Raco - Fella Twin Rotor Rakes - Brochure

fella.eu• Robust construction• Innovative• Ease of operationTwo-rotor and four-rotor rakesRAKESMADE IN GERMANY2 3FELLA – the forage harvesting specialist:BEST HARVEST TRADITION, INNOVATION, PASSION For more than 90 years, FELLA has always meant innovative technology, outstanding quality and personal passion in the service of agriculture. As the specialist for “Made in Germany” forage harvesting technology, we o? er our customers all around the world an extremely wide range of products in terms of mowers, conditioners, hay-making machines and swathers. FELLA has been represented in all important markets around the world since the 1980s. Through close contact with farmers and agricultural contractors, our machines are constantly undergoing further development towards perfection. In this way, even the most diverse markets can enjoy mutual benefi ts. FELLA’s objective is to provide every customer with the optimum solutions for their farm and their requirements.• “Made in Germany” quality • More than 90 years of experience in the field of agricultural engineering• In-house research and development department• All machines are assembled and tested on the company's site by specialists• Innovative, efficient, long-lastingThe fi rst rake was produced on our company site in Feucht as early as the mid 60s. All key components of our forage harvesting machines are assembled and tested in Feucht by specialists before they leave our works.At the same time, our research and development department continues to invest all its expertise into the development of ever better and more effi cient machines. This will guarantee the outstanding FELLA “Made in Germany” quality far into the future for all our customers the world over.4 5RAKE HEADS The rake heads from FELLA win users over due to their enclosed construction, which can be relied on to protect all important components from dirt and dust. This design is a guarantee for a long service life. The optimised shape of the cam track, which is made of unbreakable spheroidal graphite cast iron, pro-vides maximum smooth running and quick, precise lifting of the tines. The large-dimensioned drive unit and the precision-manufactured tine arm housings made of aluminium alloy both re? ect the modern and practice-proven design.TANGENTIALLY ARRANGED ROTOR ARMSBest raking quality is achieved with the tangential arrangement of the tine arms and an ideal swath is created. It makes signifi cantly higher working speeds possible – the best prerequisites if the harvesting weather is not in your favour.WHY A TWO-ROTOR OR FOUR-ROTOR RAKE FROM FELLA? These days, large rakes are key machines in the forage harvesting chain – a failure can result in the stop-page of expensive machines following on behind and enormous costs. You should therefore entertain no compromises with your new rake and be determined to put your trust in quality and operational reliability. FELLA has combined its years of experience with the latest technical knowledge and, from these, developed a range of high-performance large-scale rakes. Characteristics which all the machines share are the robust construction, ease of operation and outstanding raking quality – all things from which you, as the user, can immediately benefi t thanks to their practicality. The individual models also win users over with interesting detailed solutions – take a look for yourselfTWO-ROTOR AND FOUR-ROTOR RAKESAt a glance:• Decades of experience• Large product range• Robust construction – ease of handlingOpinions based on actual use: “We acquired the FELLA multi-rotor rakes because of their robust construction, high performance and ease of opera-tion. The journeys to the sites of operation are quick and safe and our drivers do not now want to go without the ingenious SteerGuard steering, especially on smaller plots of land. We also regard the high level of special-ist expertise of Norwood* as a hugely important factor for the high operational reliability of our FELLA machines.”Coulton