Compact Telehandler 1245/ 2506

Compact2Kramer Allrad Compact telehandlers 1245 • 250612452506Power on top form.The surprising winners:Bold. Compact. Dynamic.SMART AND COMPACT. THE FORMAT FOR SUCCESS.The new compact telehandlers from Kramer open up entirely new markets even within familiar branches of industry, and they are certainly in demand. This demand is a result of the machine’s ultra-compact dimensions, making them the emerging stars of the plant hire business. They are ideal for gardening and landscaping, municipalities, construction industry and roadworks.Their dynamic all-wheel drive, powerful hydraulics, high payload, unbeatable manoeuvrability, excellent off-road capability, low operating weight and, last but not least, sheer driving pleasure are the characteristic features of this brand-new category of plant.They offer real innovation at the right time, and there is nothing more powerful than an idea introduced at the perfect time.Perfect balance:Quality with grace.ALL-ROUND STRENGTHS. FROM PERFORMANCE TO VALUE-FOR-MONEY. FROM EASY HANDLING TO USER COMFORT. FROM FUNCTION TO DESIGN. A RADICAL RETHINK THAT OPENS UP A VISTA OF NEW PERSPECTIVES. ALL UNDER-PINNED BY A SOLID STRUCTURE.54321Model linesKramer compact telehandlers open up a new dimension for High Balanced Handling. They demonstrate in a wholy new format what has already been proven many times over in our wheel loaders, tele wheel loaders and telehandlers: the legendary Kramer quality and reliability.Comfort zonesWhen developing our vehicles we always give people the priority: comfortable workstation, precise hydro static drive with inching pedal, sensitive works hydraulics, easy servicing access – and all this in conjunction with dynamics and power that are just fun to work with.Steering modesThe legendary Kramer all-wheel steering guarantees maximum manoeuvrability. The front-wheel steering of the 2506 is the perfect option for smooth road driving, and the crab steering mode can be a great help for precision work.Attachment areasMaximum use of technical possibilities from front to rear: lots of front tool attachments, various trailer couplings and additional hydraulic functions at the rear. System carrierThe new compact telehandlers are agile and dynamic system carriers for many attachments and transport tasks.4_5 KRAMER HIGH BALANCED HANDLING132The new benchmark:Productive agility. The future has arrived.6_7 KRAMER MANOEUVRABILITY12452506Finding new avenues of deployment. Working more profitably. And all this with a real spring in your step.Compact dimensions complement the agile all-wheel steering perfectly and give you a feeling of great confidence. And you feel it straight away: this is quality with an all-new feel, opening up brand-new opportunities, as well being fun, and all with nimble manoeuvrability and incredible flexibility.1 Unrestricted operation even when constrained by low headroom. The compact telehandlers are perfectly suited to the conditions of city, factory, building yard and construction site, in function, form and dimensions.2 The best tip for becoming a favourite all-rounder linking indoors and out: offering versatile utility that always has its place.3 Its narrow profile broadens its range of application possibilities enormous-ly. Now, even the tightest and narrowest sites can be tackled effectively using machine, rather than hand power.New efficiency:One size fits all. And no waiting around.124525068_9 KRAMER REACHFrom either/or to the far more profitable both/and: one dimension with massive depth of field.Nothing is out of bounds for working as both a stacker and loader. Uncompromised high-performance and practicality: professionally designed and developed using brand components manufactured to “Made in Germany” standards. High expectations and hard-to-satisfy requirements are the best reasons for deciding on a compact tele-handler from Kramer.New intelligence:Packing the essentials into one compact bundle.1245250610_11 KRAMER POWEREverything that you could possibly need: The 1245 is equipped with a secure canopy-cockpit, a driver’s seat with durable synthetic leather upholstery and working lights front and back. A comfort cab with all-round glazing is available as an opti-on. This makes the little 