Bucket Elevators Brochure

124Bucket ElevatorsSECTION VIBUCKET ELEVATORS SECTION VIElevator Types...........................................................................125Selection ...................................................................................126100 & 200 Series.......................................................................131700 & 800 Series.......................................................................133 1000 & 1100 Series ...................................................................1351400 Series ...............................................................................137100 & 700 Series Dimensions ...................................................139Safety ........................................................................................140Troubleshooting.........................................................................143pages 113 - 128 4/7/05 11:03 AM Page 124125Elevator TypesCentrifugal discharge bucket elevatorsElevators of this design predominate in the bulk handling of free-flowing, fine and loose materials with smallto medium size lumps. Buckets, mounted at spaced intervals, are loaded by scooping up material from theboot or by feeding the material into them. Material is discharged by centrifugal action as the buckets passover the head wheel. These elevators are made in several types and are suitable for many requirements.Type BE100 Elevators of this type meet the service requirements of the majority of installations using cen-trifugal discharge elevators. The head shafts are fixed. The foot shaft takeups are of the screw type. Gravitytakeups are available. Buckets are of malleable iron for use on chain or belt. Casings are of steel plate andangle construction.Type BE200 These elevators are similar to Type BE100 except that the head shafts are adjustable andthe foot shafts are fixed to maintain the relation of buckets to the loading chute and curved bottom plate.They are preferred for handling food products, materials which tend to pack or build up in the bottom of theboot, and for materials having a considerable percentage of lumps.Type BE1400 This elevator is designed primarily for cement mill service, but is suited for many other simi-lar abrasive service applications. Their design and rugged construction makes them ideally suited for han-dling cement, clinker, crushed stone, bauxite, feldspar, gravel, gypsum, roofing granules, sand, shale, etc.They are available in a full range of sizes extending to the very high capacities and lifts.Continuous bucket elevatorsElevators of this design are made in a number of types for handling many bulk materials ranging from lightto heavy and from fines to large lumps. Buckets are spaced continuously and loaded by direct feeding,except for Type BE800 elevator where material is scooped from the boot. Spillage between buckets is pre-vented by their close spacing. As buckets discharge, the material flows over the preceding bucket, whosefront and projecting sides form a chute, to the discharge spout.Type BE700. This elevator is the most frequently used of the continuous bucket design. The head shaftsare fixed. The foot shaft takeups are of the screw type. Gravity takeups are available. Buckets are of steeland spaced continuously on a single strand of chain. Casings are of steel plate and angle construction.Material is fed to the buckets through a loading leg.Type BE800 Elevators of this type are used for the handling of fine or crushed materials with lumps notexceeding 1/2 inch. These elevators are similar to Type BE 700, except that head shafts are adjustable andfoot shafts are fixed, to maintain the relation of buckets to the loading chute and curved bottom plate.Buckets are loaded by scooping up material from the boot. When modified by the addition of a loading legand a correspondingly higher inlet spout, this type elevator can also be used for handling lumpy materials.Type BE800L Identical to Type BE800 except with loading leg and stub inlet chute.Type BE1000 This elevator is of the super-capacity type and used for handling friable, heavy or abrasivematerial ranging from fines to large lumps. The head shafts are fixed and the foot takeups are of the screwtype. Gravity takeups are available. Continuous buckets are end-mounted between two strands of ClassSS bushed roller chain. Material is fed to the buckets through a loading leg. Casings are of steel plate andangle construction. Type BE1100 These elevators are similar in design to Type BE 1000, except for greater capacities andcenters. Head terminal machinery and driving equipment are carried on independent supports. The foottakeups are of the screw type. Gravity takeups are available.pages 113 - 128 4/7/05 11:03 AM Page 125126SelectionOperatingConditionRecommended casing material and thicknessother than standard.Standard listed thickness of casing14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in. ProductcontaminationCorrosiveExposed toweatherDamp or moist14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in.14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in. 14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in. 10 ga. 3/16 in. 1/4 in. Relatively cleanOutdoors,sheltered fromweatherMildly corrosiveExposed toweatherDamp or moist14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in.14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in. 10 ga. 3/16 in. 3/16 in. 1/4 in. 3/8 in. 10 ga. 3/16 in. 3/16 in. 1/4 in. 3/8 in.1/4 in. 1/4 in. 3/8 in.CorrosiveExposed toweather Dampor moist14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in.14 ga. 12 ga. 10 ga. 3/16 in. 1/4 in. 10 ga. 3/16 in. 1/4 in. ProductcontaminationCorrosive fumesDamp or moist14 ga. 12 ga. 10 ga. 10 ga. 3/16 in.14 ga. 12 ga. 10 ga. 10 ga. 3/16 in.10 ga. 10 ga. 3/16 in.Recommended casing materials and thicknessCommercial hot rolled mild steelCommercial hot rolled mild steelgalvanized or coatedLow alloy steelStainless steel and Monel metalElevatorTypeMaximum lumpsize, inchesMaximum capacity Maximum centers, feet • Cubic feetper hourTons per hourBushelsper HourMaterial Weight(pounds per cubic foot)Percentageof lumpsMaterial Weight(pounds per cubic foot)100 10 35 50 75 100 125 35 50 75 100 125BE100 1-1/4 4 2000 35 50 75 100 80 80 80 801-1/2 4-1/2 3100 55 78 117 156 80 80 80 70BE200t 1-1/4 4 2000 35 50 75 100 80 80 80 801-1/2 4-1/2 3100 55 78 117 156 80 80 80 70BE7001 3 1300 23 32 49 65 70 70 70 701-1/4 4 1800 32 45 68 91 80 