Bros, farmer, New Zealand*FELLA importer in New ZealandEasy to maintain Low-maintenance6 7THE EASY-TO-MAINTAIN TS3 AND TS4 RAKE HEADBOLTED CONNECTION OF THE RAKE HEADThe rake head is bolted together using a conical ring to form a sturdy unit. This has the advantage that the bolts are not subjected to shearing e? ect, but rather only to compressive and tensile forces. As a result, perfect centring and rigidity is also achieved for a long service life. If required, the tine arms can be replaced individually without having to completely dismantle the rake socket.Bolted connection with conical ringsTHE LOW-MAINTENANCE TS6 RAKE HEADBEARING MOUNTING OF THE ROTOR ARMSA typical feature of this head is the solid, large-dimensioned bearing tubes of the rotor arms. With a distance between bearings of 43 cm, this key component is designed for extremely high loads and the harshest of working conditions. The precision ball roller bearings are also completely maintenance-free.Maintenance-free precision ball roller bearingsSteerGuard –only from FELLA8 9• Patented steering system• Very positive and direct transmission of the steering movement• Very high and long-lasting steering precision• Track rods as already used in commercial vehicles• Rake runs exactly in the track of the tractor• Safe and quick travel even at 50 km/hAt a glance:TYPICAL FEATURES OF THE FELLA RAKESSTEERGUARD FOR A POSITIVE AND DIRECT STEERING MOVEMENTFELLA is the only manufacturer on the market to o? er a steering system for the rake which operates within the frame. This patented steering system provides very high and long-lasting steering precision. The steering shaft is protected against damage by the frame and, unlike externally located steering rods, has only two points of de? ection. As a result accurate steering and safety is guranteed, even after years of use.The steering movement is transferred from the steering shaft to the wheels with the aid of the stub axle steering with adjustable track rod. The track rods with high-precision conical heads originate from their use in commercial vehicles where they have proved their effi ciency over millions of kilometres. The greatest benefi t of this steering system lies in the very positive and direct transmission of the steering movement. The rake always runs exactly in the track of the tractor and is also still extremely agile. Furthermore, this type of steering guarantees very smooth running even at high speeds. As a result, safe and quick travel from fi eld to fi eld is possible at a speed of up to 50 km/h.SteerGuardTrack rods as already used in commercial vehicles Adjustable track rod head10 11• Fully cardanic rotor suspension• Perfect ground adaptation when rotors are inclined both longitudinally and transversely• Tidy raking work without forage lossAt a glance:• No penetration by the tines when the rotor is lifted in and out• No damage to the sward• No forage contamination – top-quality forageAt a glance:TYPICAL FEATURES OF THE FELLA RAKESPERFECT GROUND ADAPTATION IN EVERY SITUATIONThe patented, fully cardanic rotor suspension from FELLA ensures perfect ground adaptation even under the most difficult of working conditions. The rotor can adapt itself perfectly to the ground and independently of the frame, whether inclined longitudinally or transversely. As a result, forage lying in recesses and depressions can be recovered without loss. Damage to the sward by the tines is safely avoided even in hilly terrain. With FELLA, tidy raking work is always achieved without forage loss – and it's top-quality forage.Patented, fully cardanic rotor suspensionJET EFFECTDue to the fully cardanic rotor suspension and weight distribution of the rotor, the rotor lifts first at the front and then at the back. When lowered, the rear wheels of the rotor first make contact with the ground and then the front wheels. In this way, the tines are prevented from penetrating into the ground. No penetration, no damage to the sward, no forage contamination – top-quality forage.Jet effectSwath