BBA Pumps - Model BA160L D420 High Flow -8 Inch (PTO) Tractor-Driven Pump
This 8 inch (PTO) tractor-driven pump is designed to allow you to invest responsibly in emergency pumps with a low utilisation rate. Tractors with PTO are available anytime and anywhere in the world to drive the pump in case of emergency. With the BA160L, you have a large pump capacity on standby without requiring much storage space. The pump is equipped with a vacuum system for quick suction without first having to fill the pump housing with water.
- For pumping dirty water
- Required PTO power 50 kW
- Pump flow up to 620 m³/h (10 m³/min)
- High pump efficiency for low operating costs
- 4 years BBA Pumps limited warranty
The BA160L is an 8-inch BBA Pumps centrifugal pump with enclosed impeller and adjustable wear plate. The large free passage is unparalleled at 80 x 65 mm, making this a real dirty water pump. Best-in-class pump efficiency and an excellent NPSH curve lead to an ultra-performing unit. Other standard features are large inspection covers, suction and pressure gauges and a heavy duty bearing frame with an extra oil chamber for dry running.
Featuring a fully automatic priming system, the BA series pumps quickly prime and re-prime, even from dry conditions. A genuine BBA Pumps priming system includes a diaphragm vacuum pump, a check valve on the discharge side and a float box for air-water separation on the suction side.
- Normalized lifting hitch
- Forklift pockets
- Working lights
- 2 jack stands
- Safety cones
- Rear lighting
- Discharge x Suction; 8" x 8"
- Max. flow; 620 m³/h
- Max. head; 29 mwc
- Free passage; 80 x 65 mm
- Priming system; MP50 (50 m³/h)
- Max. speed; 1000 rpm
- Frame; with 2 jack stands
- Dimensions L x W x H; 2010 x 1122 x 1587 mm
- Dry weight; 1140 kg
- Required power; 50 kW