80 80 801-1/2 4-1/2 2350 41 58 88 117 80 80 80 70BE800t1/2 1/2 1300 32 49 65 70 70 70 701/2 1/2 1800 45 68 91 80 80 80 801/2 1/2 2350 58 88 117 80 80 80 80BE10002 6 2400 60 90 120 150 85 70 55 452 6 2800 70 105 140 175 75 60 50 402 6 3200 80 120 160 200 75 55 45 352 6 3600 90 135 180 225 65 50 40 302 6 4000 100 150 200 250 60 45 35 303 8 5600 140 210 280 350 75 65 55 453 8 6800 170 255 340 425 60 55 45 403 8 8400 210 315 420 525 55 50 40 303 8 10000 250 375 500 625 50 45 35 303 8 12400 310 465 620 775 40 35 25 20BE11003 8 5600 140 210 280 350 125 125 125 1103 8 6800 170 255 340 425 125 125 110 953 8 8400 210 315 420 525 125 110 95 803 8 10000 250 375 500 625 125 100 85 753 8 12400 310 465 620 775 100 80 70 60BE14001-1/2 2 2000 50 75 100 125 80 80 80 701-1/2 2 2800 70 105 140 175 80 75 80 651-1/2 2 4200 105 157 210 262 80 80 60 801-1/2 2-1/2 4600 115 172 230 287 80 80 80 801-1/2 2-1/2 6900 172 258 345 430 70 60 50 451-1/2 2-1/2 6350 159 238 317 397 80 80 75 751-1/2 2-1/2 9500 238 356 475 594 75 65 45 501-1/2 3 8500 213 319 425 532 80 80 70 601-1/2 3 12750 318 477 635 795 70 55 45 35Tenative elevator selectiont These elevators have fixed boot shafts and curved bottom plates, they are recommended for food handling applications, materials with high percentage of lumps and materials that tend to pack .• Consult Thomas Conveyor Company for application requiring centers greater than those listed above. pages 113 - 128 4/7/05 11:03 AM Page 126127Materials TableMaterial Density Lbs./Cu. Ft. Material Code Elevator SeriesAlfalfa Meal 17 B46Y 700, 800Almonds, broken 28-30 C36Q 200, 700, 800Almonds, whole 28-30 C36Q 700Alum, fine 45-50 B35 200, 700Alum, lumpy 50-60 D35 200, 700Alumina 50-65 B27M 700 BELTAluminum chips 7-15 E46Y 700Aluminum hydrate 18 C35 700Aluminum ore, crushed (3" minus) 75-85 D37 100, 200, 700Aluminum oxide 70-120 A17M 700Aluminum silicate 49 B35S 700Aluminum sulphate 54 C25 700Ammonium chloride, crystalline 45-52 B25S 700, 800Ammonium nitrate 45 C36WUS 700, 800Ammonium sulphate, granular 45-58 C26S 700, 800Ashes (dry coal 3" minus) 35-40 D46T 200Asphalt, crushed (1/2" minus) 45 C35 100, 200, 700, 800Bakelite, powdered (similar products) 35-45 B25S 700, 800Baking powder 40-55 A25 700, 800Barite 180 D36 700, 800, 1000, 1100Barley 38 B15N 100, 200 BELTBauxite, crushed (3" minus) 75-85 D37 100, 200, 700, 1000, 1100Beans, whole castor 36 C15W 100, 200Beans, dry navy 48 C15W 700, 800Bentonite, crude 35-40 D46X 100, 200Bentonite (100 mesh minus) 50-60 A26XY 700, 800Bones, crushed (1/2" minus) 34-40 C26W 100, 200, 1400Bones, granulated or ground (1/8" minus) 50 B26W 100, 200, 1400Bone meal 55-60 B36 100, 200, 700, 800Borax, fine 45-55 B26T 100, 200, 700, 800Borax, screenings (1/2" minus) 55-60 C36 100, 200Bran 16-20 B35NY 100, 200Brewers grain, spent wet 55-60 C45T 100, 200Brewers grain, spent dry 25-30 C45T 100, 200Calcium oxide 60-65 B45X 100, 200, 700, 800,1000, 1100, 1400Carbon black, pelletized 20-25 B15Q 700, 800Carbon black powder, channel 4-7 A35Y *CFCarbon black powder, furnace 4-7 A35Y *CFCarborundum (3" minus) 100 D27 700Cast iron borings 130-200 C46 100, 200Cement, portland 94 A26M 100, 200, 700, 800Cement, portland aerated 60-75 A16M 100, 200, 700, 800, 1400Cement clinker 75-95 D37 200, 700, 1000, 1100, 1400Chalk, lumpy 75-85 D26 100, 200, 700, 800Chalk, pulverized (100 mesh minus) 65-75 A46MXY 700, 800Charcoal 18-25 D36Q 700Cinders, coal 40 D37T 200, 700Cinders, blast furnace 57 D37T 200, 700Clover seed 48 B25N 100, 200* CF = Consult Factory128MaterialsTableMaterial Density Lbs./Cu. Ft. Material Code Elevator SeriesCoal, anthracite sized 55-60 C26 100, 200, 700, 800, 1400Coal, anthracite, river coal & culm 55-60 B35TY 100, 200, 700, 800, 1400Coal, bituminous, mined 50 mesh minus 50-54 B45T 700, 800Coal, bituminous, mined, slack, 1/2" minus 43-50 C45T 100, 200, 700, 1000, 1100, 1400Coal, bituminous, mined, sized, over 1/2" 45-55 D35T 700, 1000, 1100, 1400Coal, bituminous, mined, run of mine 45-55 D35T 100, 200, 700, 1000, 1100, 1400Coal, bituminous, mined, stripping, 50-60 D36T 100, 200, 700, 1000, 1100, 1400uncleaned over 1/2"Cocoa beans 30-40 C25Q 100, 200, 700Coffee, green bean 32 C25Q 100, 200, 700, 800Coffee, roasted bean 22-26 C15W 100, 200, 700, 800Coke, loose 23-35 D47QVT 200 BELTCoke, petroleum, calcined 35-45 D36Y 200 BELTCoke breeze, /4" minus 25-35 C37Y 100, 200 BELTCopra 22 D25 100, 200, 700Copra Cake, lumpy 25-30 D25W 100, 200, 700Copra Cake, groud 40-45 B35W 100, 200, 700, 800Copra meal 40-45 B35W 100, 200, 700, 800Cork, fine ground 12-15 B45MY 700, 800Cork, granulated 12-15 C45T 700, 800Corn, cracked 45-50 C25W 100, 200Corn, seed 45 B15N *CFCorn, shelled 45 D37 *CFCorn germs 21 B25W 100, 200Corn grits 40-45 B25W 100, 200Corn sugar 31 B35 100, 200Cornmeal 38-40 B35W 100, 200Cottonseed, dry delinted 35 C25W 100, 200, BELTCottonseed, dry with lint 18-25 C35W 100, 200, BELTCottonseed, cake, lumpy 40-45 D25W 100, 200Cottonseed hulls 12 B45Y 700, 800Cottonseed meal 35-40 B35W 100, 200Cottonseed meats 40 B35W 100, 200Cullet 80-120 D37Z 200 BELTCracklings, crushed, 3" minus 40-50 D45 100, 200Dolomite, lumpy 90-100 D26 200, 700, 1000, 1100, 1400Ebonite, crushed 1/2" minus 65-70 C25 200, 700, 800Feldspar, ground /2" minus 70-85 B36 100, 200 ,700Feldspar, powdered 200 mesh 100 A46 700, 800Flaxseed cake, expeller 48-50 D35T 200Flaxseed meal 25 B25W 100, 200Flour, wheat 35-40 A45PN 100, 200, BELTFlue dust, boiler house, dry 35-40 A17MTY 700, 800 (select elevator with double the required capacity)Flourspar, 1/2" screenings 85-105 C46 100, 200, 700Fuller's Earth, dry 30-35 B26 100, 200 BELTFuller's Earth, oily 60-65 B26 100, 200 BELTFuller's Earth, burnt, oil filter 40 B26 100, 200 BELTFuller's Earth, raw, oil filter 35-40 B26 CF 100, 200 BELTGlass batch 80-100 D27Z 200 BELTGlue, ground, 1/8" minus 40 B26 200* CF = Consult Factory129MaterialsTableMaterial Density Lbs./Cu. Ft. Material Code Elevator SeriesGlue, pearl 40 C25 200Grains, distillery, spent dry 30 E25WY 100, 200Granite, 1/2" screenings 80-90 C27 1000, 1100, 1400Grass seed 10-12 B25NY 700, 800Gravel, screened 90-100 D36 100, 200, 700, 1000, 1100, 1400Gypsum, dust, non-aerated 93 A46 100, 200, 700, 1000, 1100, 1400Gypsum, dust, aerated 60-70 A36Y 100, 200, 700, 1000, 1100, 1400Gypsum 1/2" screenings 70-80 C36 100, 200, 700, 800, 1400Gypsum, 1 1/2" to 3" lumps 70-80 D26 1000, 1100, 1400Hops, spent, dry 35 E35 100, 200Hops, spent, wet 50-55 E35T 100, 200Ice, crushed 35-45 D16 200, 700Ilmenite ore 140-160 B27 