deposit on the right – makes ergonomic sense12 13TYPICAL FEATURES OF THE FELLA RAKESPOWER TRAINSAll power trains on FELLA rakes are equipped with overload protection and freewheeling clutches. The power trains are thereby protected against overload, which avoids expensive repairs. Long down-times are also prevented during the forage harvesting season.RAKE DEPOSIT TO THE RIGHTAll FELLA rakes (except central rakes) deposit the swath to the right. In this way, you always have your perfect swath in view, because the operating controls in the tractors nowadays are on the right. Depositing on the right – makes ergonomic sense TINE FIXTUREThe tines are not pushed over the tine tube; instead each tine is bolted in from the bottom. This has the advantage that the side of the arm facing the forage is absolutely smooth and therefore no forage remains stuck to it. In the event that a tine becomes worn, all tines do not have to be removed in order to change one of the inner tines. The tines also have greater freedom of movement because their move-ment is not limited by the tube.TINE ARMSAll FELLA tine arms consist of tough tube material and are manufactured in one piece. The connection point to the tine arm is machined for a perfect fi t which makes it possible to insert the tine arms easily and reduces wear on this heavily stressed point to a minimum. Each tine is bolted in place individually beneath the tine armTine ? xtureAbsolutely smooth front side of the tine armCentral rake power trainCentral rake power trainPerfectly ? tting connection point to the tine arms 14 15Machine designation TS 4000Approx. working width in m 12.50Approx. transport width in m 1.20–2.20Number of possible swaths 1Approx. weight in kg 4,300Approx. power requirement in kW/hp 59/80Machine designation TS 671 TS 801 TS 880 TS 880 PRO TS 10055Approx. working width in m 5.80–6.60 6.80–7.60 7.20–8.10 7.20–8.10 8.80–10.00Approx. swath width in m 1.20–1.80 1.20–2.00 1.20–2.00 1.20–2.00 1.30–2.20Number of possible swaths 1 1 1 1 1Approx. weight in kg 1,350 1,875 1,900 2,000 2,900Approx. power requirement in kW/hp 19/26 30/41 35/48 35/48 51/70Machine designation TS 1302 TS 1502 TS 1402 TS 1452 TS 1603 TS 9060Approx. working width in m 6.30/7.00 6.30/7.00 5.75/6.65 5.80/6.70 6.60/7.70 8.50Approx. swath width in m 0.60–1.90 0.60–1.90 0.60–1.90 0.60–1.90 0.60–1.90 0.80–2.20Number of possible swaths 2 2 2 2 2 1Approx. weight in kg 1,250 1,380 1,550 1,580 2,100 2,900Approx. power requirement in kW/hp 33/45 33/45 19/26 19/26 30/41 55/75CONTENTS OVERVIEW: TWO-ROTOR AND FOUR-ROTOR RAKESMACHINE DESIGNATIONS AND ABBREVIATIONS• TS: RakePage 18–23 TWO-ROTOR RAKE WITH SIDE SWATH DEPOSITClassic two-rotor side rake for swathing large single swaths and two small single swaths with and without transport chassis.Page 26–33TWO-ROTOR RAKE WITH CENTRAL SWATH DEPOSITTwo-rotor central rake with variable working width and swath width which wins over users with its raking perfor-mance and ? exibility.Page 36–37FOUR-ROTOR RAKE WITH CENTRAL SWATH DEPOSITFour-rotor large area rake with variable working width and swath width which wins over users with its performance, agility and simple yet sturdy construction.16 17Two-rotor side rake from FELLABEST HARVESTBased on tradition, innovation and passion.18 19FLEXIBILITY IN DEMANDING TERRAINThe models TS 1302 and TS 1502 are very agile and universally deployable machines. Depositing a single swath is just as possible as depositing two small single swaths or a double swath by making a return pass. The working width can be infi nitely adjusted hydraulically and held fi xed in any position. Using these machines, tidy and precise swaths can be formed even on demanding terrain. Due to the com-paratively low weight, small tractors can also be used, which is cost-e? ective.PERFECT GROUND ADAPTATIONThe cardanic mechanism patented by FELLA in conjunction with the twistable frame and the large-dimensioned tyres ensure perfect ground adaptation. As a result, forage lying in recesses and depres-sions can be recovered