1245 ready to take on any task. One complete package: just like every Kramer.The hydraulic quick-hitch system saves time, enhances security and improves workflow. It is perfectly suited to the compact telehandler and offers the ideal conditions for handling its outstanding versatility.High-power drive: the hydrostatic all-wheel drive with inching pedal, high ground clearance and off-road capability generate maximum power when and where it’s needed.Power with a light touch. Low charge weight, high-visibility compact format, joystick console and a comfort cab with lighting, sun shade and 360° panoramic view.Hydraulics with power in reserve: capable of lifting 2500 kg to a height of almost 6 m. Precise and sensitive steering via the joystick, and more than capable of meeting all the demands of the compact class.1 2 3A choice of steering modes to suit all operating situations:1 All-wheel steering: constant 100 % manoeuvrability, security and power whatever the turning radius.2 Front-wheel steering: ideal for smooth and safe road driving (optional on the 2506).3 Crab steering: ideal for precise stacking when space is tight (optional on the 2506).New composure:Progress and quality inevery detail.1245250612_13 KRAMER POWERThe compact telehandlers from Kramer are no small fry: they’re big performers from the leading compact machinery specialist. It’s the experience and professionalism of Kramer that make all the diffe-rence. The robust and torsion-resistant frame, the key components from the world’s leading manufacturers and the latest generation engines transform them into something extraordinary, from the 2506 model to the slimline 1245. The electronically regulated hydrostatic drive of the 2506 ensures exceptio-nal driving performance and optimal efficiency. For additional traction, 100 % differential lock is available as an option.123The hydraulic quick-hitch system: The snap-together link offering comfort, safety and optimal utility. 1 Simply drive up to the implement. 2 Through visual contact, connect and secure the tool with ease. 3 Lock and unlock the tool attachment without having to leave the driver’s seat. That’s all there is to it. This is how to make the most of the versatility of the compact telehandler – with everything to gain. And no time to lose.A tried-and-tested principle and the backbone of Kramer’s long-term success: the one-piece chassis for perfect stability, a consistently high payload with no ifs and buts and an optimal power to weight ratio.Power and quality that go a long way. The hydraulic boom is a small masterpiece in itself: from the high-grade steel through the tried-and-tested, well-protected hose guide to the perfect kinematics. Another feature to inspire your full confidence.New supremacy:Everything at a glance. Everything within reach. Everything well in hand.1245250614_15 KRAMER COMFORTThe care lavished on the technical details makes the machine. The enthusiasm for working with it produces the results. The compact telehandlers from Kramer are as strong as they are agile. They are also built with the person using them in mind, so that he or she can work with them efficiently and master every possible situation. The perfect all-round visibility, the ergonomic layout of the controls and the easy access to the maintenance points underline the practically-orientated design. 1 Unimpeded visibility of the tool attachment and working area facilitates concentration on the essentials and helps ensure safe working.2 Supreme cab comfort. Options with which to spoil yourself on the 2506: air conditioning, radio, adju-stable steering column, air-sprung seat and heated cab windows.3 The innovative joystick with illu-minated switches is a high point of user-friendliness. It allows the boom raise/lower functions along with the tilting/dumping and drive direction selection functions to be controlled with just one hand.The roomy comfort cab of the 2506 is pure ergonomic design: generous yet compact dimensions, individual adaptability, comfort layout and supreme functionality. A true cockpit, made-to-measure for every working day.34 The engine hatch of the 1245 is removable. This offers superb access to the key components for all maintenance work.5 The engine hatch of the 2506 is