S15 Series M18 Tubular Sensors Datasheet

1 S15 SERIESThe new S15 series of M18 tubular sensors offers both plastic case version S15-PA and stainless steel IP69K housing version S15-NA.S15-PA plastic version is recommended for cost and space savings with a wide selection of optic functions, ranging from 5 m retroreflex to 1 m diffuse proximity and 12 cm background suppression. Each model is available with or without trimmer setting to fit the most varied applications in assembling and conveyor lines, processing and packaging machinery.In order to maximize the installation flexibility, the sensor connectivity is available with 2 m cable, M12 4-pole connector or even a pig-tail version. A dedicated input allows the Ligh/Dark model selection.S15-NA metal version include a widest optic function selection, all equipped with trimmer setting and metal M12 connector to improve the sensor robustness.Thanks to the IP69K protection to frequent washdowns and corrosion-resistant AISI316L stainless steel housing, these sensors are recommended for processing and packaging machinery in food, beverage, dairy, and pharmaceutical industries, as well as paper and printing machinery, conveyor lines, and material handling in general. hIghlIghtS• Plastic short case version for cost and space saving• Stainless steel case version for IP69K protection• All optic functions at optimal operating distance• Models with fixed setting or trimmer adjustment• Cable, M12 connector and pig-tail versions APPlICAtIONSSENSORSPhOtOElECtRICCeramicstransportation linesBeverage & BottlingPackaging lines for food and pharmatuBulAR SENSORSwww.datalogic.com2 DIMENSIONS INStAllAtIONThe sensor can be fixed by means of the M18x1 threaded body using CH.24 nuts (1.5 Nm maximum tightening torque) or low-profile flared nut provided specifically supplied for various orientable fixing brackets are available to ease sensor positioning (please refer to the accessories listed in the general catalogue). The operating distance is measured from the front surface of the sensor lens.Proximity (C and D) models: the object has to be moved closer or further away from the front surface of the sensor lens to improve detection. In case of lateral translation, the object must move as indicated in the figure.In models with the sensitivity trimmer and the green LED (STABILITY), we can obtain an optimal installation. Turn the trimmer and move sensor until the yellow LED (OUT) and the green LED (STABILITY) switch ON permanently, in order to mount the sensor in the correct position.S15-PA/NA-5S15-PA-2/3-D50S15-PA-2/3S15-PA-3 (pig-tail)dimensions in mmCONNECtIONSS15…A00/B00/C00/C10/F00/D50S15…A01/B01/C11/C31/t01/F01Cable and Pig tailM12 ConnectorS15-…g00S15…g01* in case of white wire or pin 2 not connected the sensor operates in LIGHT mode for the proximity models (S15…Cxx/D50) and in DARK mode for the retroreflex (S15…A0x/B0x/T01) and receiver models (S15…F0x).3DEtECtION DIAgRAMStEChNICAl DAtA tEChNICAl NOtEPower supply 12 ... 