without contamination or loss. MAXIMUM CONVENIENCEChanging from working position to transport position can be conveniently performed from the tractor seat. Also, the tine arms do not have to be removed for travelling on the road. Depending on the country involved, the permissible transport speed for these models is 40 km/h. As a result, there is more time left for the actual task, namely raking. TOP-QUALITY FORAGEBecause of the numerous adjustment options on the rake, tidy raking work can be achieved, even under diffi cult conditions. High-quality basic forage can therefore be produced. • One or two swaths – anything is possible• Twistable frame• Flexible working width from 3.10 metres to 7.00 metres• Perfect ground adaptation thanks to patented fully cardanic mechanism• Quick transport without modifying the tine arms• Easy-to-maintain TS4 rake head• Top-quality forageAt a glance:TS 1302TS 1502• Tidy raking, even on demanding terrain• Low power requirement • Transport width, without converting, less than 3 metresWE RECOMMEND:• Tandem axle with 18/8.50-8hyper-balloon tyres for smooth and positive running even under difficult condi-tions • Contact wheel 18/8.50-8 with hyper-balloon tyre for the front rotor for improved adap-tation to ground conditionsTWO-ROTOR SIDE RAKETS 1502Transport width less than 3 m Single swathTwo single swaths20 21TS 1402 TS 1452 TS 1603 • Medium-sized side rake• Tidy forage handover and swath formationFIRST-RATE TECHNOLOGY FOR QUALITY FORAGE With the TS 1402, TS 1452 and TS 1603 models, FELLA o? er three medium-sized two-rotor side rakes. Using these rakes, it is possible to deposit two small swaths, one large swath or a double swath by making a return pass. The switchover can be performed easily and within seconds. All FELLA side rakes have a large overlap between the fi rst and the second rotor ensuring a tidy forage handover and swath formation even under diffi cult working conditions.PERFECT GROUND ADAPTATIONIn addition to the fully cardanic rotor suspension, the side rake is distinguished by its contact-sensing chassis. It enables optimal ground adaptation at all times. The longitudinal and transverse inclination can also be variably set on all rotors. This ensures that contamination of your high-quality forage is prevented. CONVENIENCE OF OPERATION, PURE AND SIMPLEThe machine is equipped with an automatic hydraulic sequential control system which can be individu-ally adapted to your requirements. This system controls the delayed raising and lowering of the rear and front rotor and, as a result, enables you to deposit perfectly formed swaths at the headland. Because of the automatic height limitation in the headland position, it is no longer necessary to switch o? the rotors. The lowest transport height is also ensured in the transport position, no matter which working width you have set. A FELLA patent. • Large working widths possible• Deposit of 1 or 2 swaths possible as part of standard equipment• Transport speeds of up to 50 km/h• Perfect ground contour following• Convenience of operation, pure and simple• SteerGuard• Cardanic rotor suspension• Easy-to-maintain TS3 rake head (TS 1402/TS 1452)• Easy-to-maintain TS4 rake head (TS 1603)• Jet effectAt a glance:WE RECOMMEND:• Tandem axle with 16/6.50-8 super-balloon tyres for smooth running and tidy work in all conditions and for all types of forage • Spare wheel with 16/6.50-8 super-balloon tyre TWO-ROTOR SIDE RAKE WITH TRANSPORT CHASSISPrecise steeringTS 1452NEW22 23WE RECOMMEND:• Spare wheel with 18/8.50-8 hyper-balloon tyre with holder • Tandem axle for rear rotor• Specialist for large, level surfaces• Swaths of 8.5 metres of 17 metres working width• Transport height with tines attached less than 4 metres• Transport speeds of up to 50 km/h• Perfect ground contour following• Jet effect• Low-maintenance TS6 rake head• Cardanic rotor suspensionAt a glance:TS 9060• Largest side rake from FELLA• For flat and spacious terrains• Transport height less than 4 metresTHE SPECIALIST FOR LARGE, LEVEL