Lydite - Model BY-AD150 -auger machine BYS series auger for backhoe tractor excavator
MORE COMPACT DESIGN LESS MAINTENANCE No compromise in quality, gears are precision machined from a high grade alloy steel, specifically formulated for the manufacturing of high performance gears to ensure the more lifetime and less maintenance .Compact design allows for greater length under the drive for augers or pile installation. DESIGN AND DEVELOPMENT Beiyi utilizes advanced 3D modeling software, finite analysis, cyclic testing, and extensive in field testing to ensure a product that performs, day in and day out. 2 PIECE SHAFT DESIGN The shaft is a separate component to the planetary carrier, isolating the planetary gears from the pushing, pulling and bending forces generated by the machine. For more information, you could view wxbychina@163.com www.wxbychina.com http://www.wxbychina.com/Contact/Most popular related searches
| Model | Unit | BY-AD60 | BY-AD80 | BY-AD150 | BY-AD200 | BY-AD300 |
| Excavator Application | T | 2-6T | 6-15T | 15-20T | 20-25T | 25-40T |
| Torque | Nm | 1094-4117 | 2570-9961 | 5307-20998 | 8314-30393 | 27198-59403 |
| Pressure | Bar | 80-240 | 80-240 | 80-260 | 80-260 | 160-350 |
| Flow | Lpm | 25-92 | 40-150 | 80-170 | 80-170 | 100-250 |
| Rotate speed | Rpm | 30-68 | 20-48 | 15-48 | 12-26 | 10-22 |
| Output shaft | mm | 65Rnd | 75Sq | 75Sq | 75Sq | 110Sq |
| Weight | kg | 110 | 115 | 200 | 298 | 721 |
| Max Auger Diameter clay/Shale | mm | 300 | 800 | 1100 | 1200 | 1500 |
| Max Auger Diameter Earth | mm | 500 | 1000 | 1500 | 1600 | 2000 |