100, 200, 700, 1000, 1100, 1400Lignite, air dried 45-55 D25 *CF 100, 200, 700Lime, ground, 1/8" minus 60-65 B45X 100, 200, 700, 800, 1000, 1100, 1400Lime, hydrated, 1/8" minus 40 B35MX 700, 1000, 1100Lime, pebble 53-56 D35 100, 200, 700, 1000, 1100, 1400Lime, hydrated, pulverized 32-40 A35MXY 100, 200, 700, 1000, 1100, 1400Limestone, agricultural, 1/8" minus 68 B26 100, 200, 700, 1000, 1100, 1400Limestone, crushed 85-90 C26X 700, 1000, 1100, 1400Limestone, dust 80-85 A46MY 100, 200, 700, 800, 1000, 1100, 1400Linseed meal 25 B25W 100, 200Malt, dry ground, 1/8" minus 22 B25NR 100, 200Malt, dry, whole 27-30 C25N 100, 200Malt, wet or green 60-65 C45 100, 200Malt meal 36-40 B25 100, 200Marble, crushed, 1/2" minus 34-40 C26W 100, 200, 1400Meat Scrap 50-55 E357W 100, 200Muriate of potash 77 B27 100, 200, 700Mustard seed 45 B15N 100, 200Oats, rolled 19 C25NY 100, 200Oxalic acid crystals 60 B35SU 100, 200 BELTPeas, dried 45-50 C15NG *CFPeanuts, shelled 35-45 C25Q *CFPhosphate rock, broken, dry 75-85 D26 200, 700, 1000, 1100, 1400Phosphate rock, pulverized 60 B36 100, 700 BELTPhosphate, triple super 50-55 B45T 700, 800, 1000, 1100, 1400Phosphate, acid fertilizef 60 B25T 700, 800, 1000, 1100, 1400Pumice, ground, 1/8" minus 40-45 B47 700Rice bran 16-20 B35NY 100, 200Rice grits 42-45 B35 100, 200Roofing granules 85-95 B27 1400Rubber, ground 65-70 C25 200, 700, 800Salt, dry, fine 70-80 D26TUW 200, 700, 800, 1400Salt, dry, coarse 40-55 C26TU 200, 700, 800, 1400Salt, cake, dry, coarse 85 B36TW 200, 700, 800, 1400Salt, cake, dry, pulverized 60-85 B26NT 200, 700, 800, 1400Sand, damp bank 110-130 B47 100, 200 BELT* CF = Consult Factory130MaterialsTable* CF = Consult Factory** If sand is hot, use high temperature belt & insulating pads between buckets and belt.L^ = Loading legMaterial Density Lbs./Cu. Ft. Material Code Elevator SeriesSand, dry bank 90-110 B37 100, 200 BELTSand, dry silica** 90-100 B27 100, 200 BELTSand, foundry, prepared 70-90 B47 100, 200 BELTSand, foundry, shakeout 90-100 D37 100, 200 BELTSawdust 10-13 B35 1100Shale, crushed 85-90 C36 100, 200 BELTSlag, blast furnace, crushed 80-90 A27 700, 1000, 1100Slag, blast furnace, granulated, dry 60-65 C27 700, 1000, 1100Slag, blast furnace, granulated, wet 90-100 B47 700, 1000, 1100Slate, crushed, 1/2" minus 80-90 C26 200 BELT, 700, 1000, 1100Slate, dust 70-80 A36Y 100, 200 BELTSoap beads or granules 15-25 B25Q *CFSoap flakes 5-15 B35QXY *CFSoda ash, light 20-35 A36Y 700, 800Soda ash, heavy 55-65 B36 100, 200, 700, 800Soybeans, cracked 30-40 C26NW 100, 200Soybean cake, over 1/2" 40-43 D35W 200Soybean flakes, raw 20-26 C25Y 100, 200Soybean meal, cold 40 B35 100, 200Soybean meal, hot 40 B35T 100, 200Steel chips, crushed 100-150 D27WZ 700Stone, crushed 90-100 D36Q 100, 200, 700, 1000, 1100, 1400Sugar, powdered 50-60 B235PTY 200, 800L^Sugar, granulated 50-55 B235PT 200, 800L^Sugar beet, pulp, dry 12-15 *CF 700, 800Sugar beet, pulp, wet 55-65 B36TX 700, 800Sugar, raw, cane 55-65 B36TX 100, 200Tanbark, ground 55 *CF 100, 200Timothy seed 36 B25NY 700, 800Wheat, cracked 40-45 B25N 100, 200Wheat germ 28 B25W 100, 200Wood chips 10-30 E45WY 100, 200 BELTWood shavings 8-15 E45V 100, 200 BELTZinc dust 200 E45V 700, 800, 1000, 1100, 1400Zinc concentrate 75-80 B26 700, 800, 1000, 1100, 1400Zinc ore, crushed 160 *CF 700, 800, 1000, 1100, 1400Zinc ore, roasted 110 C36 700, 800, 1000, 1100, 1400Zinc oxide, heavy 30-35 A35X 700, 800, 1000, 1100Zinc oxide, light 10-15 A35XY 700, 800131100 & 200 SeriesChain Type100 & 200 Series Chain Type Centrifugal DischargeBucket Elevator DataFEATURES1. Split removable hood for accessibility.2. Head shaft mounted in fixed ball or roller bearing pillow blocks.3. Discharge spout positioned for clean discharge of product.Style 1 shown. Style 2, with horizontal flange is optional.4. Rigid, strong dust and/or weather tight casings.5. Style AA malleable iron buckets are standard. Other materialssuch as plastic, nylon and fabricated steel are available.6. C-class combination chain is standard. SS class chain isavailable for heavy duty applications and is standard on some sizes.7. Bolted or hinged access doors are provided for installing andservicing the elevator buckets.8. Removable bolted side panels in the boot for cleanout and service.9. Screw type boot take-ups with ball or roller bearings are standard. Internal and external gravity type take-ups are available.10. Hopper type intake is standard.11. Curved bottom plate.12. Shaft mount drive is standard. Other drives available on request.NOTE: The 200 series chain type elevator is standard with screw typehead take-ups with ball or roller bearing pillow blocks. The bootshaft is fixed and mounted in ball or roller bearing pillow blocks.Elevator Max. Speed Buckets Chain Head Sprocket Boot Sprocket Casing BootNumber Capacity FPM@RPM L X W X Spacing Number Tooth X PD Tooth X PD Dim’s. ShaftBE102 280 225 @ 43 6 X 4 X 13 C188 24 X 20.0 18 X 15 9 3/4 X 35 1 1/2BE104 540 230 @ 43 8 X 5 X 16 C102B 16 X 20.5 10 X 13 11 3/4 X 39 1 1/2BE107 612 260 @ 41 8 X 5 X 16 C102B 19 X 24.25 14 X 18 11 3/4 X 42 2BE110 936 230 @ 43 10 X 6 X 16 C102B 16 X 20.5 12 X 15.5 13 3/4 X 42 2BE112 960 268 @ 41 10 X 6 X 18 C110 13 X 25 12 X 21.25 13 3/4 X 48 2BE116 1048 260 @ 41 10 X 6 X 16 C102B 19 X 24.25 12 X 20.5 13 3/4 X 48 2BE117 1536 268 @ 41 12 X 7 X18 SS110 13 X 25 9 X 17.5 15 3/4 X 48 2BE119 1668 260 @ 41 12 X 7 X 16 C102B 19 X 24.25 14 X 18 15 3/4 X 48 2BE120 1744 306 @ 38 12 X 7 X 18 SS110 16 X 30.75 12 X 23.25 15 3/4 X 48 2 7/16BE122 1948 304 @ 38 12 X 7 X 16 C102B 24 X 30.5 19 X 24.25 15 3/4 X 48 2 7/16BE123 1700 260 @ 41 14 X 7 X 19 C111 16 X 24.25 12 X 18.25 17 3/4 X 48 2 7/16BE124 1848 268 @ 41 14 X 7 X 18 SS110 13 X 25 9 X 17.5 17 3/4 X 48 2 7/16BE126 2016 260 @ 41 14 X 7 X 16 C102B 19 X 24.25 14 X 18 17 3/4 X 48 2 7/16BE127 1988 304 @ 38 14 X 7 X 19 C111 20 X 30.5 16 X 24.25 17 3/4 X 54 2 7/16BE128 2112 306 @ 38 14 X 7 X 18 SS110 16 X 30.75 12 X 23.25 17 3/4 X 54 2 7/16BE130 2360 304 @ 38 14 X 7 X 16 C102B 24 X 30.5 19 X 24.25 17 3/4 X 54 2 7/16BE131 2540 262 @ 41 16 X 8 X 19 C111 16 X 24.25 11 X 17 19 3/4 X 48 2 7/16BE132 2540 248 @ 41 16 X 8 X 18 SS110 12 X 23 8 X 15.75 19 3/4 X 48 2 7/16BE133 2940 304 @ 38 16 X 8 X 19 C111 20 X 30.5 14 X 21.25 19 3/4 X 54 2 7/16BE134 3120 306 @ 38 16 X 8 X 18 SS110 16 X 30.75 11 X 21.25 19 3/4 X 54 2 7/16pages 129 - 144 4/20/05 8:21 AM Page 131132100 & 200 Series Belt Type100 & 200 Series Belt Type Centrifugal Discharge BucketElevator DataFEATURES1. Split