TL-BE 10-BKE-BKE

be strong, be KUHNAgricultural and landscape shreddersTL / BE 10 / BKE / BKE REVVKM / BP 10 / BP 100 / BPR 10 / BPR 100 / BPR 100 PRO / BP 1000BK / BC 10 / RM / RMS / WS 320 BIOwww.kuhn.com2Requirements for shredders, intended for agricultural use and landscape maintenance, differ according to the shredded material, prevailing conditions and operator demands. In the vast KUHN range of agricultural and landscape shredders you will fi nd a model for almost every situation.HIGH-QUALITY SHREDDING IS MOST IMPORTANTWell-shredded crop residues and green spaces are a friend for your soil when fi ght ing weeds, pests and diseases and for rapidly transforming organic matter into humus. This is best achieved, if the residues are shredded very fi nely, the working height stays uniform and the residues are spread regularly over the surface.THREE CRITERIA FOR IMPECCABLE SHREDDINGA large diameter rotor, a suffi cient overlap between the tools and a high linear tool speed: If these three assets are realized, nothing stands in the way of superb shredding results. KUHN meets these criteria with its rotors, adding also the helical tool layout in order to increase the suct ion for an improved cut and to distribute the residues evenly over the soil.3The advantages of shredding p. 4 KUHN shredders introduction p. 6 Landscape maintenance (grass) shredders p. 8 Multipurpose shredders p. 14 Field shredders p. 28 Tool choices p. 44 Technical specifi cations p. 46ContentsSome models are not available in all countries. Please always check with your local dealer.FOR EACH USE A SHREDDERTLVKMBE 10BP 10BKEBP 100BKE REVBPR 100 BPR 100 PRO BP 1000BK BC 10 RM RMS WS 320 BIO44WHY SHREDDING?On pastures and fi elds, shredders have multiple areas of operation and agronomicbenefi ts. An adapted crop residue management is an integral part in today´s agriculturalproduction systems, especially in conservation agriculture, where crop residues arenormally not ploughed under, but only incorporated superfi cially into the soil. Fine shredding and a uniform distribution are the key points:- to accelerate decomposition and conversion into humus,- to provide favorable conditions for uniform germination of the subsequent crop,- to control certain pests, diseases and weeds.5No home to pests and diseasesIn close crop rotations with high shares of maize and wheat, pests and diseases fi nd a wonderful playground to develop. Shredding is an effective instrument to destroy the maize stems, which serve as winter retreats of pests such as the European corn borer. An accelerated decomposition, more-over, ensures that no residues rest on the surface until the next wheat fl owering to avoid the transmission of fusarium spores (see table below).Don’t let weeds inMany weeds migrate from the border into the fi eld andspread over the whole plot if not hindered. An effectiveprecaution measure: shredding grass strips on fi eldborders to lock out bromegrass etc.Effective destruction of intermediate crop coversShredding intermediate crops to weaken and destroy them before seeding the next crop is an environmentally friendly alternative to chemical treatment. Think in this regard also of environmental specifi cations and legal directives, both on regional and international level.Supporting soil fertilityTo improve soil fertility, incorporation of organic matter into the soil is the most important measure. The fi ner the residue is shredded the bigger is the surface area for microorganisms to attack and transform the organic matter into humus. Strong points for high humus content: improved capability to retain water and fi x nutrients, reduced nutrient leaching, improved soil structure and stability, increased biological activity.Maintain or improve pasture qualityCattle pick out the best grass to feed on, leaving lessattractive species on the pasture. If this low quality grass is not shredded, it will spread through seeds or vegetative propagation. This reduces pasture quality on the whole and consequently also animal productivity.For uniform germination of subsequent cropFinely shredded and homogeneously distributed residues faci-litate precise seeding of the subsequent crop. There shouldn´t be many undecomposed maize or cereal straw left that could hinder a regular germination and crop growth.Some models are not available in all countries. Please always check with your local dealer.Impact of tillage measures and shredding on relative DON-contents (mycotoxin associated with Fusarium) on wheat.Source: long-term trial Boigneville - Arvalis, French Agricultural Research InstituteDON (ploughing 100 %)1999 to 20112003 to 20112007 to 2011Shredding Plough100100100Shredding Rotavator146148149Semavator280255Direct seeding315416533ShreddingDirect seeding2226KUHN SHREDDING QUALITY AND TECHNOLOGY AT ITS BESTKUHN´s agricultural and landscape shredders are developed based on two main challenges: - robust machines for long service life, - high shredding quality, meaning complete and fi ne shredding of all residues on the fi eld, intermediate crop covers, undesirable growth or grasses on pastures.KUHN ADVANTAGES FOR OPTIMAL SHREDDINGConcrete technical solutions are numerous and versatile as is the product range of our landscape and fi eld shredders. Each one is optimally adapted or adaptable to its intended use and prevailing conditions. But all of them feature common specifi cs for improved shredding work as well as more robust and reliable machines. More about the KUHN advantages in the overview belowSome models are not available in all countries. Please always check with your local dealer.AGRICULTURAL AND LANDSCAPE SHREDDERSWORK QUALITY SAVINGS7Shredding qualityKUHN solution PurposeHelical tool layout* Increased suct ion effect: all residues are picked up and enter into the housingRotor speed and diameter Improved suct ion and maximum aggressivityTools Wide choice of tools for all residuesCounter blade* Improved shredding as sect ion between tools and counter-blade is reducedRoller posit ioned as close as possible to the rotor* Very precise ground contouring, roller cleaned by tools, residues ejected over the roller for faster decomposit ionMachine robustnessKUHN solution PurposeHigh resistance steel Ensured strength and stabilityLinkage frame Extremely robustBronze alveolate bearing shells / pins stopped from rotat ing Increased rigidity, higher resistance against mechanical constraints, reliable art iculat ionsSheet metal lining* Increased resistance to wear and shocksNumber of belts Optimum power transmissionPowerband belts Reliable and lower maintenance costs than basic beltsAutomatic belt tensioning* No risk of slippageNON-STOP safety* Faced with an obstacle, shredding unit pivots to the rear and returns automatically*Standard and optional equipment may vary from model to model.8KUHNA VERSATILE FAMILY PRESENTS ITSELFFrom landscape