Azeus - Model A2S-9FYD - Hydraulic Compost Turner
Hydraulic compost turner is widely used in farms, fertilizer factories and the like for treating livestock manure, agricultural residues, rotten vegetables, fruit peel, sludge or industrial organic waste. Hydraulic compost turners can turn the waste into fertilizer for growing crops, vegetable, or mushrooms. Such kind of organic fertilizer fermentation machine is environment-friendly and sustainable.
Components of hydraulic Compost Turners
Hydraulic compost turner or compost windrow turner mainly consists of engine assembly, running system, hydraulic system, auxiliary devices and framework.
- The engine assembly adopts diesel engine which owns powerful torque and great margin of power. The cooling system is suction type and two-stage filtration device was used to protect the engine.
- he running system is dual-speed control design. Its low speed is less than 15m/min during operation which benefits to stir the materials fully. The high speed is used in turn to other working site.
- The hydraulic equipment has two hydraulic system: main hydraulic system and auxiliary hydraulic system. The main hydraulic system adopts a simple circuit containing bump, valve and motor which can control by electric hydraulic proportion to complete stepless speed regulating. The auxiliary hydraulic system applys multiple circuit which can regulate the equipment during the operation or control any action independently. The key technology during the operation is to coordinate the speeds of the running system and the turning wheel.
- As one of an auxiliary devices, the guide sleeve can regulate the running system up and down. And when you operate the organic fertilizer fermentation machine from one pile to anther, you can lift the turning wheel to surmount obstacles. Or you
can adjust the turning wheel according to the resistance and evenness of the ground. When the organic fertilizer fermentation machine begin to deal with the piles or almost finish one pile, we should lower the back shield in case of the material out of working range. But during the process, we should lift the shield to its highest for letting the material fully expose to the air and decrease the temperature.
- The framework is box-shape structure including the bridge-like platform and two lateral plates. The inner side of the hydraulic equipment is painted with anti-corrosive material.
Compared to self-propelled windrow turner, hydraulic compost turner discard traditional rail-type structure. This organic fertilizer fermentation machine is widely accepted by its high productivity, relatively small working site, powerful turning capacity, great fermentation, stable working performance and low failure rate.
Hydraulic compost turner is an effective organic fertilizer machine of electro-mechanical and air-hydraulic integration. Water can be added to piles during the process of aeration, crush, stir or turning the material; and piles after being processed are compact in the working range. The hydraulic compost turner is a powerful machine with compact structure and manoeuvrabiliy. And such a organic fertilizer machine is an indispensable and cost-effective equipment for production of fertilizer manufacturer or waste treatment plant. It has been sold to USA on 4th, Jan, 2016.