removable hood for accessibility.2. Head shaft mounted in fixed ball or roller bearing pillow blocks.3. Discharge spout positioned for clean discharge of product.Style 1 shown. Style 2, with horizontal flange is optional.4. Rigid, strong dust and/or weather tight casings.5. Style AA malleable iron buckets are standard. Other materialssuch as plastic, nylon and fabricated steel are available.6. Rubber and/or PVC belts are standard. Other materials are availableto suit your application.7. Bolted or hinged access doors are provided for installing andservicing the elevator buckets.8. Removable bolted side panels in the boot for cleanout and service.9. Screw type boot take-ups with ball or roller bearings are standard. Internal and external gravity type take-ups are available.10. Hopper type intake is standard.11. Curved bottom plate.12. Shaft mount drive is standard. Other drives available on request.available. NOTE: The 200 series belt type elevator is standard with screw typehead take-ups with ball or roller bearing pillow blocks. The bootshaft is fixed and mounted in ball or roller bearing pillow blocks.Elevator Max. Speed Buckets Belt Head Pulley Boot Pulley Casing BootNumber Capacity FPM@RPM L X W X Spacing Width X Min. PIW Dia. X Width Dia. X Width Dim’s. ShaftBE141 280 225 @ 43 6 X 4 X 13 7 X 120 20 X 9 16 X 9 11 3/4 X 35 1 1/2BE142 534 225 @ 43 8 X 5 X 16 9 X 120 20 X 11 14 X 11 13 3/4 X 39 1 1/2BE143 608 258 @ 41 8 X 5 X 16 9 X 150 24 X 11 18 X 11 13 3/4 X 42 2BE144 910 225 @ 43 10 X 6 X 16 11 X 150 20 X 13 16 X 13 15 3/4 X 42 2BE145 1046 258 @ 41 10 X 6 X 16 11 X 200 24 X 13 20 X 13 15 3/4 X 48 2BE146 1464 258 @ 41 12 X 7 X 18 13 X 200 24 X 15 20 X 15 17 3/4 X 48 2 7/16BE147 1696 298 @ 38 12 X 7 X 18 13 X 200 30 X 15 24 X 15 17 3/4 X 54 2 7/16BE148 1776 258 @ 41 14 X 7 X 18 15 X 200 24 X 17 20 X 17 19 3/4 X 48 2 7/16BE149 2060 298 @ 38 14 X 7 X 18 15 X 200 30 X 17 24 X 17 19 3/4 X 54 2 7/16BE152 3040 298 @ 38 16 X 8 X 18 18 X 200 30 X 20 22 X 20 22 3/4 X 54 2 7/16pages 129 - 144 4/22/05 12:09 PM Page 132133700 & 800 SeriesChain Type700 & 800 Series Chain Type Continuous DischargeBucket Elevator DataFEATURES1. Split removable hood for accessibility.2. Head shaft mounted in fixed ball or roller bearing pillow blocks.3. Discharge spout positioned for clean discharge of product. Style 1 shown. Style 2, with horizontal flange is optional.4. Rigid, strong dust and/or weather tight casings.5. Style MF medium front buckets are standard. Other styles such as HF high front orLF low front are available.6. C-class combination chain is standard SS-class chain is available for heavy-dutyapplications and is standard on some sizes. 7. Bolted or hinged access doors are provided for installing andservicing the elevator buckets.8. Removable bolted side panels in the boot for cleanout and service.9. Screw type boot takeups with ball or roller bearings are standard. Internal and external gravity type takeups are available.10. Hopper type intake is standard.11. Curved bottom plate.12. Shaft mount drive is standard. Other drives available on request.13. Loading legs are standard on 700 series elevators and optional on 800 series elevators.NOTE: The 800 series belt type elevator is standard with screw typehead takeups with ball or roller bearing pillow blocks. The bootshaft is fixed and mounted in ball or roller bearing pillow blocks.Elevator Max. Speed Buckets Chain Head Sprocket Boot Sprocket Casing BootNumber Capacity FPM@RPM L X W X Spacing Number Tooth X PD Tooth X PD Dim’s. ShaftBE766 590 125 @ 23.4 8 X 5 X 8 C102B 16 X 20.5 11 X 14.25 11 3/4 X 39 1 1/2BE768 750 125 @ 23.4 10 X 5 X 8 C102B 16 X 20.5 11 X 14.25 13 3/4 X 39 1 1/2BE770 1010 125 @ 19.1 10 X 7 X 12 C110 13 X 25 10 X 19.5 13 3/4 X 48 2BE772 1230 125 @ 19.1 12 X 7 X 12 C110 13 X 25 10 X 19.5 15 3/4 X 48 2BE774 1420 125 @ 19.1 14 X 7 X 12 C110 13 X 25 10 X 19.5 17 3/4 X 48 2BE776 1550 125 @ 19.1 12 X 8 X 12 C110 13 X 25 9 X 17.5 15 3/4 X 48 2 7/16BE778 1830 125 @ 19.1 14 X 8 X 12 C110 13 X 25 9 X 17.5 17 3/4 X 48 2 7/16BE780 2090 125 @ 19.1 16 X 8 X 12 C132 13 X 25 9 X 17.75 19 3/4 X 48 2 7/16BE782 2340 125 @ 19.1 18 X 8 X 12 C132 13 X 25 9 X 17.75 21 3/4 X 48 2 7/16pages 129 - 144 4/20/05 8:21 AM Page 133134700 & 800 SeriesBelt Type700 & 800 Series Belt Type Continuous Discharge BucketElevator DataFEATURES1. Split removable hood for accessibility.2. Head shaft mounted in fixed ball or roller bearing pillow blocks.3. Discharge spout positioned for clean discharge of product. Style 1 shown. Style 2,with horizontal flange is optional.4. Rigid, strong dust and/or weather tight casings.5. Style MF medium front buckets are standard. Other styles such as HF high front orLF low front are available.6. Rubber and/or PVC belts are standard. Other belt materials are available to suit yourapplication.7. Bolted or hinged access doors are provided for installing and servicing the elevatorbuckets.8. Removable bolted side panels in the boot for cleanout and service.9. Screw type boot takeups with ball or roller bearings are standard. Internal and external gravity type takeups are available.10. Hopper type intake is standard.11. Curved bottom plate.12. Shaft mount drive is standard. Other drives available on request.13. Loading legs are standard on 700 series elevators and optional on 800 series elevators.NOTE: The 800 series belt type elevator is standard with screw type head takeups with ball or roller bearing pillow blocks. The boot shaft is fixed and mounted in ball or roller bearing pillow blocks.Elevator Max. Speed Buckets Belt Head Pulley Boot Pulley Casing BootNumber Capacity FPM@RPM L X W X Spacing Width X Min PIW Dia. X Width Dia. X Width Dim’s. ShaftBE766B 590 125 @ 24 8 x 5 x 8 9 x 150 20 x 11 14 x 11 13 3/4 x 39 1 1/2BE768B 750 125 @ 24 10 x 5 x 8 11 x 150 20 x 13 14 x 13 15 3/4 x 39 1 1/2BE770B 1010 125 @ 20 10 x 7 x 12 11 x 150 24 x 13 20 x 13 15 3/4 x 48 2BE772B 1230 125 @ 20 12 x 7 x 12 13 x 200 24 x 15 20 x 15 17 3/4 x 48 2BE774B 1420 125 @ 20 14 x 7 x 12 15 x 200 24 x 17 20 x 17 19 3/4 x 48 2BE776B 1550 125 @ 20 12 x 8 x 12 13 x 200 24 x 15 18 x 15 17 3/4 x 48 2 7/16BE778B 1830 125 @ 20 14 x 8 x 12 15 x 200 24 x 17 18 x 17 19 3/4 x 48 2 7/16BE780B 2090 125 @ 20 16 x 8 x 12 17 x 200 24 x 19 18 x 19 21 3/4 x 48 2 7/16BE782B 2340 125 @ 20 18 x 8 x 12 19 x 200 24 x 21 18 x 21 23 3/4 x 48 2 7/16pages 129 - 144 4/20/05 8:21 AM Page 1341351000 SeriesSuper Capacity1000 Series Super Capacity ChainType Continuous DischargeBucket Elevator DataFEATURES1. Split removable hood for accessibility.2. Head shaft mounted in fixed ball or roller bearing pillow blocks.External backstops can be mounted directly to the head shaft. 