maintenance work in parks and gardens to the upkeep of all kind of green spaces and orchards: The KUHN range of landscape shredders will perform excellently in low to medium amounts of residues. With its short tools and adapted casing size, the machines are perfect to work in grassy areas.BKE 150 REV / BKE 180 REV / BKE 210 REV / BKE 230 REV/ BKE 250 REV:Reversible versions of the BKE shredders for complete uptake of residues by the unit;BKE 150 / BKE 180 / BKE 210 / BKE 230 / BKE 250:Vast choice of models for quick and effi cient green space management with 1.53 – 2.50 m shredding width;BE 14 / BE 16 / BE 18 / BE 20:Very adaptable shredders (rear, front, reverse drive) with working widths from 1.40 to 2.00 m for professional use (villages…), suitable for tractors requiring minimally 40 to 65 hp;TL 120 / TL 150 / TL 180:Rear shredders of 1.19 – 1.78 m working width for regular use in park and garden maintenance, developed for compact tractors from 15 to 35 hp;Some models are not available in all countries. Please always check with your local dealer.Series TL BE 10 BKE BKE REVType of linkage rear front or rear or reverse drive rear front or rearIntensity of use regular professionalType of residue grassRecommended tractor power min/max (hp) 15-35 40-65 40-110Working width (cm/ft) 120 - 150 - 180 / 3´11´´- 4´11´´- 5´11´´140 - 160 - 180 200 / 4´6´´ - 5´2´5´11´´ - 6´5´´150 - 180 - 210 - 230 - 250 / 5´ - 5´11´´7´- 7´6´´ - 8´2´´LANDSCAPE MAINTENANCE SHREDDERSTL 120 150 180SMALL IS BEAUTIFULKUHN TL shredders are intended for the maintenance of parks and gardens. They have been developed for use with compact tractors. Thanks to their design and specifi c tools nothing stands in the way to high-quality mowing of lawns and green spaces anymore.HIGH-QUALITY MOWING AND SHREDDINGSpecifi c art iculated scoop knives care for superb grass mowing operat ions, as does the high number of tools. Counter knives in the casing enhance the shredding quality.IDEAL FOR GREEN SPACES- Height control by roller- Forward roller posit ion:- for perfect ground following,- roller self-cleaning by means of the tools,- project ion of shredded residues over the roller to prevent compact ing shredded grass and to favor its decomposit ion for a perfect result.DESIGNED FOR COMPACT TRACTORSAttached on three-point hitch, cat. 1 or 1N, TL shredders are adapted for tractors with low power requirements from 15 to 35 hp. TL 150 and 180 are available with an attachment with offset possibility.910BE1214 16 18 20ONE SOLUTION FOR ALMOST EVERY NEEDThe big trump card: KUHN´s BE shredders are available in rear or front mounted as well as reverse drive version. For use on front linkage or with reverse drive tractors, a kit is available to modify the linkage. In all cases, the central gearbox is supplied with two input points and integrated free wheel (540 and 1000 min-1).1. Standard rear attachment of the machine2. BE shredder in reverse drive posit ionTHE ADAPTABLE ONE FOR PARK AND GARDEN PROFESSIONALSMaintenance work in parks and grassland are the core working area of the new BE shredders. Designed for use with garden or small tractors, they can be either hitched on the tractor´s rear or front linkage or driven in reverse drive position. Available in four working widths from 1.40 to 2.00 m, these machines impress by their versatility.Some models are not available in all countries. Please always check with your local dealer.3 4EVEN MORE LINKAGE CHOICESAs standard you can choose between a fi xed linkage with two possible posit ions or hydraulic offset.THEY WORK LIKE A LAWNMOWERStandard hammer knives with specifi c patented design to avoid rotor damage.PATENT3. AN EXCELLENT GROUND FOLLOWERThe working height is set by a 160 mm diameter roller with fi xed ends, mounted on double-row ball bearings with greasing points.It is posit ioned very close to the rotor. Thus, it ensures the best possible adaptat ion to the terrain. Another advantage: The roller is automat ically cleaned by the shredding tools4. QUICK DECOMPOSITION OF RESIDUESThanks to the opt imized casing and roller posit ion, shredded grass is ejected over the roller and consequent ly can´t get compacted. It is evenly deposited in the rear, where the decom-posit ion can start immediately without delay.1112BKE BKE REV 150 180 210 230 250OPTIMIZED DESIGN FOR SUPERIOR WORKThe opt imized shredding box profi le ensuresthat large volumes of plant residues can beshredded while limit ing power consumpt ion.Equipped with a roller posit ioned very closeto the rotor, the machine follows the groundperfect ly and achieves improved decompo-sit ion.The BKE and BKE REV ranges: A vast choice of models with fi ve working widths in rear and reversible versions are available. These two ranges provide the standard KUHN machines, when it comes to maintaining grassy areas such as parks, green spaces and pastures.THE STANDARD IN THE G1312341LINKAGETwo types of linkage can be used on BKE and BKE REV shredders:• a fi xed two-posit ion coupling (centred and offset),• linkage with hydraulic offset.RASS SHREDDER RANGE LESS WEAR. IMPROVED PROTECTION.1. ADDITIONAL PROTECTIONThe bolted 4 mm thick sheet metal lining inside the casing minimizes wear and provides protect ion against foreign bodies.2. FOR INTENSIVE WORKSelect the roller with removable ends and fi tted with reinforced roller bearings that only need minimum maintenance and reduce replacement costs. FOR EVEN BETTER GROUND FOLLOWING3. ON IRREGULAR GROUNDSThe skids combined with the roller protect the side walls, improve the machine´s stability and provide addit ional guidance.4. FRONT WHEELSIntended for the BKE REV in front posit ion, the extra front wheelsimprove the ground following of the machine.Some models are not available in all countries. Please always check with your local dealer.WORK QUALITYSAVINGS1414KUHNSeries VKM BP 10BPR 10BP 100BPR 100 BPR 100 PROBP 8300BP 8340Type of linkage rear front or rear (reversible on BPR) front or rearfront or rear(BP 8300) or reversedrive (BP 8340)Main applications undergrowth, pasture, fallow landpasture, fallow land (for light work) undergrowth, pasture, fallow landpasture, fallowland, crop residuesRecommendedtractor power min/max (hp)70-175 60-175 70-175 80-250 150-300Working width (cm/ft)210 - 240 - 280 -305 / 6´11´´ -7´10´´ - 9´2´´ -9´11´´280 - 305 / 9´2´´ -9´11´´240 - 280 - 305 /7´10´´ - 9´2280 - 305 / 9´2´´ -9´11´´830 / 27´3´´ (canbe used with BPR100 PRO)A TRULY MULTIPURPOSE RANGEWith KUHN multipurpose shredders, you have a range of shredders suitable formaintaining pastures and fallow land, but also for destroying intermediate crops and plantcover.BPR 280 PRO / BPR 305 PRO:Designed for intensive work with tractors of high power requirements up to 250 hp;BP 8300 / BP 8340:2 shredding units combined with BPR 100 PRO shredder for a large working width of 8.30 m; BP 8300 as rear version, BP 8340 with