SURFACES AND HEAVY FORAGE LEVELSThe TS 9060 side rake sets new standards in rotor diameter, work output and working width. With a rotor diameter of 4 metres and a working width of 8.5 metres or 17 metres by making a return pass, this machine takes you forward into a new dimension of area output. This machine was specially developed for farms in ? at, spacious terrains with a thick cover of forage. Single or double swaths can be e? ort-lessly formed, thereby preparing a perfect swath for the machines following on behind. Because of the special folding mechanism of the TS 9060, the transport height remains less than 4 metres even with tines attached. Coupled with a transport speed of up to 50 km/h, transferring from fi eld to fi eld is child’s play. The low centre of gravity provides safe driving behaviour as well as a high level of stability. Because of the low-maintenance overall concept, time and e? ort spent on servicing is reduced to a minimum. PERFECT GROUND ADAPTATIONIn addition to the fully cardanic rotor suspension, the TS 9060 is distinguished from other machines by its new 5-wheel contact-sensing chassis with steerable leading wheels at the front rotor and the 4-wheel contact-sensing chassis on the rear rotor. This confi guration enables optimal ground adapta-tion at all times. The longitudinal and transverse inclination can also be variably set on all rotors. As a result, it is not possible for your forage to become contaminated. CONVENIENCE OF OPERATION, PURE AND SIMPLEThe machine is equipped with an automatic hydraulic sequential control system which can be individu-ally adapted to your requirements. This system controls the delayed raising and lowering of the rear and front rotor and, as a result, enables you to deposit perfectly formed swaths at the headland. Because of the automatic height limitation in the headland position, it is no longer necessary to switch o? the rotors. The swath sheet folds automatically from the working position to the transport position. TWO-ROTOR SIDE RAKE WITH TRANSPORT CHASSISTS 906024 25Two-rotor central rake from FELLABEST HARVESTBased on tradition, innovation and passion.26 27• Variable working width from 5.8 metres to 6.6 metres• Short and agile rake• Jet effect• Transport speeds of up to 50 km/h• SteerGuard• Ideally suited for small tractors• Easy-to-maintain TS3 rake head• Cardanic rotor suspensionAt a glance:TS 671• Entry-level model with professional equipment• Short and agile frame• Ideally suited for small tractorsCENTRAL RAKE FOR SMALL TRACTORSThe TS 671 entry-level model in the two-rotor central rake range has a working width of 5.8 metres to 6.6 metres. This machine combines the technology which has proven itself so many times before in the single-rotor rake with elements of the professional equipment fi tted to its “big brothers”. The TS 671 wins users over with its uncompromising stability even under harsh working conditions. Because of the short and agile frame, you can overcome any situation, however diffi cult. True to the motto: wide in the fi eld, narrow and quick on the road. CONVENIENCE OF OPERATION, PURE AND SIMPLEThe working width can be adjusted without tools and, combined with the externally adjustable control cam, enables the creation of an optimum swath for the machines following on behind. The working width can be selected in four di? erent dimensions, thereby providing maximum convenience without great expenditure of time and e? ort. Because of the patented technology, the lowest transport height is always ensured regardless of the preselected working width. Because of the automatic height limita-tion in the headland position, it is no longer necessary to switch o? the rotors. The swath sheet folds up automatically and, in this way, it is even possible to travel over transverse swaths without forage loss. WE RECOMMEND: • Tandem axle with 16/6.50-8 super-balloon tyres for smooth running and tidy work in all conditions and for all types of forage • Single-rotor lifting TWO-ROTOR CENTRAL RAKE WITH TRANSPORT