3. Discharge spout positioned for clean discharge of product.Style 1 shown. Style 2, with horizontal flange is optional. 4. Rigid, strong dust and/or weather tight casings. 5. Style SC super capacity continuous buckets are standard and are mounted between twostrands of steel roller chain. Internal angles guide chain. 7. Bolted or hinged access doors are provided for installing and servicing the elevator buckets.8. Removable bolted side panels are provided in the boot for cleanout and service. 9. Screw type boot take-ups with ball or roller bearings are standard. Internal and external gravity type take-ups are available. 10. Stub type intake with loading leg is standard. Hopper type inlets can be provided 11. Curved bottom plate.12. Shaft mount drive is standard. Other drives available to meet specific requirements.Elevator Max. Speed Buckets Chain Head Sprocket Boot Sprocket Casing BootNumber Capacity FPM@RPM L X W X Spacing Number Tooth X PD Tooth X PD Dim’s. ShaftBE1001 2400 100 @ 12.5 12 X 8 3/4 X 12 SS4850 8 X 31.4 8 X 31.4 26 x 54 2 7/16"BE1002 2800 100 @ 12.5 14 X 8 3/4 X 12 SS4850 8 X 31.4 8 X 31.4 28 x 54 2 7/16"BE1003 3200 100 @ 12.5 16 X 8 3/4 X 12 SS4850 8 X 31.4 8 X 31.4 30 x 54 2 7/16"BE1004 3600 100 @ 12.5 18 X 8 3/4 X 12 SS4850 8 X 31.4 8 X 31.4 32 x 54 2 7/16"BE1005 4000 100 @ 12.5 20 X 8 3/4 X 12 SS4850 8 X 31.4 8 X 31.4 34 x 54 2 7/16"BE1006 5600 120 @ 16 16 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 30 x 60 3"BE1007 6800 120 @ 16 20 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 34 x 60 3"BE1008 8400 120 @ 16 24 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 38 x 60 3"BE1009 10000 120 @ 16 30 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 44 x 60 3"BE1010 12400 120 @ 16 36 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 50 x 60 3"pages 129 - 144 4/20/05 8:21 AM Page 1351361100 Series Super Capacity1100 Series Super Capacity Chain Type Continuous DischargeBucket Elevator DataFEATURES1. Split removable hood for accessibility.2. Head shaft mounted in fixed ball or roller bearing pillow blocks.External backstops can be mounted directly to the head shaft. 3. Discharge spout positioned for clean discharge of product.Style 1 shown. Style 2, with horizontal flange is optional.4. Rigid, strong dust and/or weather tight casings.5. Style SC super capacity continuous buckets are standard and are mounted between twostrands of steel roller chain. Internal guide chain.7. Bolted or hinged access doors are provided for installing and servicing the elevator buckets.8. Removable bolted side panels are provided in the boot for cleanout and service9. Screw type boot take-ups with ball or roller bearings are standard. Internal and external gravitytype take-ups are available.10. Stub type intake with loading leg is standard. Hopper type inlets can be provided11. Curved bottom plate.12. Shaft mount drive is standard. Other drives available to meet specific requirements.Elevator Max. Speed Buckets Chain Head Sprocket Boot Sprocket Casing BootNumber Capacity FPM@RPM L X W X Spacing Number Tooth X PD Tooth X PD Dim’s. ShaftBE1101 5600 120 @ 16 16 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 30 x 60 3"BE1102 6800 120 @ 16 20 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 34 x 60 3"BE1103 8400 120 @ 16 24 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 38 x 60 3"BE1104 10000 120 @ 16 30 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 44 x 60 3"BE1105 12400 120 @ 16 36 X 12 5/8 X 18 SS4851 10 X 29.12 10 X 29.12 50 x 60 3"BE1106 5600 120 @ 16 16 X 12 5/8 X 18 SS4852 10 X 29.12 10 X 29.12 31 1/2 x 60 3"BE1107 6800 120 @ 16 20 X 12 5/8 X 18 SS4852 10 X 29.12 10 X 29.12 35 1/2 x 60 3"BE1108 8400 120 @ 16 24 X 12 5/8 X 18 SS4852 10 X 29.12 10 X 29.12 39 1/2 x 60 3"BE1109 10000 120 @ 16 30 X 12 5/8 X 18 SS4852 10 X 29.12 10 X 29.12 45 1/2 x 60 3"BE1110 12400 120 @ 16 36 X 12 5/8 X 18 SS4852 10 X 29.12 10 X 29.12 51 1/2 x 60 3"pages 129 - 144 4/20/05 8:21 AM Page 1361371400 Series Cement Mill1400 Series Cement Mill Chain Type Centrifugal DischargeBucket Elevator DataFEATURES1. Split removable hood for accessibility.2. Segmental rim hardened tooth head sprocket or traction wheel.3. Roller bearing pillow block mounted head shaft with fabricated shaft seals. Shaft mounted external backstop available.4. Style 1 discharge furnished as standard. Style 2 discharge furnished if specified.5. Style AC high capacity buckets mounted on single strand SS style chain furnished as standard.6. Bolted or hinged access doors are provided for installing and servicing the elevator buckets.7. Rigid, strong dust and/or weather tight self supporting casings.8. Stub inlet is standard. Hopper type intake contoured to feed product directly into thebuckets available if specified.9. Removable bolted side panels are provided in the boot section for maintenance and cleanout. 10. Internal gravity take-up is provided as standard. The boot shaft is hardened in the bearing area and is mounted in hard iron bearing blocks.11. Boot sprocket is a reversible type segmental rim traction wheel.Elevator Max. Speed Buckets Chain Head Sprocket Boot Sprocket Casing BootNumber Capacity FPM@RPM L X W X Spacing Number Tooth X PD Tooth X PD Dim’s. ShaftBE1405 2000 255 X 36 12 X 8 X 19 SS111-K2 18 X 27.41 16 X 24.4 19 3/4 X 55 1/2 2 7/16BE1408 2800 255 X 36 16 X 8 X 18 SS856-K35 14 X 26.96 13 X 25.07 23 3/4 X 55 1/2 3"BE1409 4200 255 X 36 16 X 8 X 12 SS856-K35 14 X 26.96 13 X 25.07 23 3/4 X 55 1/2 3"BE1412 4600 250 X 34 18 X 10 X 18 SS2859-K44 15 X 28.86 13 X 25.07 32 3/4 X 64 3"BE1413 6900 250 X 34 18 X 10 X 12 SS2859-K44 15 X 28.86 13 X 25.07 32 3/4 X 64 3"BE1415 6350 250 X 34 24 X 10 X 18 SS2859-K44 15 X 28.86 13 X 25.07 32 3/4 X 64 3"BE1416 9500 250 X 34 24 X 10 X 12 SS2859-K44 15 X 28.86 13 X 25.07 32 3/4 X 64 3"BE1417 8500 250 X 33 27 X 12 X 21 SS2864-K44 13 X 29.16 11 X 24.76 35 3/4 X 68 3"BE1418 12750 250 X 33 27 X 12 X 14 SS2864-K44 13 X 29.16 11 X 24.76 35 3/4 X 68 3"pages 129 - 144 4/20/05 8:21 AM Page 137138DiagramHJACCESS DOORLC6'-10"CASINGS(STDLENGTH10'-0")G4'-0"FOVERALLHEIGHTACCESS DOORDSHAFTCENTERSDISCHARGEHEIGHTEKBAACCESS DOORNTYPICAL INLET ANDDISCHARGE OPENING.139Model No. A B C D E F G H J K L M N102 9 3/4 35 36 3/4 20 1/2 27 1/4 22 70 17 1/2 48 23 1/2 29 3/4 9 3/4 10141 11 3/4 35 36 3/4 