reverse drive;BP 240 / BP 280 / BP 305BPR 240 / BPR 280 / BPR 305:The standard mult i-purpose KUHN shredders in rear (BP 100) and reversible versions (BPR 100) with working widths from 2.37 to 3.03 m;BP 28 / BP 30BPR 28 / BPR 30:The range for lighter works with either rear (BP) or reversible versions (BPR) with 2.79 and 3.03 m working width;VKM 210 / VKM 240 / VKM 280 / VKM 305:Optimally manage pastures and grass regrowth in working widths from 2.09 to 3.03 m;Some models are not available in all countries. Please always check with your local dealer.MULTIPURPOSE SHREDDERS1515VKMA «UNIVERSAL» DESIGNThe low construct ion with rounded edges, internal rotor bearings and smooth sides with no sharp edges facilitate shredding almost everywhere, including under trees and vines. It can also be equipped with raking t ines forligneous residues. With an adjustable rear hood, the shredding degree can be adapted to the amount of residues.A COMPACT UNITThe VKM is equipped with an offset by sli-ding tube (mechanical as standard, hydraulic as opt ion).This design allows the machine to gain in compactness with a centre of gravity close to the tractor.THE RELIABILITY OF THE ROLLER WITH REMOVABLE ENDS- Double row of ball bearings for increased longevity, perfect sealing through chicanes and greasing system.- Roller fi tted closest to the rotor for effi cient ground hugging and selfcleaning by means of the shredding tools.HIGH-QU ALITY SHREDDINGThe helical layout of tools on the VKM rotor is opt imized for:- smooth rotat ion without jolts,- good suct ion for a clean cut,- even distribut ion of shredded residues for improved decomposit ion.EASY MANAGEMENT FROM GRASSTO BRUSHWOODVKM shredders are designed primarily for use in pastures and fallow land, but can also be used for shredding prunings. With the VKM, fi nd an adaptable multipurpose shredder best suited to your needs210 240 280 305WORK QUALITYBP 28 30SHREDDERS TO SATISFY BASIC NEEDSWHEN SHREDDING BECOMES EVERYDAY WORKThe new BP 10 series shredders are desi-gned for shredding all kind of grassy areas from managing weeds on fi eld borders to maintenance work on pastures or the upkeep of green spaces in parks and gardens. Individual crop and livestock farms as well as local authorities can benefi t from its superb cost-performance ratio, when they are loo-king for a multipurpose shredder for everyday shredding operations.16TWO VERSIONS FOR DIFFERENT NEEDSFIXED LINKAGEWith the fi xed central frame the gearboxis also posit ioned in the machine´s centre. The hitch pins are supported at each end.SHIFTABLE LINKAGEThe linkage frame can be shifted mechani-cally or hydraulically on a sliding tube and comes with an off-centre gearbox to provide an extended offset of up to 45 cm to the right. Frame and top link are connected via an art iculated rod for improved ground contouring.17CONTROLLING CUTTING HEIGHTFor effi cient shredding and plant cover preser-vat ion, it is essent ial to have control over the cutt ing height. The BP shredders can either be fi tted with:- a 220 mm press roller with either fi xed or removable ends posit ioned very close to the rotor for improved ground adaptat ion, grass eject ion over the roller and automat ic cleaning by the tools,- semi-pivot ing wheels fi xed onto the shredder casing.PERFORMING SHREDDING UNITHelical layout for improved residue suct ion and homogeneous spread – robust tool holders and ant i-rotat ion attachment screws - rotor speed of 1960 min-1 for clean shredding – driven by four high-capacity XPB V-belts: Nothing stands in the way of a long-last ing high performance. A ROBUST STRUCTURELong service life and resistance against impacts is an important issue for us. There-fore, the casing structure of BP shreddersconsists of 6 mm thick metal with 8 mm thick side walls. The two counter-blades (1 notched & 1 smooth) are welded on the casing.Some models are not available in all countries. Please always check with your local dealer.SAVINGS18BP1 2240 280 305AN ALLY IN MAINTENANCEOffset possibility, adjustable rear hood, different tools to choose from: Owing to its versatility, this shredder is able to meet very varied applications such as maintenance of pasture land, orchards, unsown areas, but also shredding crop residues or intermediate crops.193 A ROBUST AND MULTIPURPOSE HOODThe structure is made up of two beams inclu-ding a welded sheet metal lining for increasedresistance. The rear hood is adjustable. Adjust it to the minimum for shredding slight ly dense vegetat ion or maximum product recycling. Adjust it to the maximum when shredding dense vegetat ion or if you want to work faster, while limit ing the power input.APPROACHING PERFECTSHREDDING:- rotor with eight rows and helical layout of tools for increased residue suct ion andperfect distribut ion over the ground;- two counter-knives for impeccable shredding;- possibility to fi t hammer knives or universal knives.WORKING HEIGHT UNDER CONTROLA BP 100 can be fi tted either with:- a roller of Ø 220 mm with removable ends that is posit ioned close to the rotor for precise ground following,- or semi-pivot ing wheels fi tted on the side walls.A FAULTLESS DRIVEThe BP 100 features:- a gearbox for tractors of maximal 175 hp,- an automat ic belt tensioning system,- three to fi ve belts depending on the model.Some models are not available in all countries. Please always check with your local dealer.A STRUCTURE TO LASTThe hitch frame design, a lasting structure of assembled parts, is especiallyrobust. As standard, the BP 100 models can be offset mechanically by 58 cm to the right. This is obtained using a sliding double tube system (one lower and one upper tube). This design reduces the machine overhang and limits stress on the hitch frame when working in offset position.The hitch pins are blocked and thus stopped from rotating. The upper link is equipped with a longhole for improved following of irregular grounds.SAVINGSWORK QUALITY20BPR 28 30THE ART OF MAINTAREASThe BPR series 10 shredder is designed for individual farms owning tractors of up to 175 hp. Its main purpose is to maintain meadows and uncultivated grassy areas. SAVINGS1 2 45 cm AINING GRASSYOwing to its front/rear mount options and lateral offset capability, it is the perfect shredder for farms with differing conditions and diffi cult-to-access corners. It is available in widths of 2.80 and 3.05 m.A ROBUST HOODThe body consists of 6 mm thick metal sheet ing for the outer struc-ture and 8 mm thick side walls.Internally, the hood is fi tted with two welded counter blades.PROVEN WORK HEIGHT SOLUTIONSThere are two rollers available for height control:- either a standard roller Ø 220 mm with fi xed ends,- or a roller with removable ends Ø 220 mm.In both cases, the roller is posi-t ioned as close as possible to the rotor for effect ive ground hugging,self-cleaning by the tools and a better decomposit ion of the residues.THE ROTOR DESIGN YOU ARE LOOKING FORThe machine is equipped with a rotor featuring eight rows of tools 465 mm in diameter.The helical layout of the tools ensures perfect suct ion of residues to be shredded and high-qualityground distribut ion of the shredded waste.ROTOR DRIVE EASY TO MAINTAINThe rotor drive includes:- a central gearbox with double input including a free wheel for tractors of up to 175 hp.