Silvator Wood Chipper 2000 Series- Brochure

EInnovative technologyfor bioenergySilvator 20002ErgonomicWorkplaceThe perfect workplace for the operator The heated and air-conditioned cabin can be raised to a height of 4.60 meters. This provides the operator with a good all round view. The ergonomic rotary seat (180° rotatable) is equipped with operator consoles on both sides.A generously sized water tank and the windscreen wipers en-sure perfect visibility in difficult weather conditions.Standard heated, electrically adjustable and pneumatically foldable mirrors provide an ex-cellent rear view.Due to the resiliently mounted cabin, shocks and vibrations are kept to a minimum.Silvator 2000 3 The Silvator 2000 is equipped with 2 ergonomi-cally arranged MINI-JOYSTICKS. These allow for a smooth operation of the crane and the main func-tions of the mobile chipping machine. Operation - Practical and InnovativeLower conveyor track Reverse conveyor trackRotate dischargechute anticlockwiseLift deflector flapLower deflector flapLift conveyor track Rotate discharge chute clockwiseLift discharge chuteLower discharge chuteForward conveyor trackSilvator 20004Clearly structured and easy to operate A large and clear terminal is in-tegrated into the rooflining and is controlled via an incremental encoder in the right hand control console. This arrangement allows a comfortable and effortless opera-tion.Both, the display of various operat-ing conditions as well as the pos-sibility to make personal configu-rations simplifies the operation of the Silvator 2000.Important contract data can also be exported via a USB interface or onboard printer.Clear Overview and Efficient Monitoring of all Processes• Status display of the power-train • Freely configurable sensitivity of the crane control • Monitoring the condition of the chipper body and blower • Interactive manipulation • Contract management • Engine and hydraulic control Silvator 2000 5Sufficient Power from 612 HPSufficient powerand the innovative drive system The Silvator 2000 is powered exclusively by one of Mercedes best engines. Sufficient power and torque, plus low fuel con-sumption and smooth running are typical characteristics of this engine. A specially designed pump distribution gearbox per-mits maximum capacity.The Silvator also has a drive system which is based on ad-vanced technology. The special axles and a hydrostatic drive provide excellent on and off-road driving characteristics.The hydraulicsystem can be eas-ily maintained due to the clear pipe layout.Silvator 20006Silvator 2000 7Silvator 20008Best wood chip quality12 rotationally mounted chipper knifes allow a constant, quiet and energy-saving cut. The distance between the chipper knives and the shear blade can be varied. The shear blade is pivot-mounted. In the event of an overload, the shear blade automatically moves away, which provents unnecessary wear.Replaceable wear plates consisting of Har-dox minimizes maintance costs.Uniform Wood Chips forBest Processing VariableSilvator 2000 9From Professionalsfor Professionals It only takes a few simple steps to fold out and open the blower with its dis-charge chute. This allows perfect access for maintenance work on the screw con-veyors and the shear blade. Using the MINIJOYSTICKS the discharge chute can be easily moved into any position. The crane and the discharge chute can be op-erated simultaneously with out any dif-ficulty.Big discharge chute for small pieces The very accessible and easily maintainable blower is hydraulically driven and has an intelligent control system to keep the rotor speed constant, even when the engine speed is varying.Silvator 200010Engine type MercedesModel OM 502 LACylinders V8Engine Power (according to ECE 24) at 1690 rpm KW(HP) 450 (612)Engine displacement l 16Enginespeed during chipping rpm 1400-1800Fuel tank capacity l 13002-Speed transmission hydrostatic4 Wheel drive - mechanically by propshaftMax. Speed km/h 40Turning radius approximately m ca. 8,50ChipperWidth (with feed rollers) mm 1230 (1730)Input Height mm 980Rotor speed U/min up to 500Max. flow rate m³/h up to 330 Feed rate variableRotor diameter mm 1040Number of knives qty. 12Rotor drive mechanicalBlower drive hydraulicShear blade usable on 2-sidesDistance between shear blade and knives variableShear blade protection Hydraulic overload protection Feed direction reversibleBlowerNumber of rotor blades 4Rotorspeed rpm up to 1140Rotordiameter mm 1200Discharge chute rotation angle ° 210Discharge chute length m 6,20CraneType S110 F Forwardercrane EpsilonMax. reach m 10,10Loads at 10,1m t 1Oil flow (1600 rpm) l/min 200DimensionLength m 9,70Width m 3,0Height (with cabin lifted) m 3,70 (4,80)Tires type 710/75 R34TechnicalDatasConvincingArguments • Easy to maintain• Central lubrication• Maintenance position of the blower • Rapid change of the shear blade• Maintenance-free screw actuators • Hydraulic direct drives (except chipper rotor) • Automatic reversible cooler • Reliable transfer of the material from the conveyor table to the Chipper rotor• Additional material flow due to the cross mounted screw conveyors• Chainless drives • Due to the rotatable drivers seat, the operater can comfortably reverse in to forest traks. • Balanced lighting concept with 32 working lights Silvator 2000 11FroMProFESSionalSForProFESSionalS Albach Maschinenbau GmbH & Co. KG Schlierstraße 20, 85088 Vohburg/MenningTel.: 0049 8457 934688-0 Fax: 0049 8457 934688-1 Email: email@albach-maschinenbau.dewww.albach-maschinenbau.dePLANOprint GmbH, 84069 SchierlingThe Best in its Class