20 1/2 27 1/4 22 70 17 1/2 48 23 1/2 29 3/4 11 3/4 10104 & 105 11 3/4 39 36 3/4 20 1/2 29 24 72 19 1/2 52 25 1/2 31 3/4 11 3/4 10107 & 108 11 3/4 42 43 3/4 24 1/2 30 1/4 25 1/2 73 1/2 21 57 1/4 27 36 1/4 11 3/4 13142 13 3/4 39 36 3/4 20 1/2 29 24 72 19 1/2 52 25 1/2 31 3/4 13 3/4 10110, 111, & 143 13 3/4 42 43 3/4 24 1/2 30 1/4 25 1/2 73 1/2 21 57 1/4 27 36 1/4 13 3/4 13112, 113, & 116 13 3/4 48 48 1/4 24 1/2 33 1/4 28 1/2 76 1/2 24 64 5/8 29 41 1/4 13 3/4 15144 15 3/4 42 43 3/4 24 1/2 30 1/4 25 1/2 73 1/2 21 57 1/4 27 36 1/4 15 3/4 13117, 119, & 145 15 3/4 48 48 1/4 24 1/2 33 1/4 28 1/2 76 1/2 24 64 5/8 29 41 1/4 15 3/4 15120 & 122 15 3/4 54 54 3/4 31 1/2 35 3/4 31 1/2 79 1/2 27 72 33 46 1/4 15 3/4 17123, 124, 126, & 146 17 3/4 48 50 1/4 29 33 1/4 28 1/2 76 1/2 24 64 5/8 29 41 1/4 17 3/4 15127, 128, 130, & 147 17 3/4 54 54 3/4 31 1/2 35 3/4 31 1/2 79 1/2 27 72 33 46 1/4 17 3/4 17131, 132, & 148 19 3/4 48 50 1/4 29 33 1/4 28 1/2 76 1/2 24 64 5/8 29 41 1/4 19 3/4 15133, 134, & 149 19 3/4 54 54 3/4 31 1/2 35 3/4 31 1/2 79 1/2 27 72 33 46 1/4 19 3/4 17152 22 3/4 54 54 3/4 31 1/2 35 3/4 31 1/2 79 1/2 27 72 33 46 1/4 22 3/4 17Model No. A B C D E F G H J K L M N766 & 767 11 3/4 39 49 3/4 20 1/2 29 24 72 19 1/2 52 25 1/2 31 3/4 11 3/4 10766B, 767B, 768 & 769 13 3/4 39 49 3/4 20 1/2 29 24 72 19 1/2 52 25 1/2 31 3/4 13 3/4 10770 &771 13 3/4 48 66 3/4 27 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 13 3/4 15768B & 769B 15 3/4 39 49 3/4 20 1/2 29 24 72 19 1/2 52 25 1/2 31 3/4 15 3/4 13770B, 771B, 772, 773, 15 3/4 48 66 3/4 27 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 15 3/4 15776 & 777772B, 773B, 774, 775, 17 3/4 48 66 3/4 27 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 17 3/4 15776B, 777B, 778 &779774B, 775B, 778 & 779 19 3/4 48 66 3/4 27 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 19 3/4 15780 & 781 19 3/4 48 68 3/4 29 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 19 3/4 15782 & 783 21 3/4 48 68 3/4 29 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 21 3/4 15780B & 781B 22 3/4 48 68 3/4 29 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 22 3/4 15782B & 783B 24 3/4 48 68 3/4 29 33 1/4 28 1/2 76 1/2 24 64 5/8 30 41 1/4 24 3/4 15Bucket ElevatorDimensionsNote: All dimensions are for reference only. Certified dimensional drawings will be provided with each order.NOTE: 700B indicates a belt type elevator.BE-100 Dimension ScheduleBE-700 Dimension Schedule140SafetySafety must be considered a basic factor in machinery operation at all times. Most accidents are the result of carelessness or negligence. Thefollowing safety instructions are basic guidelines and should be considered as minimum provisions. Additional information shall be obtained by thepurchaser from other sources, including the American Society of Mechanical Engineers, Standard ANSI B20.1, Standard ANSI B15.1, StandardANSI Z244.It is the responsibility of the contractor, installer, owner and user to install, maintain and operate the bucket elevator and elevator assembliesmanufactured and supplied by Thomas, in such a manner as to comply with the Williams-Steiger Occupational Safety and Health Act and with allstate and local laws and ordinances and the American National Standards Institute Safety Code.Precautions:1. Maintain a safety training and safety equipment operation/maintenance program for all employees.2. Bucket elevators shall not be operated unless the elevator housing completely encloses the elevator moving elements and power transmis-sion guards are in place. If the elevator is to be opened for inspection, cleaning or observation, the motor driving the conveyor is to belocked out electrically in such a manner that it cannot be restarted by anyone, however remote from the area, unless the elevatorhousing has been closed and all other guards are in place.3. If the elevator must have an open housing as a condition of its use and application, the entire elevator is then to be guarded by a railing orfence.4. RUGGED gratings may be used where necessary. If the distance between the grating moving elements is less than 4 inches, the grating open-ing must not exceed 1/2 inch by 2 inches. In all cases the openings shall be restrictive to keep any part of the body or clothing from coming incontact with moving parts of the equipment. SOLID COVERS should be used at all points and must be designed and installed so that personnelwill not be exposed to accidental contact with any moving parts of the equipment.5. All rotating equipment such as guards, drives, gears, shafts and couplings must be guarded by the purchaser/owner as required by applicablelaws, standards and good practice.6. SAFETY DEVICES AND CONTROLS must be purchased and provided by the purchaser/owner as required by applicable laws, standards andgood practices.7. Practice good housekeeping at all times and maintain good lighting around all equipment.8. Keep all operating personnel advised of the location and operation of all emergency controls and devices. Clear access to these controls anddevices must be maintained.9. Frequent inspections of these controls and devices, covers, guards and equipment to ensure proper working order and correct positioning.10. Do not walk on elevator covers, gratings or guards.11. Do not poke or prod material in the elevator.12. Do not place hands, feet or any part of the body or clothing in the elevator or opening.13. Do not overload elevator or attempt to use it for other than its intended use.14. Inlet and discharge openings shall be connected to other equipment in order to completely enclose the moving elements of the elevator.15. Before power is connected to the drive a pre-start up check shall be performed to ensure the equipment and area are safe for operation and allguards are in place and secure.16. Bucket Elevators are not manufactured or designed to handle materials that are hazardous to personnel unless specially designed. Thesematerials which are hazardous include those that are explosive, flammable, toxic or otherwise dangerous to personnel. Elevators may bedesigned to handle these materials. Elevators are not manufactured or designed to comply with local, state or federal codes for unfired pres-sure vessels. If hazardous materials are to be conveyed or if the elevator is to be subjected to internal or external pressure, Thomas should beconsulted prior to any modifications.17. Removal of backstop may cause unexpected machine movement. Remove or block all external loadsbefore