- a lateral drive using four belts.For fast, easy control of belt tension, the guard is attached by a single screw.Some models are not available in all countries. Please always check with your local dealer.211. A DOUBLE-PURPOSE LINKAGEThe double attachment frame can be front or rear mounted by simply inverting the transmission.2. LATERAL OFFSETThe BPR 28/30 series provides a hydraulic lateral offset of the hitch frame of 45 cm fi tted as standard. For an increased reliability and compact machine dimensions, it is displaced by sliding it over two tubes guided on Tefl on rings.2258 cmBPRADDING VERSATILITY210 240 280 305With a reversible BPR shredder you can enjoy the benefi ts of maintaining pastures and fallow land But it will also enable you to shred crop residues. When in frontal position, the tractor does not drive over the plants providing smoother shredding action. A BPR fi ts all tractors: It is coupled at the front or back. Work can also be done with a front and back combination including the KUHN verge mainte-nance equipment or hedge and grass cutters.SAVINGSA FAULTLESS DRIVEThe BPR 100 features: - a gearbox for tractors of up to 175 hp, - an automat ic belt tensioning system, - three to fi ve belts depending on the model.PERFECT GROUND FOLLOWINGFor controlling the working height, the BPR 100 features a 220 mm Ø roller with removable ends for an easier maintenance. It is posit ioned closest to the rotor to ensure:- perfect ground following,- self-cleaning of tools,- easy rolling in all situat ions.OFFSET BY SLIDING MOVEMENTThe sliding offset of 58 cm allows it to reach the most diffi cult to access corners. The BPR 100 models are equipped with a hydraulic offset as standard.23EFFECTIVE ROTORThe rotor with eight rows of tools effi cient ly sucks up the residues to be shredded, also those pressed against the ground, for irreproachable shredding quality.SHREDDING CASING:LONGER LIFEThe standard model of shredding casing isreinforced by a 4 mm lining for longer service life, and it is equipped with two counter blades (one notched and one smooth) for fi neshredding.A PIVOTING HOOD FOR MOST WORKING CONDITIONSThe pivot ing hood provides greater versat ility. It can be adjusted according to the quant ity and type of plants to be shredded.Some models are not available in all countries. Please always check with your local dealer.HIGH-QUALITY SHREDDINGWORK QUALITYBPR 280 PRO 305 PRO24 HIGH OUTPUTS FOR CONTRACTORS AND LARGE FARMSFront-mounted BPR 280 and 305 PRO shred-ders are the ideal partners of rear BP 8300 large-width shredders, the BPR 280 PRO is addit ionally for use with the BP 8340. Ident ical tools, tool holders and number of counter-knives make a homogeneous shredding work possible.SAVINGSFIT A BPR 100 PRO IN FRONT FOR POWERFUL COMBINATIONSBPR 100 PRO models, available in widths of 2.80 and 3.05 m, can be easily attached to the front or rear. It has been specifi cally designed for intensive use with high horsepower tractors with its powerful gearbox and a higher attachment than the BPR 100. It is intended to shred everything from grass to crop residues and cover crops.25Some models are not available in all countries. Please always check with your local dealer.A VERSATILE IMPLEMENTThe BPR 100 PRO can be easily attached to the front or rear of your tractor.As the BPR 100 models, also the BPR 100 PROrange are equipped with a 580 mm hydraulicoffset as standard. The shredder slides on twotubes of 70 mm diameter, including Tefl on bushes and greaser for more reliability.DESIGNED FOR HIGH-QUALITYSHREDDINGThe 465 mm diameter rotor is fi tted with heavy hammer knives which are perfect ly adapted for shredding pasture land, cover crops and woodycrop residues. For especially fi ne shredding, the BPR 100 PRO is fi tted with two counter knives with a third available on opt ion. A pivot ing rear hood makes an adaptat ion to differentvolumes of residues possible.ADAPTED FOR INTENSIVEWORK WITH HIGH POWERTRACTORSThe BPR 100 PRO models are designed for tractors of up to 250 hp. The attachment point is raised to allow the attachment to powerful tractors. The top link remains fl oat ing to allow improved ground following. The robust lateral drive is made up of fi ve rib Powerband belts, featuring an automat ic tensioner to withstand the stresses of the most extreme working condi-t ions.26BP 8300 8340IMPECCABLE SHWhether you are a contractor or owner of a large farm, these multi-purpose BP 8300 and BP 8340 shredders are made for you. As triple combination with a BPR 280 PRO or BPR 305 PRO, the output rates are impressing at a working width of 8.30 m. Mainly designed for maintaining pastures, fallow land and grassy areas, its versatility is that it can also shred cover plants (mustard,phacelia...) as well as crop residues or maize stubbles. As no vegetation is run over by tractor wheels, residues can be easier sucked into the shredding units.SAVINGSWORK QUALITYREDDING OUTPUTHIGH-QUALITY SHREDDING RESULTSThe 465 mm diameter rotor with helical positioning of tools, combined with a body equipped with a pivoting rear hood means that the large width shredders can shred a large quantity of vegetation, even at high speed. Ejected above the press roller, the residues are not compacted, thus accelera-ting decomposition rates.RELIABLE IN MOST INTENSIVE APPLICATIONSTo cope with the most intensive jobs, these shreddersare equipped with:- a gearbox designed for tractors of up to 300 hp,- reduced maintenance SFT secondary PTO shafts,- a drive for each shredding unit using fi ve SPBX belts,- an automat ic belt tensioning device.A «PRO» STRUCTUREThe two shredding units are equipped with: - welded sheet metal lining for opt imal protect ion against wear and impact, - two counter blades for fi ne shredding (third opt ional), - a pivot ing rear hood to adaptto all types of working condi- t ions,- a press roller with removable ends 220 mm in diameter,- lateral skids, - rotor with hammer support axles (20 mm diameter) made of special treated steel.Some models are not available in all countries. Please always check with your local dealer.- Non-stop safety is combined with a shredding unit lift system to provide the machine with opt imal protect ion against obstacles when moving rearwards.