tractor three-point mount cat. I/II or coupling triangle cat. I/II or I N, with roller levelling - service free -• Municipal tractor three-point mount cat. 0 with roller levelling - service free -• Municipal vehicles mounting plates with roller levelling - service free -• Forklift attachment with roller levelling - service free -• Quick change adaptor with roller levelling for wheel- and yardloaders up to 0,4 m³ bucket capacity - service free -• Hydraulic swivelling system 30° by 2 stable hydraulic cylinders and hydraulic connector plug SVK size 3• Hydraulic swivelling system 30° and integrated overload protection by 2 stable hydraulic cylinders and hydraulic connector plug SVK size 3• Pressure control valve• Rubber blade with corundum inlay• Flag holder, flags and warning marks• Lighting system (necessary if used on public roads)• Hydraulic connector on demand• Special paint finishSnow plough 700 Typ 1300 Typ 1550 Typ 1800 Typ 2050 Typ 2300 Typ 2550Width (over all) 1290 mm 1535 mm 1780 mm 2025 mm 2270 mm 2520 mmClearing width, swivelled 30° 1115 mm 1330 mm 1540 mm 1750 mm 1965 mm 2180 mmStandard height (over all) 700 mm 700 mm 700 mm 700 mm 700 mm 700 mmMachine weight Basic configuration - Polyurethan stripsapprox. 120 kgapprox. 130 kgapprox. 140 kgapprox. 150 kgapprox. 185 kgapprox. 195 kgMachine weight Option 1 - Spring apron/Wheelsapprox. 165 kgapprox. 180 kgapprox. 190 kgapprox. 200 kgapprox. 235 kgapprox. 245 kgMachine weight Option 2 - Spring apron/Galvanised skid platesapprox. 140 kgapprox. 150 kgapprox. 160 kgapprox. 170 kgapprox. 205 kgapprox. 220 kgPolyurethan trim Basic configuration 30 x 200 mm 30 x 200 mm 30 x 200 mm 30 x 200 mm 30 x 200 mm 30 x 200 mmPolyurethan trim Option 1/Option 2 20 x 150 mm 20 x 150 mm 20 x 150 mm 20 x 150 mm 20 x 150 mm 20 x 150 mmNEWwww.kehrmaschine.debema 09/14 We do not accept liability for printing errors Copyright © 2013 bema GmbH Maschinenfabrik