servicing unit. Failure to observe these precautions could result in bodily injury.All equipment shall be checked for damage immediately upon arrival. Do not attempt to install a dam-aged item or elevator.All bucket elevators are shop assembled by Thomas, have warning labels affixed in many easily seenlocations. If the equipment exterior is painted, coated or altered in any way or if the material conveyed is inexcess of 175°F or if a change in the original intended use of the equipment is considered, the factory shall beconsulted before modifications are made. Additional stickers are available upon request.CHR930001CHS930001(5” Wide x 2 1/2” High)CVS930012(3” Wide x 6” High)ProminentlyDisplayIn Work Areas14112 83/4 115/8 49/16 22 29 39 49 .35 .5414 83/4 115/8 49/16 23 31 41 51 .41 .6316 83/4 115/8 49/16 25 34 45 56 .46 .7216 12 175/8 61/2 43 58 76 95 1.11 1.55 18 83/4 115/8 49/16 27 36 48 60 .52 .8120 83/4 115/8 49/16 29 39 52 65 .58 .9020 12 175/8 61/2 49 67 88 110 1.40 1.9424 12 175/8 61/2 55 75 104 130 1.68 2.3330 12 175/8 61/2 65 88 117 146 2.11 2.9136 12 175/8 61/2 73 99 132 165 2.53 3.49NOTE: All dimensions are inside to inside of bucket.Consult Thomas for other chains.Style AADuctile iron buckets forgeneral use with most types ofrelatively free flowing materialin centrifugal dischargeelevators. Can be mounted onchain or belt and furnished insteel, ductile iron, and variousplastic materials.Style CFabricated buckets are usedin centrifugal dischargeelevators to handle materialsthat tend to pack or stick, suchas sugar, clay, salt or wetgrains.MF ContinuousMedium front non-overlappingfabricated steel buckets areused in continuous dischargeelevators for general service.Heavier gauges should beused when handling abrasivematerials. Available fabricatedfrom various materials. Highfront continuous buckets areavailable also. Plastic bucketsavailable in most sizes.AC Welded SteelHigh front for greater capacity.Hooded back for closerspacing. Typical in cement,gypsum powder or otherpowdery materials. Ventingavailable for clean filling anddischarge. Mounted on chainor belt.Bucket Size Weight CapacityLbs. cu. ft.A B C X — XBucket Size Weight CapacityLbs. cu. ft.A B C X — XCapacityBucket SizeWeightcu.Lbs.ft.A B C 12 Ga. 10 Ga. 3/16? 1/4? X — XBucket Size, Inches Weight Cap. Cu. Feet^Filled FilledL P D 3/16” 1/4” to Line to LineLength Proj. Depth Steel Steel X-X X-YBuckets4 23/4 3 1.0 .01 6 4 41/4 2.7 .03 8 5 51/2 4.8 .07 10 6 61/4 7.7 .12 12 7 71/4 12.0 .19 14 7 71/4 13.9 .23 16 8 81/2 21.8 .346 41/2 4 2.0 .026 8 41/2 4 2.8 .035 10 5 4 4.0 .052 12 5 4 4.8 .061 14 7 51/2 8.5 .138 16 7 51/2 10.5 .158 8 5 73/4 5.1 6.3 8.7 — .070 10 5 73/4 5.9 7.4 10.2 — .090 10 7 115/8 9.3 11.9 16.5 — .180 12 7 115/8 10.4 13.4 18.6 — .218 14 7 115/8 11.6 14.9 20.7 — .253 12 8 115/8 11.2 14.4 20.0 26.1 .275 14 8 115/8 12.4 16.0 22.2 29.1 .325 16 8 115/8 13.7 17.6 24.5 32.0 .375 18 8 115/8 14.9 19.2 26.7 35.0 .42012 8 81/2 18.25 24.30 .231 .303 14 8 81/2 20.30 27.00 .271 .356 16 8 81/2 22.48 29.98 .311 .408 18 10 101/2 31.15 38.95 .488 .691 20 10 101/2 33.68 42.10 .542 .768 24 10 101/2 39.67 52.69 .651 .92127 12 12 1/2 53.84 71.46 1.072 1.474D(DEPTH)L (LENGTH)50…PX XYP(PROJ.)AD(DEPTH)L (LENGTH)X XYSC Welded SteelMounted between two strandsof chain. Suitable for theheaviest materials. Designedfor super capacity elevators.Typical in asphalt andconcrete applications. Designoffers increased capacity.Bucket Size, Inches Weight Cap. Cu. Feet*10 Filled FilledL P D A Gauge 3/16” 1/4” 5/16” to Line to LineLengthProj. Depth Inches Steel Steel Steel Steel X-X X-Y*Note: Actual capacity depends on angle of repose of material handled andinclination of elevator.^Weights do not include bolt reinforcing plates. Bolt reinforcing plates are rec-ommended if less than 8 bolts are used. Vent holes in bottom are optional instyle “AC” buckets.pages 129 - 144 4/7/05 11:08 AM Page 141142Bucket Punching (Belt)CEMA Standard (Formerly P1 thru P9)B1 B2 B3 B4B5 B6 B7 B86 B-1 4-3/8 1 1/4 — — — —8 B-6 3 7/8 1/4 -5/16 B-6 3 1/4-5/1610 B-6 31/2 7/8 1/4 -5/16 B-6 31/2 1/4-5/1612 B-6 41/2 7/8 1/4 -5/16 B-6 41/2 1/4-5/1614 B-7 4 7/8 5/16 B-7 4 5/1616 B-7 41/2 7/8 5/16 B-7 41/2 5/1618 — — — — B-7 5 5/16BucketLengthM.I. & Steel BucketsStyle A, AA, AA-RB, B, C, etc.ContinuousBucketsPunch A B C Punch A B CC-188 K-2 1 11/4 43/16 23/4 3/8C-102B K-2 3/4 13/4 55/16 2 3/8C-110 K-2 7/8 13/4 55/16 33/8 3/8C-111 K-2 3/4 25/16 61/4 21/8 3/8SS-102B K-2 3/4 13/4 55/16 2 3/8SS-110 K-2 7/8 13/4 55/16 33/8 3/8Chain AttachmentNumber Number A B C D EBucket Punching — ChainStyle AA, C, SC, etc. ContinuousPlatformsHead section service plat-forms are of structural steel,angle hand rails and heavynon-skid grating. The platformmounts securely to the eleva-tor head section. Various sizesand configurations are avail-able. Rest platforms are alsoavailable and required at 30´intervals.Ladders/Safety CagesLadders with safety cages areavailable. They are construct-ed of heavy gauge steel andsized to provide easy accessto platforms. Ladders withsafety cage are easily boltedto the elevator casings.C BOLTS1? 1? 1?B=DEPTH–12BE BOLT DIApages 129 - 144 4/7/05 11:08 AM Page 142143Troubleshooting Guide – BeltProblem Cause CorrectionBucket bolts pull through belt or belt tears atbolt hole. Bucket bolts not tight.Inadequate belt construction for bolt-holding.Obstruction in casing or insufficient clearance.Jammed boot.Too-small pulleys or incorrect splice strainsbolts as belt flexes.Service conditions changed. Lump size orweight in buckets increased from originaldesign.Bucket bolts should be inspected frequentlyand kept tight.Proper belt recommendation should considerminimum plies for bolt-holding.Check terminal pulleys for proper alignment toensure straight-running belt. Redesign ele-vator if necessary.Install controlled feed to help eliminate jamsand turbulence in boot.Install larger head pulley if possible. Use cor-rect splice. Check belt construction for pos-sibility of thinner belt.For larger lumps, change feed or boot design tohandle them. For heavier material, change beltconstruction to proper construction.Belt cover wearing excessively on bucketside.Bucket not completely discharging material.Material downlegging and getting betweenbucket and belt.Fine abrasive material between bucket andbelt cover.Too light a cover gauge or improper belt quality.Change speed to effect better discharge.Use rubber washers or bucket pad betweenbucket and cover.On replacement belt, increase cover