30 Vdc¹ Ripple = 2 VppConsumption =25 mA Output current = 100 mA Saturation voltage = 2 VDielectric strength 500 Vac 1 min., between electronics and housingInsulation resistence >20 MO 500 Vdc, between electronics and housing Mechanical protection IP65, IP67, IP69K Ambient light rejection According to EN 60947-5-2Vibrations 0.5 mm amplitude, 10 … 55 Hz frequency, for each axis (EN60068-2-6)Protection devices A, B²housing Plastic version ABS TERLURAN Metal version INOX AISI 316LIndicators yellow OUTPUT LEDgreen STABILITY LED, POWER LED (through beam emitter S15-xx-x-G0x)Operating mode selectable dark/light³ Auxiliary functions Test + and Test - Emitter off with Test+ on Vdc and Test- on 0 VConnection Cable vers. 2 m Ø 4 mm (PVC, 4 x 0,14 mm2)Connector vers. M12 4-pole connectorpig-tail vers. 150 mm cable + M12 4-pole connectorlens material plastic PMMA Weight 40 g max mod. M1255 g max mod. cable35 g max mod. pig-tail Operating temperature -25 ... +55°C Storage temperature -25 ... +70°C Reference directives EN 60947-5-2, UL 508 t01 - REtROFlEx By tRASPARENtF00/g01 - thROugh BEAMC00 - ShORt DIFFuSE PROxIMItycmB00 - POlARISED REtROREFlExcmC10/C11 - MEDIuM DIFFuSE PROxIMItycmD50 - FIxED FOCuS PROxIMItymmmmM01 - BACkgROuND SuPPRESSIONDifference White/grey and Black/White¹Limit values² A - reverse polarity protection B - overload and short-circuit protection³ With L/D input not connected the proximity models function in the light mode and the retroreflex and through beam models in the dark mode; the light mode can be selected connecting the L/D input to +Vdc, the dark mode connecting it to 0Vdc.II3DGA00 - REtROFlExcmm mC31 - lONg DIFFuSE PROxIMItycmcmcmmDiff. W/G Diff. B/Wcm mR2R5R2 R5R2 R5Grey 18% White 90%mmwww.datalogic.com4OPtIC FuNCtION lIght EMISSION¹ OPERAtINg DIStANCE CONNECtION SEttINg SWItCh FREQuENCy RESPONSE tIMEnon-polarised retroflex infrared LED 880 nm 0,1…5 m on R2connector M12 sensitivity trimmer500 Hz 1 mscable fixedpig-tail fixedpolarised retroflex red LED 660 nm 0,1…4 m on R2connector M12 sensitivity trimmer500 Hz 1 mscable fixedpig-tail fixeddiffuse proximity infrared LED 880 nmshort: 1...10 cmcable fixed500 Hz 1 mspig tail fixedmedium: 1...35 cmconnector M12 sensitivity trimmercable fixedpig-tail fixedlong: 1...100 cm connector M12 sensitivity trimmerfixed focus proximity red LED 660 nm 1...5 cmcable fixed 1 KHz 500 µs pig-tail fixedthrough beam receiver n/a 0…20 mconnector M12 sensitivity trimmer250 Hz 2 ms cable fixedpig-tail fixedthrough beam emitter infrared LED 880 nm 0…20 mconnector M12 light emission power trimmern/a 2 ms cable fixedpig-tail fixedretro-reflex by transparent red LED 660 nm 0,1…0,8 m on R2 connector M12 sensitivity trimmer 500 Hz 1 msbackground suppression red LED 660 nm 40…120 mm connector M12 sensitivity trimmer 500 Hz 1 ms¹ Average life of 100.000 h with TA = +25 °COPtIC FuNCtION lIght EMISSION¹ OPERAtINg DIStANCE CONNECtION SEttINg SWItCh FREQuENCy RESPONSE tIMEnon-polarised retroflex infrared LED 880 nm 0,1…5 m on R2 connector M12 sensitivity trimmer 500 Hz 1 mspolarised retroflex red LED 660 nm 0,1…4 m on R2 connector M12 sensitivity trimmer 500 Hz 1 msdiffuse proximity infrared LED 880 nm medium: 1...35 cm connector M12 sensitivity trimmer 500 Hz 1 mslong: 1...100 cm connector M12 sensitivity trimmer 500 Hz 1 msthrough beam receiver n/a 0…20 m connector M12 sensitivity trimmer 250 Hz 2 ms through beam emitter infrared LED 880 nm 0…20 m connector M12 light emission power trimmer n/a 2 ms retro-reflex by transparent red LED 660 nm 0,1…0,8 m on R2 connector M12 sensitivity trimmer 500 Hz 1 msbackground suppression