self-releasing and opens wide by means of pneumatic struts – a small but useful help to the everyday working routine.4 521New value for money:Quite simply, the perfect format for lasting cost-effectiveness.1245250616_17 KRAMER VALUE FOR MONEYForever with an eye on the future and following the latest trends, to make the most of the deployment possibilities: Versatility, manoeuvrability, durability, high availability and attractive resale value, as only a top brand machine is capable of. This all adds up to Kramer being the right choice.The compact telehandlers from Kramer are robustly built and have an ideal power to weight ratio. They are low on fuel consumption, low on maintenance and servicing and economical to transport.A good-value decision all round.The rear of the compact telehandler is a power centre for so many areas of use: tow coupling, tipper connection and hydraulic auxiliary control circuit are just some of the many possibilities for making the most of the machine’s power sources.Output kW Torque Nm Fuel consumption g/kWhPfullendorfMUNICH5 model ranges:Perfect formation.Ideal balance of payload, performance and bucket capacity.ALL KRAMER LOADERS COME OFF THE PRODUCTION LINE OF A LEADING COMPACT MACHINERY MANUFACTURER BASED IN THE HEART OF EURO-PE. THEY BEAR THE HALLMARK OF QUALITY, STABILITY AND CONSISTEN-CY THAT YOU CAN RELY ON: TYPICALLY “MADE IN GERMANY”. EVERY MODEL IS BUILT TO LAST AND IS A MODULAR ELEMENT OF AN OVERALL SYSTEM. ONE PART FITS INTO ANOTHER, AND EVERYTHING IS FUTURE-PROOFED, FOR LONG-TERM COST-EFFECTIVENESS.Max. engine outputBucket capacityMax. payloadCharge weight *Turning radius (tyres)Max. speedMax. load-over height MINI-LOADERS350 Canopy 27 kW / 37 hp 0.35 – 0.55 m3 970 kg 1665 kg 1950 mm 0 – 20 kph 2680 mm350 CAB 27 kW / 37 hp 0.35 – 0.55 m3 970 kg 1740 kg 1950 mm 0 – 20 kph 2680 mm180 23 kW / 31 hp 0.3 – 0.4 m3 950 kg 1860 kg 1940 mm 0 – 20 kph 2458 mm280 28 kW / 40 hp 0.65 – 1.1 m3 1900 kg 3300 kg 2430 mm 0 – 20 kph 2820 mmWHEEL LOADERS750 45 kW / 61 hp 0.75 – 1.15 m3 2300 kg 4200 kg 2550 mm 0 – 30 kph 2915 mm850 45 kW / 61 hp 0.85 – 1.3 m3 2350 kg 4500 kg 2550 mm 0 – 30 kph 3100 mm950 58 kW / 79 hp 0.95 – 1.6 m3 2500 kg 4700 kg 2780 mm 0 – 30 kph 3120 mm1150 58 kW / 79 hp 1.15 – 1.8 m3 3500 kg 5900 kg 2850 mm 0 – 30 kph 3235 mm380 45 kW / 61 hp 0.75 – 1.15 m3 2400 kg 4300 kg 2900 mm 0 – 40 kph 2915 mm480 58 kW / 79 hp 0.85 – 1.3 m3 2600 kg 4750 kg 2900 mm 0 – 40 kph 3100 mm580 58 kW / 79 hp 0.95 – 1.5 m3 2750 kg 4900 kg 2900 mm 0 – 40 kph 3050 mm680 58 kW / 79 hp 1.05 – 1.6 m3 3100 kg 5650 kg 2950 mm 0 – 40 kph 3050 mm780 58 kW / 79 hp 1.15 – 1.8 m3 3500 kg 6100 kg 2950 mm 0 – 35 kph 3200 mm880 88 kW / 120 hp 1.5 – 2.5 m3 4500 kg 8400 kg 3450 mm 0 – 35 kph 3530 mmTELE WHEEL LOADERS750T 45 kW / 61 hp 0.75 – 1.15 m3 2000 kg 5100 kg 2550 mm 0 – 30 kph 4510 mm680T 58 kW / 79 hp 0.95 – 1.5 m3 2600 kg 5950 kg 2950 mm 0 – 40 kph 4450 mmCOMPACT TELEHANDLERS1245 23 kW / 31 hp 0.4 – 1.03 m³ 1200 kg 2530 kg 2607 mm 0 – 20 kph 4130 mm2506 50 kW / 68 hp 0.85 – 1.8 m3 2500 kg 4500 kg 3670 mm 0 – 30 kph 5600 mmTELEHANDLERS3307 88 kW / 120 hp 1.2 – 2.5 m3 3300 kg 7200 kg 3600 mm 0 – 40 kph 7050 mm4507 88 kW / 120 hp 1.2 – 3.0 m3 4400 kg 8100 kg 3600 mm 0 – 40 kph 7050 mm4009 88 kW / 120 hp 1.2 – 3.0 m3 4000 kg 8600 kg 3850 mm 0 – 40 kph 8825 mm* Vehicle weight of basic model with standard bucketFind a dealer at: www.kramer.de/Haendler24_25 KRAMER MILESTONESGenuine competence only becomes established when know-how, ability and customer-orientati-on have been consolidated over many years to become a distinctive style. The success story of Kramer is telling proof of this adage:- Over 50 years of experience in the development, design and production of intelligent, durable and versatile construction machinery. Structures that have grown organically.- Innovation bringing progress to life. Kramer constantly strives to make things work better. This is how the brand has become the acknowledged pioneer and market leader that it is today.- Consistent customer orientation, personal con-tacts, the flexibility and short decision pathways of a medium-sized enterprise, along with the security of guaranteed and rapid spare parts procurement with no red tape.