Hiniker - 5600 Series - Flail Windrowers Brochure

5600 SERIES FLAIL WINDROWER 15-, 20- & 30-FT MODELSHINIKER COMPANY58766 240 St. • P.O. Box 3407Mankato, MN 56002-3407Phone (507) 625-6621FAX (507) 625-5883www.hiniker.comWE RESERVE THE RIGHT TO AMEND THESE SPECIFICATIONS AT ANY TIME WITHOUT NOTICE. THE ONLY WARRANTY APPLICABLE IS OURSTANDARD WRITTEN WARRANTY. WE MAKE NO OTHER WARRANTY, EXPRESSED OR IMPLIED.1/14SPECIFICATIONS5610L WINDROWER*5620HH WINDROWER5620HLI WINDROWER5630HL WINDROWERWorking Width 15 ft. 20 ft. 20 ft. 30 ft.Overall Width 197" 257" 257" 380"Knives (72) 1/4" x 3"High-Vacuum Cup(96) 1/4" x 3"Hard-FacedHigh-Vacuum Cup(96) 1/4" x 3"Hard-FacedHigh-Vacuum Cup(144) 1/4" x 3"Hard-FacedHigh-Vacuum CupRotor Drive Belts (4) “C” Premium (6) “C” Premium (6) “C” Premium (2) 4-Groove BandedRotor Bearings 2" Bore Piloted 2" Bore Piloted 2" Bore Piloted 23/16" & 27/16" PilotedCross Auger 17" O.D. x 20" Pitch 17" O.D. x 20" Pitch 17" O.D. x 20" Pitch (2) 17" O.D. x 20" Pitch (Center Delivery)Wheels (Field Operation) Four 15 x 8KB Six 15 x 8KB Four 15 x 8KB Four 15 x 10Recommended Tire Size 9.5L x 15 8-Ply Rib 9.5L x 15 8-Ply Rib 9.5L x 15 8-Ply Rib 11L x 15-12PR(Included in Base)Hitch Type Pull-TypePull-Type Hydraulic End Transport Patent PendingPull-TypePull-Type or2-Point Semi MountPTOCategory 5 PlusConstant Velocity13/8" or 13/4" w/Overrunning ClutchCategory 5 PlusConstant Velocity13/8" or 13/4" w/Overrunning ClutchCategory 5 PlusConstant Velocity13/8" or 13/4" w/Overrunning ClutchCategory 5 PlusConstant Velocity13/8" or 13/4" w/Overrunning ClutchGearbox 235 HP Rated (USA Made)235 HP Rated (USA Made)235 HP Rated (USA Made)235 HP Rated (USA Made)Belt Idler Spring-Loaded Backwrap Spring-Loaded Backwrap Spring-Loaded BackwrapSpring-Loaded BackwrapApproximate Weight (with Tires) 4,390 lbs. 7,700 lbs. 6,210 lbs. 10,490 lbs.Hydraulic Cylinders and Hoses (Field Operation) One 3 x 8(optional)7 (Including End Transport)Two 2½ x 8(optional)Four CylinderPhased SystemSafety Lighting (optional) Standard (optional) StandardEnd Transport NA Standard (optional) StandardA More Efficient Way To Harvest Stalks*Model 5620HH is not recommended for use with tractor equipped with dual wheels. Hydraulic End TransportThe new hydraulic end transport feature helps custom operators improve efficiency and ultimately increase profits5620HLI5610LCut Field Time with a Hiniker 5600 Series Flail WindrowerAcre-eating 30-ft width20-FT15-FT5630HL30-FT 235 hp rated Superior™ gearboxes provide long-life trouble-free performance.High-vacuum 3-inch cup knives ensure clean, thorough shredding. Rotors are factory spin balanced for smooth operation. 20 and 30-ft models are standard with hard surfaced knives.Constant-velocity P.T.O shafts are standard equipment to reduce driveline vibration and knocking when turning. An overrunning clutch is also included, providing protection for both tractor and shredder.Proven Cross-Auger Delivery SystemAll rotor and drive shaft bearings are 2-inch diameter self-aligning (23/16" & 27/16" on 30' sizes). Bearings are triple lip sealed and shielded. Rotor bearings are precision piloted for long term stability and life.FEATURESThe Hiniker high-volume 17" diameter cross-auger system provides positive material flow for consistently well-formed windrows. Material is placed—rather than thrown—into the windrow, resulting in neat, easily baled windrows with less opportunity for bunching. 5610L Shown Shown with access covers open.• Shred and windrow in one pass• Big windrows save time at harvestA Hiniker 5600 Series Flail Windrower can substantially cut your field time by shredding and windrowing stalks in one pass. Both the 5610L 15-ft flail shredder and the 5620HLI & 5620HH 20-ft flail shredder use a full width end-delivery cross auger to build neat, uniform windrows ready for baling or stacking. 5620HHOptional Gauge WheelTransport Position Field PositionAvailable 2-Point HitchNEW Model 5620HH Shredder/Windrower with Hydraulic End TransportHiniker’s new 5620HH Shredder/Windrower features a specially designed, fully hydraulic end transport. The patent pending feature provides the ability to quickly go from field operations to transport mode, allowing custom operators and high production farmers to improve efficiency and increase profits.The new model 5620HH offers greatly enhanced productivity for users that require frequent moving of machines on public roadways. Conversion from field ready to road transport (less than 12-foot transport width) position can be done hydraulically, in just a few minutes, without ever leaving the tractor seat20-FTSave Harvesting Time with the Hiniker 5600 SeriesEquipped with a unique augering system the 5600 Series Windrowers give you the potential to reduce harvesting trips across the field by 50%. The 5610L gives you a choice of 6 or 12-row windrowers and a 15-ft cutting width while the 5620HLI & 5620HH offer a choice between 8 or 16-row windrows and a 20-ft cutting width. To achieve maximum windrow size, the operator simply doubles back and lays a second windrow adjacent to the first one. Heavy duty hard faced knives are standard equipment on the 20' models.5620HLI with optional end transport package shown.The Model 5630HL covers twelve, 30-inch rows and adds a new dimension to cornstalk residue windrowing. This model provides 30 feet of cutting width and features center windrow delivery. Twin augers produce a nicely-formed, baler-friendly windrow. Heavy duty hard faced knives are standard equipment.Available in pull-type or 2-point semi-mounted configurations. This model comes standard with hydraulic end transport.30-ft center delivery model covers large acreages quickly.• Fully hydraulic “from tractor seat” end transport system.• 96 Hard-faced cup knives.• 17" High capacity cross auger delivery.• Narrow transport width.• Enhanced drive and bearing components for longer machine life.• Off center pull point results in enhanced visibility for more precise windrow placement.• Optional adjustable front frame gauge wheel assembly. Must be used when machine is operated in fields with pivot irrigation system wheel tracks.