red LED 660 nm 40…120 mm connector M12 sensitivity trimmer 500 Hz 1 ms¹ Average life of 100.000 h with TA = +25 °CS15 - PA (PlAStIC VERS.)S15 - NA (MEtAl VERS.)5OPtIC FuNCtION hOuSINg CONNECtION OutPut MODEl ORDER NO.retroreflexPLASTICconnector M12PNP S15-PA-5-A01-PK 952301220NPN S15-PA-5-A01-NK 9523013002 m cablePNP S15-PA-2-A00-PK 952301001NPN S15-PA-2-A00-NK 952301051pig-tailPNP S15-PA-3-A00-PK 952301111NPN S15-PA-3-A00-NK 952301161METAL connector M12PNP S15-NA-5-A01-PK 952301370NPN S15-NA-5-A01-NK 952301450polarised retroreflexPLASTICconnector M12PNP S15-PA-5-B01-PK 952301230NPN S15-PA-5-B01-NK 9523013102 m cablePNP S15-PA-2-B00-PK 952301011NPN S15-PA-2-B00-NK 952301061pig-tailPNP S15-PA-3-B00-PK 952301121NPN S15-PA-3-B00-NK 952301171METAL connector M12PNP S15-NA-5-B01-PK 952301380NPN S15-NA-5-B01-NK 952301460short distance diffuse proximity PLASTIC2 m cablePNP S15-PA-2-C00-PK 952301021NPN S15-PA-2-C00-NK 952301071pig-tailPNP S15-PA-3-C00-PK 952301131NPN S15-PA-3-C00-NK 952301181medium distancediffuse proximity PLASTICconnector M12PNP S15-PA-5-C11-PK 952301250NPN S15-PA-5-C11-NK 9523013302 m cablePNP S15-PA-2-C10-PK 952301031NPN S15-PA-2-C10-NK 952301081pig-tailPNP S15-PA-3-C10-PK 952301141NPN S15-PA-3-C10-NK 952301191METAL connector M12PNP S15-NA-5-C11-PK 952301400NPN S15-NA-5-C11-NK 952301480long distance diffuse proximity PLASTIC connector M12PNP S15-PA-5-C31-PK 952301260NPN S15-PA-5-C31-NK 952301340METAL connector M12PNP S15-NA-5-C31-PK 952301410NPN S15-NA-5-C31-NK 952301490fixed focus proximity PLASTIC2 m cablePNP S15-PA-2-D50-PK 952301520NPN S15-PA-2-D50-NK 952301530pig-tailPNP S15-PA-3-D50-PK 952301540NPN S15-PA-3-D50-NK 952301550retro-reflex by transparent PLASTIC connector M12PNP S15-PA-5-T01-PK 952301240NPN S15-PA-5-T01-NK 952301320METAL connector M12PNP S15-NA-5-T01-PK 952301390NPN S15-NA-5-T01-NK 952301470through beam (receiver)PLASTICconnector M12PNP S15-PA-5-F01-PK 952301280NPN S15-PA-5-F01-NK 9523013602 m cablePNP S15-PA-2-F00-PK 952301041NPN S15-PA-2-F00-NK 952301091pig-tailPNP S15-PA-3-F00-PK 952301151NPN S15-PA-3-F00-NK 952301201METAL connector M12PNP S15-NA-5-F01-PK 952301430NPN S15-NA-5-F01-NK 952301510through beam (emitter)PLASTICconnector M12 - S15-PA-5-G01-XG 9523012902 m cable - S15-PA-2-G00-XG 952301101pig-tail - S15-PA-3-G00-XG 952301211METAL connector M12 - S15-NA-5-G01-XG 952301440background suppressionPLASTIC connector M12PNP S15-PA-5-M01-PK 952301270NPN S15-PA-5-M01-NK 952301350METAL connector M12PNP S15-NA-5-M01-PK 952301420NPN S15-NA-5-M01-NK 952301500MODEl SElECtION AND ORDER INFORMAtIONwww.datalogic.com6ACCESSORy SElECtION AND ORDER INFORMAtIONACCESSORIESDESCRIPtION MODEl ORDER NO.M18 fixing bracket ST-5011 95ACC5240M18 fixing bracket ST-5012 95ACC5250flared fixing nut PLASTIC NUT 95ACC2630M18 fixing bracket ST-5017 95ACC5270fixed support for tubular M18 sensors SP-40 95ACC1370UNI EN ISO9001The company endeavours to continuously improve and renew its products; for this reason the technical data and contents of this catalogue may undergo variations without prior notice. For correct installation and use, the company can guarantee only the data indicated in the instruction manual supplied with the products.dimensions in mmRev.00, 11/2012*9C503500E* 9C503500ESP-40 St-5017 PlAStIC NutØ 27.5M18X140°4St-5012St-5011