- A broad one-stop product and service spectrum: “Made in Germany”, in the Bodensee region. Deve-lopment, production, purchasing and sales all on one site.- The most up-to-date manufacturing facilities with in-house paint shop and an experienced work-force, who personally invest a great deal of value in the quality of “their machines”.- Robust, long-standing trading partners and well-trained contacts who represent Kramer out of conviction and for whom one thing counts above all else: loyal and contented customers.1925 Founding of the company as a manufacturer of motor mowers.1963 Kramer is the first manufacturer to present a hydraulic quick-hitch mechanism.1965 The innovative load stabiliser for the boom arm is developed by Kramer engineers.1987 The first all-wheel-steering wheel loader is launched on the market. The steering system continues to be found in all Kramer vehicles.1992 In order to satisfy customer requirements, Kramer develops a wheel loader with telescopic boom. The extra pallet height and reach give customers what they were looking for.2000 The Neuson and Kramer companies merge to become Neuson Kramer Baumaschinen AG, a company specialising in the development and manuf-acturing of compact machinery.2003 Kramer presents the first wheel loader series with stepless high-speed drive (“Ecospeed”) and highway-certified trailer coupling.2005 A new vehicle segment – the telehandler – is developed and unveiled. Through cooperation with the agricultural machinery manufacturer, Claas, telehandlers are successfully marketed to the agricultural sector.2007 A new company is born: Neuson Kramer Baumaschinen AG and Wacker Construction Equipment AG come together to form Wacker Neuson SE, a comprehensive provider of Light and Compact Equipment.2008 Due to increasing demand and the expansion of the product range, Kramer builds a new factory from scratch in Pfullendorf. This is one of the most up-to-date manufacturing sites in Europe.Innovation born of tradition:Robust program.State-of-the-art manufacturing.Competent partners.Packaging genius:Technology, power and competence. DIMENSIONS 1245 2506A Length incl. quick hitch 2916 mm 4230 mmB Length with standard bucket 3879 mm 4958 mm*C Max. width 1560 mm 1960 mmD Track width 1296 mm 1660 mmE Height to cab roof 1940 mm 1980 mmF Inside cab width 662 mm 825 mmG Wheelbase 1920 mm 2650 mmH Ground clearance 290 mm 302 mmI Centre of rear axle to end of vehicle 391 mm 620 mmK Rear approach angle 80° 80°L Crowd angle pallet forks down 8° 21° / 21°M Crowd angle standard bucket down 44° 45° / 45°N Dump-out angle pallet forks up 66° 45° / 63°O Dump-out angle standard forks up 31° 22° / 40°P Load-over height 4130 mm 5600 mmQ Dump height 3600 mm 5280 mmR Dump reach 543 mm 680 mmS Max. lift height 4300 mm 5730 mm* With teethDCFE1245250657305000 53004500209931568000 kg1300 kg1800 kg2500 kg2000 kg2630184015701260500,514801195101540003000200010000°–2,5°10°20°30°40°50° 60° 66°4300229016601380112066013501040 960 40440 kg 740 kg920 kg1100 kg1200 kg0°10°20°30°40°50° 60° 69°2506 With standard bucket and standard tyres (front view)1245 Load diagram (with load centre 500 mm)2506 Load diagram (with load centre 500 mm)2506 With standard bucket and standard tyres2506 With pallet fork and standard tyresQKEOMHG IBARPNSLOPERATIONAL DATA 1245 2506Bucket capacity 0.4 – 1.03 m3 0.85 – 1.8 m3Weight without tool attachment 2530 kg 4500 kgTurning radius tyres 2607 mm 3670 mmTurning radius pallet forks 3505 mm 4500 mmTotal swing angle of tool carrier 148° 132°/150° (optional)ENGINEMake / Type / Model Yanmar 3TNV82A-BDWM water-cooledDeutz TD 2009 L04 water-cooledOutput 22 kW / 30 hp @ 3000 rpm 50 kW / 68 hp @ 2800 rpmMax. torque 83 Nm @ 1400 rpm 200 Nm @ 1800 rpmEngine displacement 1331 cm3 2290 cm3Emissions Tested and certified as per 97/68 EC, emissions standard level 3POWER TRANSMISSIONDrive Hydrostatic HydrostaticDrive speed 0 – 7 km/h, 0 – 20 km/h 0 – 7 km/h, 0 – 20 km/h 0 – 30 km/h (optional)Axles Planetary axles Planetary axlesTotal oscillation angle 14° 20°Differential lock 100 % in the front axle (optional) 100 % in the front axle (optional)Service brake / Parking brake Front axle disc brake Front axle disc brake Standard tyres 10.0/75-15.3 AS 12.5-18 MPT04STEERING AND WORK HYDRAULICSMode of operation Hydrostatic