CHASSISTS 67128 29THE ALL-ROUNDERS IN THE TWO-ROTOR CENTRAL RAKE RANGEAutomatic working width preselection, tidy raking work, precisely deposited swaths (even where large quantities of forage are involved) and quick and safe travel from fi eld to fi eld are all o? ered by the TS 801 and TS 880 two-rotor central rakes. With variable working widths from 6.8 metres to 8.1 metres and swaths of 1.2 metres to 2.0 metres, they can master any working situation. Due to the 4-wheel contact-sensing chassis with the self-steering twin leading wheels and the cardanic suspension of the rotors, tidy and loss-free raking work is always achieved. The best precondition for your high-quality forage.CONVENIENCE OF OPERATION, PURE AND SIMPLEThe working width can be adjusted without tools and, combined with the externally adjustable control cam, enables the creation of an optimum swath for the machines following on behind. The working width can be selected in four di? erent dimensions, thereby providing maximum convenience without a great expenditure of time and e? ort. Because of the patented technology, the lowest transport height is always ensured regardless of the preselected working width. Because of the automatic height limita-tion in the headland position, it is no longer necessary to switch o? the rotors. The swath sheet folds up automatically and, in this way, it is even possible to travel over transverse swaths without forage loss.• Variable working width from 6.8 metres to 8.1 metres• Perfect ground contour following• High level of operational convenience• SteerGuard• Easy-to-maintain TS4 rake head• Cardanic rotor suspension• Jet effectAt a glance:TS 801TS 880• The all-rounders• Automatic working width preselection• Optimum swath formationWE RECOMMEND:• Tandem axle with 16/6.50-8 super-balloon tyres for smooth running and tidy work in all conditions and for all types of forage • Single-rotor liftingTWO-ROTOR CENTRAL RAKE WITH TRANSPORT CHASSISTidy raking work – down to the last blade of grassTS 880Headland positionCompact swath30 31THE SPECIALIST FOR STRAW AND EXTREME WORKING CONDITIONSBecause the rotor rakes are under enormous stress during straw recovery and other diffi cult working conditions, they require an improved level of technology and equipment. The TS 880 PRO includes all the benefi ts of the already successful TS 880, with the addition of a particularly robust rotor chassis which was specially developed for extreme requirements. The new rotor chassis on the TS 880 PRO has been equipped with six rather than four wheels and with a tandem axle with 18-inch tyres, which ensures optimum ground adaptation. The twin leading wheel was also redesigned to be larger and rigid in order to guarantee running even under diffi cult conditions in the stubble fi eld. The clearance between tines and leading wheel was also reduced in order to guarantee a top-quality swath without contamination and stones, creating perfect conditions for your machine following on behind. The TS 880 PRO of course also copes competently with all operations on normal grassland.• Specialist for straw and harsh working conditions• Rigid twin leading wheel with 18/8.50-8 tyres• Wide tandem axle• Greater tandem axle wheel clearance• Transport speed of up to 50 km/h• Convenience of operation, pure and simple• Easy-to-maintain TS4 rake head• SteerGuard• Cardanic rotor suspension• Jet effectAt a glance:TS 880 PRO• Specialist for extreme working conditions• Optimum ground adaptation• Top-quality swathWE RECOMMEND:• Flow divider for synchronised lifting of the rotors • Spare wheelTWO-ROTOR CENTRAL RAKE WITH TRANSPORT CHASSISTS 880 PROHeadland positionLARGE WORKING WIDTH32 33THINK BIG – THINK FELLABigger, faster, stronger. The TS 10055 is the largest central rake with two rotors in the FELLA range. Its enormous area output is essential for ensuring the high level of effi ciency of the harvesting ma-chines following on behind. In order to optimally handle large quantities of forage, the working width can be changed hydraulically