Modular Timber Frame Wall & Windows Brochure

BUILDHOMESBuildEco Homes Penallta Industrial EstateYstrad Mynach Hengoed CF82 7QZTel: 08448 000811 01443863728www.buildecohomes.co.ukBUILDHOMESU ValuesAir LeakageAir leakage rates of less than 1 ACH @ 50 Pa have been proven to be possible using the system.Low Cost, Fast FixLow Energy Modular Timber FrameWall & Window SystemThe U Value of triple glazed windows and doors will be no greater than 1.2The following table provides typical wall U Values achievable using the system.EXTERNAL SKIN OF BUILDINGEXTERNAL TIMBER CLADDINGEXTERNAL TIMBER CLADDINGEXTERNAL TIMBER CLADDINGEXTERNAL TIMBER CLADDINGEXTERNAL TIMBER CLADDING102mm BRICK OR RENDERED100mm DENSE CONCRETE BLOCK102mm BRICK OR RENDERED100mm DENSE CONCRETE BLOCK102mm BRICK OR RENDERED100mm DENSE CONCRETE BLOCK102mm BRICK OR RENDERED100mm DENSE CONCRETE BLOCK102mm BRICK OR RENDERED100mm DENSE CONCRETE BLOCKSTANDARD BUILDECO HOMESWALL PANELS WITH... NO ADDITIONAL INSULATION... ADDITIONAL INTERNALLY FIXED30mm MINERAL WOOL INSULATION... ADDITIONAL INTERNALLY FIXED70mm MINERAL WOOL INSULATION... ADDITIONAL INTERNALLY FIXED35mm PHENOLIC FOAM INSULATION... ADDITIONAL INTERNALLY FIXED70mm PHENOLIC FOAM INSULATION... NO ADDITIONAL INSULATION... ADDITIONAL INTERNALLY FIXED30mm MINERAL WOOL INSULATION... ADDITIONAL INTERNALLY FIXED70mm MINERAL WOOL INSULATION... ADDITIONAL INTERNALLY FIXED35mm PHENOLIC FOAM INSULATION... ADDITIONAL INTERNALLY FIXED70mm PHENOLIC FOAM INSULATION0.250.240.200.220.180.250.230.200.210.18BRE AVERAGE “U”VALUE ESTIMATE* A separate leaflet is available on request for our Foundation System.Contact DetailsTe l : 0 7 8 7 2 8 2 4 2 9 5Email: vahid@buildecohomes.co.ukAll enquiries:D r. V a h i d Ta b a t a b a i B S c ( H o n s ) , M E n g , P h D .M a n a g i n g D i r e c t o rA5 Wall Windows Print.indd 1 6/11/08 13:34:19In the main we do this by providing our customers with two separate,but complementary, Modern Methods of Construction (MMC)This leaflet gives a brief overview of our wall and window system.“We are a small UK based company dedicated to helping our customers attain the very best value low energy homes they desire” Who are we?D r. V a h i d Ta b a t a b a iB S c ( H o n s ) , M E n g , P h D .M a n a g i n g D i r e c t o rLow Cost, Fast Fix, Low EnergyModular Wall & Window SytemBasic descriptionThe system comprises a selection of over 80 standard,easily handled, prefabricated, fully insulated,closed panel timber frame external wall modules. Our Low Cost, Fast Fix,Low Energy Modular Wall and Window System.Our Low Cost, Fast Fix,Super Insulated Modular Foundation System.The system also includes 6standard prefabricated internaltimber stud partition modules.This unique and Modern Method of Construction (MMC) providesalmost infinite design possibilities and allows new build homesand extensions to be made wind and watertight within days ata cost that can be 10-20% less than traditional construction costs.Many of the modules incorporatefactory fitted triple glazed timberwindows and doors of various designs.Typical Site ProcessDAY 1DAY 1DAY 1 DAY 2DAY 2DAY 2DAY 3DAY 3BUILDHOMESA5 Wall Windows Print.indd 2 6/11/08 13:34:27The Installation Process cont:8. Head binders are used to help tie all the internal and external wall modules together.9. In single storey properties the roof trusses are installed directly onto the head binders. On two or three storey properties floor joistsand boarding are fixed on top of the head binders. Upper wall modules are fixed on soleplates located on top of the floor and fixedto each other in a similar way to the ground floor.10. When the wall, floors and roof trusses are in place the superstructure is wrapped in breather membrane creating a completelywind and watertight structure ready for follow on trades to complete their works.11. This picture shows our timber frame being externally clad with horizontal timber cladding and brickwork.The Modules are used to create the external walls of a buildingThe components are manufactured in heights of 2400mm or 2700mm, widths of 300mm, 600mm and 1200mm1. Timber Stud Frame of Spruce 45x145mm,quality; SS 23 01 20 (Swedish standard)Construction quality; C142. Masonite Wood Fibre Board 9.2mm, meetingthe requirements of DIN 68 754 and ISO 14 001and registered according to EMAS3. Isofol Building Film 0.2mm approved according toSITAC 2698/904. Isover Insulation G-33-A1, 145mm in compliancewith EU directive 89/106/ECC, Lambda 0.355. Visa Spruce 850 Plywood 9.5mm approvedaccording to JAS (Japanese Agriculture Standard)6. Triple Glazed Timber Windows P marked,certificate 35 35 01Unpainted or Painted in Akzo Nobel;US A NCS S-0502 Y (Akzo Nobel is certified according toISO 9001 and ISO 14001.External Wall ModulesBasic Specification Details1234658 910 1124-CO24-6-5x1024-6-5x15 24-6-5x15WB 24-12-11x7 24-12-11x7WB 24-12-11x1324-12-11x13WB 24-12-11x15 24-12-11x15WB 24-12-10x2124-6-5x10SWB 24-6-5x13 24-6-5x13S 24-6-5x13WB 24-6-5x13SWB24-CI-3 24-PLAIN-3 24-PLAIN-6 24-PLAIN-12 600 1200300300159.5Standard External Wall Modules 2400 or 2700 HighA5 Wall Windows Print.indd 3 6/11/08 13:34:29The Installation Process142356 71. The external and internal wall module soleplates are fixed to the top of the foundation system.2. The external wall module soleplate guide rail is fixed in place.3. The first external wall corner module is fixed to the top of the soleplate and temporarily supported.4. Each external wall module is then individually fixed in position and secured to each adjacent using the unique fast fix installation method.5. Note the insulation positioned between each module and the way the integral vapour barriers are sealed and lapped.6. The external wall modules may require temporary support until the superstructure is completed.7. The internal wall modules are now installed. Please note exact opening sizes and positions can be created using loose timber supplied.24-12-10x21-13L24-12-10x21-15L 24-12-10x21-15R 24-12-10x21-15LWB 24-12-10x21-15RWB 24-12-10x21-13/8L24-12-10x21-15/6R 24-12-10x21-21L 24-12-10x21D 16x21 PATIO DOOR24-12-10x21-13R 24-12-10x21-13LWB 24-12-10x21-13RWBStandard External Wall Modules 2400 or 2700 HighA5 Wall Windows Print.indd 4 6/11/08 13:34:38
