Huida Tech - Model HD408 - Autopilot Navigation
Most popular related searches
rice transplanting
agriculture machine
crop protection machine
crop protection
transplanting system
automated transplanting system
harvesting operation
agriculture drive
agriculture system
tractor harvesting
Continuous Work
Unrestricted by visibility, continuous work, improvingthe efficiency of agricultural machinery operations.
Raise The Efficiency Of The Landing Use
Intelligent planning of operation paths, centimeter-level precision controlreducing heavy and missed tillage, and maximizing land utilization.
Reduce Labor Intensity
Excessively reduce the attention on the forward path and have moreenergy to pay attention to the operating status of agricultural machinery.
Reduce Labor Requirements
Lower the driver`s technical threshold and improve the quality of work.
Modular Design
Easier to install and maintain.
Quick Installation and Calibration
HD408 is easy to install on most of agriculture machines within 30 min and calibration within 3 minutes.
RTK Base Station Precise Positioning
3km, 12km, 30km range RTK base stations are available.
Simple Operation InterfaceI
Multilingual support.
Multiple Working Mode Options
Adapt to more terrain.
Adapt to A Variety of Job Scenarios
Adapt to a variety of job scenarios.
- ±1.5cm Accuracy
- Modular Design
- Simple installation and calibration
- Automatic U-turn
- RTK cm-level Positioning
- Extensible System
Satellite Flatearth System
- Standard farmland construction
- Soil Erosion Restoration
- Slope-Terrace Reconstruction
Operation Monitoring System
- Operation Depth Monitoring
- Operating Area Statistics
- Vehicle and Equipment Management
Rice Transplanter Autopilot Steering System
- Convenient control panel
- Turn around with one key on the ground
- Reduce the number of people on board
upport the installation of leveling syetem, operation monitoring system, rice transplanter automatic driving system, agricultural machinery unmanned driving system, multi-functional portable device.
- Design features: Highly integrated, modular design
- Satellite antenna solution: Support single-antenna and dual-antenna solutions
- Controller type: Support motor steering wheel control or hydraulic control
- Working precision: ±1.5cm/km
- Operating speed range: 0.1-30km/h
- Value-added function: Position mark, real scene map operation, quick adjustment of handover line, reset point B, intelligent voice prompt, remote control control, farm tool control, plot network sharing, one-key U-turn, restoration of AB line, network diagnosis
- Work mode: AB straight line, parallel curve, diagonal rake, circular pattern, back pattern
- Model adaptation: Wheeled tractors, crawler tractors, articulated tractors, harvesters, rice transplanters, green storage machines, plant protection machines, etc.
- Job type adaptation: Ridging operation, sowing operation, film mulching operation, intertillage operation, harvesting operation, ditching operation, plant protection operation, etc.
- Work scenario adaptation: Hard ground scene, soft ground scene, sandy ground scene, slope scene, composite scene
- System scalability: Support the expansion of satellite leveling system, operation monitoring system, rice transplanter automatic driving system, agricultural machinery unmanned driving system, multi-functional portable treasure
