That's What You Need To Know To Start An Organic Fertilizer Production Line
Organic Fertilizer Plant
It is not a trivial matter to start an organic fertilizer factory, perhaps this is our next few years, a decade or even decades of business, so many people will consider a lot of issues. Next, we briefly introduce the organic fertilizer production line of various configurations, each link of the equipment characteristics. After understanding these, you can choose the organic fertilizer production line that suits you.
Organic fertilizer production line includes fermentation equipment, granulation equipment, crushing equipment, mixing equipment, screening equipment, cooling equipment, drying equipment, enveloping equipment, automatic packaging equipment, and other processes.
1. Fermentation Equipment Of The Organic Fertilizer Production Line
Trough throwing machine. The trough type throwing machine also commonly referred to as a rail type turning machine, a rail type turning machine, a turning machine, and so on. It can use for fermentation and dumping of organic waste such as livestock and poultry manure, sludge garbage, sugar mill sludge, slag cake, straw sawdust, and so on. It widely used in organic fertilizer plants and compound fertilizer plants. The utility model comprises a walking fermentation tank body, a walking track, a power taking device, a turning over pile part, and a turning device.
2. Crushing Equipment
New semi-wet material crusher. The semi-wet material crusher is a professional crushing high humidity and multi-fiber material equipment. The semi-wet material crusher mostly used for crushing bio-fermentation and high-humidity materials such as bio-organic fermentation compost, urban domestic garbage compost, grass mud carbon, rural straw garbage, industrial organic waste, cultured livestock poultry manure, and so on.
3. Mixing Equipment
Horizontal mixer. When the horizontal mixer is working, the material in the machine subjected to the action of two rotors in opposite directions, and doing the compound motion. The blade drives the material to rotate counterclockwise along the inner wall of the machine slot, and on the other hand, the material turned left and right, the two rotors cross and overlap form a weightless zone. In this area, no matter the shape, size, and density of the material, it can float to the surface in a state of instantaneous weightlessness. This makes the material in the machine tank form an all-round continuous cycle of turning, interleaving shear, so as to achieve a quick and gentle mixing uniform effect.
4. Conveying Equipment
Movable belt conveyor, fixed belt conveyor, and so on, this is relatively easy to understand.
5. Granulating Equipment
Disc granulator (also known as the ball disc) is a volumetric measurement of feeding equipment, it can be evenly and continuously feed the material to the next process, and can withstand the greater warehouse pressure. As a fine grain material feeding equipment, it is suitable for transporting all kinds of non-viscous materials in the form of powder, cement, clinker, limestone, shale, gangue, clay, and so on.
6. Drying Cooling Equipment
Rotary dryer also is known as a drum dryer, biological organic fertilizer dryer, because the temperature of organic fertilizer drying can not exceed 80°, so our dryer adopts hot air drying mode.
Rotary cooler also known as rotary drum cooling machine. Cooling of a certain temperature and particle size in the production of compound fertilizer. It can greatly improve the cooling speed, reduce the labor intensity, and increase the yield, then further remove some water and reduce the grain temperature of compound fertilizer. At the same time, the cooling machine can also use for other powder, granular material cooling. The cooling machine has a simple structure, good stability, and reliable operation. Similar in appearance to a dryer, but different in material and performance. Dryer host adopts boiler steel, cooling machine host adopts carbon steel customized.
7. Screening Equipment
Rotary screening machine is a common equipment in the production of organic fertilizer and compound fertilizer. It mainly used for the separation of finished products and returned materials, but also to achieve the classification of finished products, so that the finished products uniform classification. The combined screen is used for easy maintenance and replacement. This machine has a simple structure, convenient operation, and stable operation
8. Envelop Equipment
Granule enveloped machine. The main machine appearance is similar to the dryer and cooling machine similar, but the internal structure is very different. Complete equipment of rotary envelop machine composed of screw conveyor, agitator, oil pump, main engine, and so on. Powder or liquid coating process can effectively prevent the caking of compound fertilizer, which is an effective special equipment for compound fertilizer.
9. Automatic Packaging Equipment
Automatic quantitative packing scale designed for quantitative packing, including double bucket packing scale and single bucket packing scale. Adopt integrated structure, small scale height, compact structure, energy-saving and efficient, otherwise, novel appearance, simple installation, and easy maintenance.
Hope this article can help you to know more about the organic fertilizer production line. If you want to build the organic fertilizer plant, please contact us.