- Lift system is built into the frame for easy manoeuvring.The results: perfect shredding and reduced costsA SHREDDER WITH WEIGHT REDUCTION AND NON-STOPSAFETYThe BP 8300 and BP 8340 have a frame which is unique on the market. It is equipped with LIFT-CONTROL technologyused on the widest KUHN mowers and with characterist icswhich are exclusive on a shredder.In detail:- Pendulum type art iculat ion on both shredding units for excellent ground hugging.- The shredding units are equip-ped with a weight-reduct ion system reducing stress on the roller.EXCLUSIVE BP 8340: IN REVERSE DRIVEThe new reverse drive version combines the exceptional productivity and superior shredding quality of the BP 8300 with increased user comfort. This is due to an easier attachment and improved visibility whiledriving. Monitoring all three shredding units at once is no problem.NEW27WORK QUALITY28KUHNSeries BK BC 10 RM RM R RMS 820 WS 320 BIOType of linkage rear front or reverse driveMain applications fallow land, intermediate cropsand crop residues intermediate crops and crop residuesharvest ofenergy cropsRecommendedtractor power min/max (hp)70-190 80-360 300-450 150-300Working width (cm/ft)230 - 280 - 320 /7´6´´ - 9´2´´ - 10´6´´240 - 270 - 300 /7´9´´ - 8´8´´ - 9´10´´240 - 280 - 320 - 400 - 450 - 480 - 610 / 7´10´´ - 9´2´´ - 10´6´´ - 13´1´´ - 14´9´´ - 15´9´´ - 20´1´´820 / 26´9´´ 320 / 10´6´´A RANGE TO COPE WITH HIGH AMOUNTS OF RESIDUESFIELD SHREDDERSWell-shredded crop residues are a friend of you and your soil, fi ghting pests and diseases and rapidly transforming the organic matter into benefi cial humus structures. Discover the KUHN range of fi eld shredders, which provide fi ne shredding and good spreading for all necessary jobs in the fi eldRM 240 / RM 280 / RM 320 / RM 400 / RM 450:Field shredders proven worldwide on cereal farms and in machinery cooperat ives with working widths from 2.36 to 4.32 m;BC 24 / BC 27 / BC 30:Part icularly designed for shredding intermediate crops and crop residues, working widths from 2.40 to 3.00 m;BK 230 / BK 280 / BK 320:Shredder series for individual mixed crop farms with working widths of 2.30 m, 2.80 m and 3.20 m; with mobile hood for maintenance work;29RMS 820:An outstanding rigid machine for large farms with shredding width of 8.20 m and adapted to very high power tractors;WS 320 BIO:Front-mounted shredder with built-in windrower for energy crops harvest, can be used in combinat ion with baler. Two act ions in one passRM 480 R / RM 610 R:Even more work output in foldable version for easy road transport with working widths of 4.80 and 6.10 m;Some models are not available in all countries. Please always check with your local dealer.BK 230 280 32030THE ALLROUNDER FOR MIXED FARMSBK shredders are intended for mixed crop farms. Available in three working widths, 2.30 m, 2.80 and 3.20 m, they are designed for effi cient shredding of crop residues, straw, maize or sunfl ower stalks, set-aside and pasture land.THE MEANING OF EFFICIENT SHREDDINGShredding improves the decomposition of crop residues. A satisfying result is achieved, if the majority of residues is less than 5 cm long, the shredding height is uniform and the residues distributed regularly over the soil after shredding. With KUHN shredders you can count on proven solutions to achieve these requirements.IMPORTANT POINTS FOR AN INCREASED SERVICE LIFE- The coupling device ensures that the tractor/tool link is very rigid.- The free wheel is integrated in the gearbox as standard.- A double skinned hood is available on opt ion.WORK QUALITYROTOR FOR PERFECT SHREDDINGThe high linear speed combined with the high level of overlap between tools ensures high-quality shredding.Moreover, you can shred large quant it ies of residues with the large rotor diameter.SHREDDING TOOLSThe rotor is fi tted with four rows of tools to choose from:- universal knives with stubble pallets to lacerate the residues better: for stubble and cereals.- hammer knives for woodier material: maize and sunfl ower stalks, maintenance of hay fi elds.PERFECTLY CONTROLLED SHREDDING HEIGHTTwo working height control devices are available for these machines:- semi-pivot ing wheels,- roller.Wide height-adjustable skids are available as opt ion.EASY TOOL EXCHANGEThe rear hood can be lifted manually for better access to the rotor. Therefore the shredding tools can be changed in total ease.31Some models are not available in all countries. Please always check with your local dealer.MAKE YOUR LIFE EASIERLENGTHWAYS TRANSPORTThe BK 320 can be transported lengthways forpassing narrow paths and roads at ease.HYDRAULIC OFFSETBK 230 and BK 280 shredders can be fi ttedwith hydraulic offset of 40 cm to the right to shred in fi elds with obstacles: orchards, rocks, etc.LIMITED MAINTENANCEYou will benefi t from the maintenance-free rotorthanks to bearings that are greased for life. The free wheel in the central gearbox needs nomaintenance as well.COMFORTBC 24 27 3032HIGH-QUALITY SHREDDING AT AN ATTRACTIVE PRIZEThese machines are intented for shredding crop residues (maize, oilseed rape, sunfl owers), intermediate crops and grassy areas (pastures, fallow land,…). Individual cereal or mixed farms of medium size equipped with tractors up to 190 hp will take much pleasure in the BC shredders, if they are looking for a superior cost/performance ratio.AGGRESSIVENESS OF THE NEW GENERATIONThe BC models are equipped with new generat ion rotors with long tools, which work very aggressively to shred really every kind of residue. The rotor has a diameter of 680 mm for shredding high volumes and tough residues. A high rotat ion speed and the tried and tested helical layout of the tools also contribute to a high-quality work.WORK QUALITY33A DRIVE THAT LASTS AND LASTS…The power transmission is opt imized as the rotor is driven by 2 x 2 rib Powerband belts. You will also benefi t from the simplifi ed belt guard with a single bolt in response to new machinery regu-lat ions (bolt incorporated into the guard).AT HOME ON IRREGULAR TERRAINThe work height is controlled either by two semi-pivot ing wheels fi xed on the casing or by a roller (220 mm) with removable ends adjustable to six posit ions.ROBUSTNESS MEETS WORK QUALITYAn outer casing with 5 mm walls, a 8 mm side casing and rear beams to st iffen the structure: Robustness is not an empty word when talking about this machine. With its round profi le it is also designed for high volumes of residues. Some models are not available in all countries. Please always check with your local dealer.RM RRM FIELD SHREDDERSDESIGNED FOR INTENSIVE USESAVINGS RELIABLE HECTARE AFTER HECTAREThe RM shredders have proven themselves in the fi eld for years, as did their casing that is except ionally robust. The secret: It´s made up of three large sect ion beams and can therefore resist the most diffi cult condit ions. For addit ional protect ion against stones all RM models are fi tted with a 4 mm bolted sheet metal lining.34The RM shredders with horizontal axis, both rigid and foldable, are adapted for shredding crop residues such as cereal straw, sunfl ower or corn stalks, but also for the maintenance of pastures and meadows. Still, the main areas of operation will be on cereal farms, in machinery cooperatives or for contracting work.THREE CRITERIA FOR IMPECCABLE SHREDDING QUALITYA large diameter rotor, a suffi cient overlap between the tools and a high linear tool speed: Those are the three most impor-tant things to think of when designing a shredding rotor. KUHN meets these criteria with its rotors, adding also the helical tool layout in order to increase the suction for an impro-ved cut and to distribute the residues evenly. 