thicknessor upgrade belt, or both.Excessive wear on pulley side of cover.Abrasive material dropping between belt andboot pulley.Belt slips at drive pulley.Too light a cover gauge or improper belt quality.Use slotted or self-cleaning type of pulley.Lag head pulley. If necessary, increase ten-sionat terminal pulley.On replacement belt, increase cover thicknessor upgrade belt, or both.Belt carcass breaks.Lump material dropping between belt and bootpulley.Operating tension is higher than maximumallowable working tension of belt.Some type of slotted or self-cleaning pulleyshould be used.Calculate belt tension and install belt with cor-rect strength design.Separation of rubber cover from carcass. Severe service conditionsImprove cover adhesion by using breakerbetween carcas and cover.144Troubleshooting Guide – ChainProblem Cause CorrectionExcessive noiseMisalignment.Too little or too much slack.Improper lubrication.Loose casing or sprocketsWorn chain or sprocketsCheck alignment and correct.Adjust take-up.Lubricate properly (follow instructions in lubri-cation section.)Draw up all bolts... brace housings if necessaryReplace chain and sprocket.Wear on chain side bars and sides ofsprocket teeth.Misalignment.Obstruction in guides, ways or casing.Correct alignment of sprockets and shaftsRemove obstruction...repair or replace dam-aged guides, ways or casing.Chain climbs sprockets.Poorly fitting sprockets.Chain worn long in pitch... or worn out.Insufficient chain wrap or excessive slack.Material build-up in sprocket tooth pockets.Loose or broken buckets.Replace sprockets...and chain if necessaryReplace chain.Increase chain wrap with idler or adjust centerfor proper slack.Remove material build-up.Tighten, repair or replace buckets. Broken pins and rollers.Elevator speed too high for chain.Shock or suddenly applied loads.Inadequate lubrication.Material build-up in sprocket tooth pockets.Bucket striking casing.Use chain of shorter pitch or sprocket withmore teeth.Reduce shock loads...easy starts give long life.Lubricate properly (follow instructions inlubrication section.)Remove material build-up.Check bucket clearance with casing or tightenloose buckets. PulsationChain tension too low.Chain speed too slow. Obstruction.Heavy or tacky lubricants.Sprockets with too few number of teeth, result-ing in a large amount of chordal action. Adjust take-ups to restore proper tensionIncrease size of sprocket or increase elevator speed.Remove obstruction and be sure lower strandis not striking foreign obstruction, ways or casing.Lubricate correctly.Replace with sprockets having correct numberof teeth.Chain gets stiff joints. Misalignment.Material in chain joint. Improper lubrication.Corrosion.Peening of side bars.Excessive overloads.Check sprocket and shaft alignment, and cor-rect...replace damaged chain if necessary.Remove foreign material.Lubricate properly.Protect chain from corrosion with cases...cleanand lubricate more often.Check for interference between chains andanother member. Correct as needed.Review chain size.Broken sprocket teeth. Excessive shock loads.Objects wedged between chain and sprocket.Chain climbing sprocket teeth.Avoid shocks...easy starts give long life.Remove and protect from foreign objects...altertrough at discharge point to prevent droppingoff objects onto sprocket teeth.See ”Chain climbs sprockets”.Rapid wear on troughs, ways or casings. Abrasive material or obstruction in casing,ways or casings.Bent or damaged buckets, attachments orlinks.Insufficient casing lubrication. Remove obstructions and try to avoid accumu-lation of abrasive material.Replace or repair damaged buckets attach-ments and links. Lubricate properly where lubrication is permitted. Damage to conveyed articles.Bent or damaged buckets, attachments or links.Obstruction in ways or casings.Improper timing. Repair or replace damaged parts.Remove obstruction.Check timing sequence, chain elongation,chain selection. Chain clings to sprocketsIncorrect or badly worn sprockets.Heavy or tacky lubricants.Material build-up in driveR sprocket tooth pockets.Replace chain and sprockets.Clean and lubricate properly.Remove material build-up...protect from con-tact with foreign material, or use sprockets withmd relief, pitch line clearance. Index Material Handling Products Section I Design Table 1-1 Table 1-2 Selection of Conveyor Size and Speed Capacity Factors Capacity Table Lump Size Limitations Component Selection Bearing Selection Horsepower Requirements Horsepower Factor Tables Horsepower Torsional Ratings of Components Conveyor Screw Deflection Inclined and Screw Feeders Design and Layout Section II Enclosures Hand Conveyors Conveyor Screw Rotation Layout Bolt Patterns Bolt Requirements Pipe Sizes, Dimensions & Weights Typical Drive Arrangement Sample HP Work Sheet Components - Section III Component Selection Conveyor Screws CEMA Standards Conveyor Screws Conveyor Screws Helicoid Conveyor Screws (Sectional) Conveyor Screws (Ribbon) Conveyor Screws Conveyor Screw (Components) Shaft No. 1 Drive Shaft Shafts End Shaft Hangers Screw Conveyor Hanger Bearing Selection Application Hanger Bearings Trough Ends Shaft Seals End Bearings Thrust Bearings Conveyor Trough Standard Conveyor Trough Tubular Trough Flared Trough Saddles - Feet Trough End Flanges Discharges and Gates Discharge Spouts Discharge Gates Trough Covers Trough Accessories Feeder Shrouds Conveyor Shrouds Special Features Section IV Covers Trough Ends Trough Conveyor Screws Discharges Discharges and Inlets Installation & Maintenance Installation & Maintenance Section V Warning & Safety Reminders Bucket Elevators Section VI Elevator Types Selection Material Table 100 & 200 Series Chain Type 100 & 200 Series Belt Type 700 & 800 Series Chain Type 700 & 800 Series Belt Type 1000 Series Super Capacity 1100 Series Super Capacity 1400 Series Cement Mill Diagram Bucket Elevator Dimensions Safety Buckets Bucket Punching (Belt) Troubleshooting Guide - Belt Troubleshooting Guide - Chain Bucket Elevator Data Sheet Screw Conveyor Data Sheet Vertical Screw Data Sheet Shaftless Screw Conveyors -Section X Size and Capacity Safety Modular Plastic Screw Section IX Warning & Safety Reminder Modular Plastic Screw Conveyors - Design Data Technical & Design Data Vertical Screw Elevator Section VIII Screw Elevators Standard Screw Elevators Super Screw Elevator Warning & Safety Reminder Drag Conveyors Section VII Round Bottom Drag Conveyor Flat Bottom Drag Conveyors L-Path Drag Conveyor Safety