all-wheel steering with final position synchronisationMax. steering angle 2 x 38° 2 x 38°Work pump Gear wheel Gear wheelFlow rate 42 l/min 75 l/min (optional)89 l/minPressure 240 bar 235 barKINEMATICSMax. payload 1200 kg 2500 kgMax. lift height 4300 mm 5730 mmBack angle (bucket) 43° 45° / 45°Dump angle (bucket) 31° 22° / 40° (optional)Payload at max. lift height 1200 kg 1800 kgPayload at max. span 440 kg 800 kgLift height at maximum load 4300 mm 4500 mmSpan at maximum load 1040 mm 1260 mmMax. span (pallets) 2290 mm 3156 mmScraping depth 112 mm 150 mm*CAPACITIESFuel tank 25 l 100 lHydraulic fluid tank 40 l 75 lHydraulic system 45 l 130 lRaising lift ram 6.2 sec 6.0 secLowering lift ram 5.1 sec 4.0 secExtending extension ram 5.1 sec 5.6 secRetracting extension ram 3.9 sec 3.8 secTilt 2.6 sec 3.0 secDump 2.4 sec 2.5 secNOISE EMISSIONS as per 2000/14/EG ELECTRIC SYSTEMOperating voltage 12 V 12 VBattery 77 Ah 74 AhAlternator 55 A 80 AStarter 1.7 kW 2 kW* Standard tyres124512451245250625062506We reserve the right to make modifications without notice. No responsibility is taken for the accuracy of this information. The provisions of the contractual agreement shall be considered definitive.STANDARD EQUIPMENT 1245 • 2506CAB Excellent all around visibility from a spacious and comfortable work environment for increased safe-ty and efficiency. Optimised visibility at maximum dump height. All-round view when in transport position, thanks to the laterally placed engine. Extremely roomy cab. Cockpit canopy with large, curved side windows. Soundproofed, vibration-insulated comfort cab with panoramic front windscreen.Instrument panel: Neatly designed instrument panel withcontrol lights and ergonomically arranged controls. Overload warning mechanism in field of view of driver.Joystick console: Ergonomic layout of driver‘s control console with - Joystick for raising/lowering and tilting in/tilting out the boom with switch for selecting the drive direction- Extending/retracting telescopic boom arm with joystick Actuation of 3rd control circuit on joystickDriver‘s seat: Mechanically-sprung comfort seat with seat belt, weight adjustment, backrest adjustment and horizontal adjustment. Synthetic leather Fabric cover Sun shadeRear-view mirrors: Large outside mirrors, foldable tonotched positions on either side.12 V electric socketLIGHTSFront and rear working lights Headlights Indicators Brake lights Cab lightsENGINE HATCH Entirely removable. Self-releasing, wide-opening by means of pneumatic spring for optimal maintenance access.QUICK-HITCH FACILITY MechanicalENGINE AIR INTAKEVia air filter with integrated safety cartridge.OPTIONS 1245 • 2506CAB Front windscreen with wiper, rear windscreen, fully glazed cab with heating, ventilation and front wiper, highway-certified lighting. Air-sprung driver‘s comfort seat, radio set, additional working lights front and rear, air-conditioning, adjusta-ble steering column, right and rear heated cab windows.PERFORMANCE Hydraulic quick-hitch plateElectric socket for front and rear tool attachmentsUnpressurised front refluxLow-speed control and manual throttleVarious quick-hitch systemsFront and/or rear hydraulic control circuitTipper connection100 % differential lock on front axle Hydraulic 3-point connector at rear (Cat. 1) Hydraulic PTO 540 rpm Hydraulic trailer brake valve Fully automatic central lubrication unit Front-wheel-steering and crab steering Load stabiliser High-speed drive 30 kph Proportional actuation of 3rd control circuit and telescopic boom Performance kinematics with 150° swing anglePREHEATINGEngine oilHydraulic fluidTYRES Construction machinery tyres 10-16.5 Tractor tyres 31x15.5-15 Construction machinery tyres 14.5-20 Industry tyres 335/80-18 Tractor tyres 12.5-18, 12.5-20, 405/70-20SAFETY & SECURITYRotary beacon Protective grille for front windscreen Acoustic reversing warning system Battery master switch Engine immobiliser Puncture kit Tilt ram lock1245124512452506250625062506250625062506Kramer-Werke GmbHWacker Neuson Straße 1D-88630 PfullendorfTel. 00 800 90 20 90 20Fax +49(0)7552 92 88-234info@kramer.dewww.kramer.deKramer-Werke GmbH is a subsidiary of Wacker Neuson SE, Munich. 10/2010 art.nr.1000245141You won’t find the original just anywhere.www.kramer.de/Haendler