351 2CONTROL THE SHREDDING HEIGHTThe shredding height is adjusted either by:- pivot ing wheels adjustable in height and laterally for shredding crop residues,- or by a roller for management of set-aside land and grass land.For improved contour following, the 3-point linkage is in “fl oat ing” posit ion.A TOOL FOR EACH NEED2. A CLEAN CUT FOR THE MOST LIGNEOUS PLANTSThe hammer knives are adapted for shredding grass, maize or sunfl ower stalks.1. FINE SHREDDING OF ALL TYPES OF PLANT RESIDUESThe universal knives with stubble pallets will lacerate the residues for faster decomposit ion. They also provide an improved suct ion especially of lodged crops into the hood.WORK QUALITYSome models are not available in all countries. Please always check with your local dealer.RM36240 280 320 400 450RIGID VERSIONS FOR MORE COMFORTIN DIFFICULT CONDITIONSA DRIVE ADAPTED TOHIGH POWERThanks to their double drive, the power transmission on RM 320, RM 400 and RM 450 models is better distributed to the drive components. FOR AN EASY TOOL EXCHANGEThe rear hood can be lifted manually for easier access to the rotor for maintenance.Therefore the shredding tools can be changed in total ease.FOR MORE COMFORT DURING TRANSPORTFor road safety, some RM shredders (depending on the width) can be transported lengthways. The machine does not exceed the tractor width.RM shredders are used on many farms worldwide. Their reputation is the best proof of their strength and shredding quality. The rigid versions are available in workingwidths from 2.40 to 4.50 m.A SINGLE ROTOR OF 4.50 MThe RM 450 shredder is a single rotor machine. That means 4.50 mworking width without non-shredded areas for an uncompromised quality of workEXCLUSIVECOMFORT37RMSome models are not available in all countries. Please always check with your local dealer. TOTALLY SAFE ON THE ROADThe two shredder units fold and unfold hydraulically and lock in place for total safety during transport.Light ing and signalling belong to the standard equipment.480 R 610 R CENTRAL STRIP MANAGED EFFECTIVELYTo reduce the central strip to aminimum, we have opt imized the suct ion at the centre of the machine.To reach this goal:- the fl ux of residues is directed into one of the units,- long tools have been mounted at the rotor´s centre,- the number of tools is increased in this area and a divider share has been fi tted.With the foldable RM R range, an exceptional work output is sure when shredding with these sturdy machines of 4.80 and 6.10 m working width Thanks to their hydraulic folding, travel time between fi elds is also limited.HIGH RESISTANCE TOSTRESSThe main frame is made up of heavy profi les that ensure good rigidity and mechanical strength.Moreover, each half shredder is fi xed to the main frame with a bushed pivot pin that cannot rotateand therefore prevents the whole attachment from wear.FOLDABLE VER-SIONS FOR MORE PRODUCTIVITYCOMFORTWORK QUALITY38RMS 820AN OUTSTANDING SHREDDER FOR LARGE CEREAL FARMSSome basic numbers about this shredder already speak for itself:- working width of 8.20 m,- licensed for high-power tractors up to 330 hp,- with a weight of 6600 kg.This is the right shredder for extra-large surfaces that are shredded intensively, exposingthe machine to high loads and strains.Apart from that you can count on the familiar KUHN assets as a large-diameter rotor withhelical tool layout and high tool speeds for superior shredding quality. The shredding height is controlled by four pivoting wheels. 391 2Some models are not available in all countries. Please always check with your local dealer.2. A ROBUST ROTOR DRIVEThanks to their double drive, the power transmission distribut ion to the drive components is improved. At each side the rotor is driven by six SPCX high-capacity belts, which are fi tted with an automat ic tensioning device.1. A STURDY CHASSISThe welded chassis is made up of four beams for increased rigidity: one front, one upper, andtwo lower beams. Also the structure components are very thick and an interchangeable sheet metal lining is bolted to the chassis. PRACTICAL AND SAFE TRANSPORTFor a machine of this size innovat ive transportsolut ions have to be found. On the RMS 820 both the hydraulic transport device and the hydraulic drawbar are fi tted with double act ing cylinders with pilot-operated valves. Both safe and pract icalSAVINGSCOMFORTIT´S ALL ABOUT RELIABLE MACHINES WHEN THEY SHOULD EAT UP THE HECTARESWS 320 BIONOT ONLY SHREDDING, BUT HARVESTINGThe WS 320 BIO is a specialised energy crop shredder designed also for harvesting crops. It can work in combination with a baler - an absolute innovation on the market. It is front-mounted with a built-in windrowing device designed for harvesting bioenergy crops with a high volume, such as Miscanthus, Switchgrass, Sorghum and Arundo Donax. The aim is to work in combination with a baler in order to reduce the number of passages and tools. That means only one driver is needed to shred, swath and bale the cropThe shredder can also be driven in reverse drive.40CONVINCING ADVANTAGES OVER CURRENT HARVESTING SYSTEMSWhen compared to self-propelled forage harvesters or mowing and baling in separate steps, the WS 320 BIO stands out with following assets:- only one person necessary for the entire harvesting process;- simpler transport logistics;- less space needed for storage of bales especially if baled with a high-density baler into square bales;- reduced fuel requirements;- less soil compaction due to less passages of large machines over the fi eld.41ADAPT SHREDDING FOR CROP HARVESTThe rotor speed is reduced to receive shredding lengths of more than 15 cm. Only then they are able to be baled. If you need fi ner shred-ding, we recommend the use of a shredder on the baler. The roller can be adjusted to provide the desired cutt ing height, from 4 to 15 cm.EASY GRASPFor a better grasp of the crops, which are generally tall and dense, the shredder has a hydraulically adaptable front cover and reel. The WS 320 BIO is suitable for all types of vegetat ion with high volumes. It can even work in diffi cult condit ions with lodged crops.Some models are not available in all countries. Please always check with your local dealer.ONE PASSAGE, THREE OPERA-TIONSWindrowing is provided by a worm screw attached behind the rotor. This is driven by a hydraulic