from 8.8 metres to 10 metres, allowing a perfect swath to be produced. The permissible transport speed of up to 50 km/h ensures quick journeys to the place of work so you can quite easily manage any working day with the FELLA TS 10055, no matter how long. Because of the low-maintenance overall concept, time and e? ort spent on servicing is reduced to a minimum.PERFECT GROUND ADAPTATIONIn addition to the fully cardanic rotor suspension, the TS 10055 sets itself apart with its wide 4-wheel contact-sensing chassis with steerable leading wheels. This confi guration enables optimal ground adaptation at all times. The longitudinal and transverse inclination can be variably set on all rotors. As a result, no contamination occurs to your high-quality forage.SIMPLY INGENIOUSThe switchover from transport position to working position is triggered simply and very conveniently. The automatic locking system opens automatically and so the risk of incorrect operation is excluded.• SteerGuard• Cardanic rotor suspension• Jet effect• Low-maintenance TS6 rake head• Transport speeds of up to 50 km/h• Variable working width from 8.80 metres to 10.00 metres• Automatic locking and unlocking during changeoverAt a glance:TS 10055• The largest two-rotor central rake from FELLA• Fully following the trend towards larger working widths• Powerful performance, full of punchWE RECOMMEND: • Tandem axle • Electrohydraulic operation for rotor height adjustment and single liftingTWO-ROTOR CENTRAL RAKE WITH TRANSPORT CHASSISTS 10055Variable working width Automatic locking systemEnormous working width34 35Four-rotor central rake from FELLABEST HARVESTBased on tradition, innovation and passion.36 37THE FELLA FLAGSHIPPerformance and agility: With the TS 4000, FELLA o? ers a four-rotor large-area rake which wins over new users. With its four rotors and a working width of 12.5 metres, this rake provides each machine fol-lowing on behind with an optimum swath and, as a result, optimum capacity utilisation.The model was specially developed for large-scale farms as well as inter-farm use. Because of its simple yet extremely robust construction, the TS 4000 is easy to operate, which increases its ? exibility precisely when used on more than one farm. And so, new drivers can also use the TS 4000 safely and effi ciently.HEADLAND CONTROL SYSTEMThe machine is equipped with an automatic hydraulic sequential control system which can be individu-ally adapted to your requirements. This system controls the delayed raising and lowering of the rear pair of rotors and, as a result, enables you to deposit perfectly formed swaths at the headland. Because of the automatic height limitation in the headland position, it is no longer necessary to switch o? the rotors. The swath sheet folds up automatically and, in this way, it is even possible to travel over trans-verse swaths without forage loss.SAFE ON THE ROAD AND ON THE HILLSIDEThe TS 4000 is designed for a transport speed of up to 50 km/h, which ensures quick journeys to the site of work. In order to be safe at all times when travelling, the machine is equipped with a high-perfor-mance brake system. The brake system allows you to carry out diffi cult operations in hillside situations. Due to the low centre of gravity, safe driving behaviour is also guaranteed, even at 50 km/h.• Variable swath width• Simple yet robust construction• Ease of operation• Transport speeds of up to 50 km/h• Headland control system• Easy-to-maintain TS4 rake head• Brake system• Cardanic rotor suspension• Jet effectAt a glance:TS 4000• For large farms and inter-farm use• Simple yet robust construction• Low centre of gravity, excellent driving behaviourWE RECOMMEND: • Electrohydraulic single lifting for individually raising or lowering the rotors FOUR-ROTOR CENTRAL RAKE WITH TRANSPORT CHASSISTS 4000Automatic hydraulic sequential controlTransport position38 39TS 1302 TS 1502 TS 1402 TS 1452 TS 1603 TS 9060 TS 671 TS 801 TS 880 TS 880 PRO TS 10055 TS 4000Dimensions and weightApprox. working width in m 