motor connected direct ly to the tractor. Rotat ion speed can be adjusted to adapt to the working condit ions (quant ity of material, forward speed). The shredded product is discharged uniformly via a central opening at the back of the shredder. This avoids crushing by the tractor wheels. Baling, in combinat ion or not, will be all the easier.42Standard grassGrass in diffi cult condit ions (stony,…)Grass and wood residues (vine shoots, cut wood)Standard undergrowthClearing, woody crop residues in place (stubble)Field crop residue (maize seed, wheat straw,…): increased suct ion effectGrassGrassHAMMER KNIVESGrass/wood/woody residueUNIVERSAL KNIVESUndergrowth/crop residueARTICU-LATED SCOOP FLAILSARTICU-LATED SCOOP KNIVESHammer knivesArt iculated hammer knivesHeavy hammer knivesLong hammer knivesUniversal knivesUniversal and straight knivesUniversal knives with stubble palletsA specifi c rotor*Art iculated scoop knivesAGRICULTURAL AND LANDSCAPE SHREDDERSCHOOSE THE Assembly possible at the factory*Not possible to fi t other tools Contact KUHN PARTSAssembly not possibleType Residue ToolFallow land, woody crop residues43RIGHT TOOLTL BE BKEBKE REVBP 10VKM BP 100 BPR 10 BPR 100 BPR 100PRO-BP 8300BP 8340WS 230 BIOBC BK-RMRM-RRMSMaintenance, green spaces and landscapeSHORT TOOLS For grass and multipurpose shredders (with low and medium casing)LONG TOOLSFor crop shredders (with high casing)Multipurpose CropsOther uses (biomass, bioenergy, …)44KUHN foundries and forge as well as a high-level manufacturing process allow the product ion of spare parts to defy t ime. You can truly rely on our know-how and our genuine parts. Farmers benefi t from our client support and logist ics services via any KUHN PARTS warehouse, which provide quick and reliable repair solut ions in cooperat ion with your nearest authorized KUHN dealer.DESIGNED AND MANUFACTURED TO RIVAL TIMEKUHN PARTSbe strong, be KUHNTechnical specifi cations GRASS shreddersTL BE BKE BKE REV120 - 150 - 180BE 14 - 16 - 18 - 20 150 - 180210 - 230 - 250 150 - 180210 - 230 - 250Working width (m/ft)1.19/3´11´´ -1.46/4´9´´-1.78/5´10´´1.40/4´7´´ -1.60/5´3´´ -1.80/5´1´1´´ -2.00/6´7´´1.53/5´1´´1.80/5´9´´2.14/7´2´´ -2.29/7´5´´ -2.50/8´2´´1.53/5´1´´1.80/5´9´´2.14/7´2´´ -2.29/7´5´´ -2.50/8´2´´Transport width (m/ft)1.35/4´5´´ -1.60/5´3´´ -1.92/6´4´´1.55/5´1´´ -1.75/5´9´´ -2.00/6´7´´ -2.20/7´3´1.71/5´6´´ -1.99/6´5´´2.36/7´7´´ -2.51/8´2´´ -2.71/8´9´´1.71/5´6´´ -1.99/6´5´´2.36/7´7´´ -2.51/8´2´´ -2.71/8´9´´PTO speed (min-1) 540 540 / 1000 540 540 / 1000Recommended tractor power(kW/hp) 11-26 / 15-39 29-48 / 40-65 29-81 / 40-110Attachment 3-point, cat. 13-point, cat. 1 (14/16)3-point, cat. 1 or2 (18/20)3-point, cat. 1 (150)3-point, cat. 1 or2 (180)3-point, cat. 23-point, cat. 1 (150)3-point, cat. 1 or2 (180); front orrear3-point, cat. 2;front or rearLateral offset (mm/in)no offset (120) -280/11´´(150/180)280/11´´ (14/16) -450/18´´ (18/20)350/14´´ -450/18´´ 455/18´´350/14´´ -450/18´´455/18´´Free wheel (integrated in the gearbox)Rotor drive 2 SPA belts 3 SPBX belts(2 on BE 14) 3 SPBX belts 4 SPBX belts 3 SPBX belts 4 SPBX beltsRotor diameter (mm/in) 366/14´´ 374/15´´ 425/17´´ 450/18´´ 425/17´´ 450/18´´Rotor speed (min-1)PTO 540 min-1 2309 2281 2203 1833PTO 1000 min-1 - 2339 - 1961Linear speed of tools(m/s)PTO 540 min-1 44.2 45.6 49 51.8 41 43.1PTO 1000 min-1 - 46.6 - 44 46.2Number of art iculated scoop knives 24 - 30 - 36 -Number of hammer knives - 16 - 20 - 24 - 28 18 - 20 24 - 26 - 28 18 - 20 24 - 26 - 28Number of universal Y-knives - 36 - 40 48 - 52 - 56 36 - 40 48 - 52 - 56Counter blade (smooth, welded) (smooth, bolted)Side skids - Height adjustment by roller by roller withfi xed ends by semi-pivot ing wheels or roller by rollerRoller diameter (mm/in) 90/3.5´´ 160/6´´Tyres - 6.5 x 50 8 ply -Weight with equipment (kg/lbs)150/330 -185/407 -205/452330/728 -370/816 -420/926 -460/1014470/1036 -580/1278660/1455 -690/1521 -710/1565470/1036 -580/1278660/1455 -690/1521 -710/1565 standard opt ion - not available45Some models are not available in all countries. Basic and optional equipment vary according to the country. Please check with your local dealer.Technical specifi cations MULTIPURPOSE shreddersVKM BP BPR BP210 - 240 -280 - 305 28 - 30240 - 280 -305 28 - 30210 - 240 -280 -305280 PRO -305 PRO8300 - 8340Working width (m/ft)2.09/6´10´´ -2.37/7´8´´ -2.79/9´2´´ -3.03/9´11´´2.79/9´2´´ -3.03/9´11´´2.37/7´8´´ -2.79/9´2´´ -3.03/9´11´´2.79/9´2´´ -3.03/9´11´´2.09/6´10´´ -2.37/7´8´´ -2.79/9´2´´ -3.03/9´11´´2.79/9´2´´ -3.03/9´11´´ 8.30/27´3´´Transport width (m/ft)2.25/7´5´´ -2.55/8´4´´ -2.99/9´9´´ -3.21/10´6´´2.96/9´8´´ -3.19/10´6´´2.68/8´8´´ -2.99/9´9´´ -3.34/10´11´´2.96/9´9´´ -3.19/10´6´´2.26/7´5´´ -2.68/8´8´´ -2.99/9´9´´ -3.34/10´11´´2.99/9´9´´ -3.34/10´11´´ 3.00/9´10´´PTO speed (min-1) 540/1000 1000Recommended tractor power (kW/hp) 51-129 /70-17559-129 /80-17551-129 /70-17559-129 /80-17559-184 /80-25059-184/80-250110-220 /150-300Attachment3-point, cat. 2 -fi xed orfl oat ing3-point, cat. 2 3-point, cat. 2 - front or rear -fi xed or fl oat ing3-point, cat. 2or 3 - front orrear - fi xed orfl oat ing3-point, cat. 2or 3Lateral offset (mm/in)520/20.5´´(210) -580/22.8´´450/17´7´´ 580/22.8´´ 450/17.7´´520/20.5´´(210) -580/22.8´´580/22.8´´ -Free wheel (integrated in the gearbox)Rotor drive (SPBX belts) 3 - 3 - 4 - 4 4 3 - 5 - 5 4 3 - 3 - 5 - 5 5-strandPowerband 5 + 5Rotor diameter (mm/in) 465/18.3´´Rotor speed (min-1)PTO 540 min-11960 (210/240) - 1833 (280/305)1833 - -PTO 1000 min-1 1960 (280/305) 1960 1870 2052Linear speed of tools (m/s)PTO 540 min-148 (210/240) - 44 (280/305)44 - -PTO 1000 min-1 48 (280/305) 48 46 50Number of hammer knives 22 - 24 - 28 - 32 28 - 32 24 - 28 - 32 28 - 3222 - 24 - 28 - 32 28 - 32 64Number of universal knives 44 - 48 - 56 - 64 - 48 - 56 - 64 56 - 6444 - 48 - 56 - 64 -Number of fl ail knives - 54 - 60 - 72 - 78 -Counter blades (1 smooth, 1 bolted)3rd counter blade -Side skidsHeight adjustmentsemi-pivot ingwheels orroller withremovableendsroller withfi xed orremovableendsroller withremovableends orpivot ingwheelsroller withfi xed orremovableendsroller with removable endsRoller diameter (mm/in) 180/7´´ 220/9´´Tyreswheels with non-adjustable track 185/70 R13- 185/75-15 -wheels with adjustable track145-10(210/240) -185/70 R13(280/305)Weight with equipment (kg/lbs)870/1918 -910/2006 -960/2116 -990/2182890/1958 -920/2024820/1962 -900/1984 -950/2094990/2182 -1120/2460870/1914 -950/2090 -1020/2249 -1100/24251150/2535 -1230/2712 2630/5798 standard opt ion - not availableTechnical specifi cations FIELD shreddersBK BC RM RMS WS230 - 280 -320 24 - 27 - 30240 - 280 - 320 -400 - 450480 R - 610 R 820 320 BIOWorking width (m/ft)2.30/7´7´´ -2.80/9´2´´ - 3.20/10´6´´2.33/7´8´´ -2.69/8´10´´ -2.95/9´8´´2.36/7´9´´ - 2.80/9´2´´ -3.23/10´7´´ -4.01/13´2´´ -4.52/14´10´´4.80/15´9´´ -6.10/20´ 8.20/26´11´´ 3.23/10´7´´Transport width (m/ft)2.50/8´2´´ -3.00/9´10´´ -3.47/11´5´´2.55/8´4´´ -2.94/9´8´´ -3.19/10´6´´2.55/8´4´´ - 3.00/9´10´´- 3.48/11´5´´ -4.35/14´3´´ -4.93/16´2´´2.50/8´2´´lengthwaystransport -drawbar3.48/11´5´´PTO speed (min-1)540 -540/1000 -1000540 / 1000 1000 (540/1000 on RM240) 1000Recommended tractor power(kW/hp)51-140 /70-19059-220 / 80-300132-265 /180-360220-330 /300-450110-220 /150-300Attachment 3-point, cat. 23-point, cat.2 - semiautomat ic(fi xed onRM 240/280)3-point, cat.2 or 33-point, cat.3 or 4 -quick-hitchcompat ible3-point, cat.2 or 3 -fi xed orfl oat ingFree wheel (integrated in the gearbox)Rotor drive 4 - 4 - 5SPBX belts2+2 ribPowerband4 - 4 - 3+3 - 4+4 - 5+5SPBX belts4+4 - 5+5SPBX belts6+6 SPCX belts5-strandPowerbandRotor diameter (mm/in)620/24.4´´ -647/25´´(280-320)680/27´´647/25´´ (240-320) -703/28´´ - 730/29´´620/24´´ 730/29´´ 647/25´´Rotor speed (min-1)PTO 540 min-1 2083 (230) -1833 (280) 1833 1833 (240) - - -PTO 1000 min-1 1960 (280) -1758 (320) 19601960 - 1680 -1758 - 1392 - 15601714 1721 1117Linear speed of tools (m/s)PTO 540 min-1 67.6 (230) -62 (280) 65 62 (240) - - -PTO 1000 min-1 66.3 (280) -59.5 (320) 7066 - 57 - 60 - 51 - 60 56 66 38Number of hammer knives 26 - 32 - 36 32 - 36 - 40 28 - 32 - 36 - 44 - 52 56 - 72 - -Number of universal knives withstubble pallets 52 - 64 - 72 64 - 72 - 8056 - 64 - 72 - 88 - 104 112 - 144 - -Number of universal Y-knives - 264 72Side skids -Counter blades (1 smooth, 1 notched) (1 notched) (1 smooth) -Height adjustment semi-pivot ing wheels orrollerssemi-pivot ing wheels or rollers(rigid twin wheels on trailed RM 450)4 pivot ingsupportwheelsroller withremovableendsRoller diameter (mm/in) 220/9´´ - 220/9´´Tyres 185/60-R14 7.00x12195/65-15 (240-280)195-14 6 PR (320-450)10.0/80-12 10 PR -Weight with equipment (kg/lbs)950/2094 -1100/2420 -1410/3108870/1914 -945/2079 -1030/22661195/2634 -1400/3086 -1820/4012 -2390/5258 -2720/59842600/5720 -3200/7054 6600/14550 1800/3960 standard opt ion - not available46MAXIMIZE THE USE AND PRODUCTIVITY OF YOUR KUHN EQUIPMENTKUHN SERVICESExpress spare parts service 24/7You urgent ly need spare parts? With KUHN sos order benefi t from express delivery seven days a week, 365 days a year. Thus, you can minimize machine downt ime considerably and increase your work output.The choice of professionalsBenefi t from 36 months in complete serenity because of KUHN´s protect + warranty extension. You can concentrate exclusively on your work and the performance of your machine. Because this is what you expect, when invest ing in high-tech machinery.For ever quicker repairsAn unexpected technical problem always occurs at the wrong t ime. Your KUHN dealer can support you quickly and effi cient ly thanks to KUHN i tech. With this 24/7 online service, a quick and exact diagnosis is possible.Invest rationallyNew machine necessary, fi nancing unsure? Modernize your equipment and develop your farm with KUHN fi nance, in total safety and according to your needs and demands. We offer custom-made fi nance solut ions, adapted to your requirements.* *Not all services are available in every country.Optional equipment BE 10: front or reverse drive stat ion adaptat ion kit - special varnish.Optional equipment BKE/BKE REV: adjustable skid set - sheet metal lining - pivot ing support wheels – light ing and signalling.Optional equipment VKM: hydraulically controlled offset - roller with removable ends - roller scraper - pair of support wheels fi tted on the side walls - pair of wheels - collect ing rake beam without collect ing t ines - collect ing rake t ines– light ing and signalling.Optional equipment BP 10: set of side stabilizing skids – light ing and signalling - special varnish.Optional equipment BP 100: hydraulically controlled offset - reinforced SFT S8 drive– light ing and signalling - special varnish.Optional equipment BPR 100: pivot ing front wheels - double free wheel gearbox - input shaft extension set – light ing and signalling - special varnish.Optional equipment BPR 100 PRO: pivot ing front wheels - input shaft extension set - addit ional bolted counter-blade - special varnish.Optional equipment BP 8300: addit ional bolted notched counter-blade – light ing and signalling.Optional equipment BP 8340: addit ional counter-blade.Optional equipment RM: reinforced wheels - adjustable side skids - addit ional semi-pivot ing wheels – light ing and signalling.Optional equipment RM R: light ing and signalling. Some models are not available in all countries. Basic and optional equipment vary according to the country. Please check with your local dealer.47Optional equipment1 2 3 4KUHN S.A.4 Impasse des Fabriques - BP 50060 - F-67706 Saverne CEDEX-FranceKUHN NORTH AMERICA, INC.1501 West Seventh Avenue – P.O BOX 167 - Brodhead, WI 53520 - USAKUHN FARM MACHINERY PTY. LTD313-325 Foleys road - Deer Park, 3023 Victoria AUSTRALIAKUHN FARM MACHINERY (U.K.) LTDStafford Park 7 - GB TELFORD/ SHROPS TF3 3BQFor more information about your nearest KUHN dealer, visit our websitewww.kuhn.comYour KUHN dealerwww.kuhn.comAlso fi nd KUHN onVisit us on our YouTube-channels.Some machines have a considerable weight. Respect the tractor gross vehicle weight rating, its lift capacity and maximum load per axle. The tractor front axle load must always reach minimum 20 % of the tractor net weight. Our material is produced in accordance with the European Machinery Directive in the member states of the European Union. In countries outside the E.U., our machinery complies with the safety regulations set by the country concerned. Some safety devices may have been removed from our leafl ets in order to clarify the illustration. Under no circumstances should the machine be operated without the necessary safety devices in place (as specifi ed by the assembly instructions and operators manual). We reserve the right to change any designs, specifi cations or materials listed without further notice. Machines and equipment in this document can be covered by at least one patent and/or registered design. Trademarks cited in this document may be registered in one or several countries.1. Vineyard and orchard shredders 2. Front-mounted maintenance shredders 3. Offset arm verge shredders 4. Professional-duty road-side mowers.FOR EACH USE A SHREDDERAGRICULTURAL AND LANDSCAPE SHREDDERSYou have thought that those are all shredders and mowers KUHN has to offer? There are more to discover.Recom-manded tractor power (hp)Interme-diate crops and crop residues)Fallow landPastureGrassy areasRearFrontSeriesType of linkage Grass Crops Energy crops Mult ipurposeTLBE 10BKE / BKE REVVKMBP 10/BPR 10BP 100/BPR 100BPR 100 PROBP 8300/BP 8430BK / BC 10RM / RM RRMS 820WS 320 BIO( )( ) ( )( )( )( )( )( )13 - 3540 - 6540 - 11010 - 17560 - 17580 - 25080 - 250150 - 30070 -19080 - 360300 - 450150 - 300To protect the environment, this leafl et is printed on chlorine-free paper / Printed in France - 920 760 GB - 11.13 - Copyright 2013 KUHN