6.30/7.00 6.30/7.00 5.75/6.65 5.80/6.70 6.60/7.70 8.50 5.80–6.60 6.80–7.60 7.20–8.10 7.20–8.10 8.80–10.00 12.50Approx. rotor diameter in m 2.96 2.96 2.74/2.78 2.78 3.20 4.00 2.74 3.20 3.40 3.40 4.20 3.20Approx. transport width in m 2.30/3.00 2.30/3.00 2.65 2.70 2.98 2.98 2.98 2.98 2.98 2.98 2.87 2.98Approx. swath width in m 0.60–1.90 0.60–1.90 0.60–1.90 0.60–1.90 0.60–1.90 0.80–2.20 1.20–1.80 1.20–2.00 1.20–2.00 1.20–2.00 1.30–2.20 1.20–2.20Number of possible swaths 2 2 2 2 2 1 1 1 1 1 1 1Approx. transport length in m 8.45 8.45 6.65 6.65 7.45 10.80 4.65 5.35 5.35 5.35 6.50 8.50Approx. transport height in m 2.80 2.80 3.30/3.60 3.30/3.60 3.65 3.50/3.99 3.18/3.70 3.55 3.60 3.60 3.85 3.65Approx. weight in kg 1,250 1,380 1,550 1,580 2,100 2,900 1,350 1,875 1,900 2,000 2,900 4,300Power requirementApprox. power requirement in kW/hp 33/45 33/45 19/26 19/26 30/41 55/75 19/26 30/41 35/48 35/48 51/70 59/80HitchingTwo-point lower links – – CAT I + II CAT I + II CAT I + II CAT II CAT I + II CAT I + II CAT I + II CAT I + II CAT II CAT IITractor linkage drawbar • • – – – – – – – – – –Rotor, arms, tinesCrop delivery Right Right Right Right Right Right Centre Centre Centre Centre Centre CentreNumber of rotors 2 2 2 2 2 2 2 2 2 2 2 4Number of tine arms per rotor (front rotors) 10 12 10 12 12 15 10 12 12 12 15 12Number of tine arms per rotor (rear rotors) 10 12 12 12 12 15 – – – – – 12Number of tines per arm (front rotors) 3 4 4 4 4 5 4 4 4 4 5 4Number of tines per arm (rear rotors) 3 4 4 4 5 5 – – – – – 4Hydraulic control unitsRequired hydraulic connections 1 x single-acting/ 1 x double-acting1 x single-acting/ 1 x double-acting 1 x single-acting 1 x single-acting 1 x single-acting1 x single-acting/ 1 x double-acting 1 x single-acting 1 x single-acting 1 x single-acting 1 x single-acting1 x single-acting/ 1 x double-acting 2 x double-actingTyres, axles, lighting equipmentTyres (rotors) 18/8.50-8 18/8.50-8 16/6.50-8 16/6.50-8 16/6.50-8 18/8.50-8 16/6.50-8 16/6.50-8 16/6.50-8 18/8.50-8 18/8.50-8 16/6.50-8Tandem axis • • • • • • • • • • • •Standard tyres (main chassis) – – 10.0/75-15.3 10.0/75-15.3 10.0/75-15.3 380/55-17 10.0/75-15.3 10.0/75-15.3 10.0/75-15.3 300/80-15.3 300/80-15.3 500/50-17Electric lighting • • • • • • • • • • • •TECHNICAL SPECIFICATIONS OF MULTI-ROTOR RAKESIllustrations show some of the special equipment. The right to technical revision is reserved.Best harvest – based on tradition, innovation and passion.• Series • Equipment variant – not availableFELLA FOR YOUPHILOSOPHYFor FELLA, close contact with its customers is very important. The experiences of farmers and agricul-tural contractors who use FELLA products is collected from the various markets around the world and is purposefully incorporated in the design of our products.SERVICE“Out of sight, out of mind.” But not at FELLATogether with our dealers, we are always there and ready to provide reliable support to our partners, both at home and abroad – as we have been now for almost 100 years. In conjunction with our well organised spare parts stores, regular further technical training for our dealers ensures that FELLA machines can be used, maintained and repaired to a professional standard. This comprehensive service ensures a high level of deployment reliability for your FELLA machines and makes a signifi cant contribution to high-yield and stress-free forage harvesting.• Exceptionally wide range of mowers, hay tedders and swathers• Innovation and progress: continuous further development for the best harvest• Deployment reliability thanks to professional dealers and well organised spare parts stores• Long service life machines “Made in Germany”PATENTSIt is FELLA's objective to create ingenious and sustainable solutions for our products . This has already been well documented through numerous FELLA patents. “We can't change the weather, but we have the machines that can make the most of it in any conditions.”Your FELLA teamFELLA-Werke GmbHFellastraße 1–3D-90537 Feucht +49 9128 73-0 +49 9128 73-117vertrieb@fella.euwww.fella.eu
