Model Arctigo HRCD - Banana Ripening Coolers

SHARE

Arctigo HRCD banana ripening coolers have been designed for application in airbag and side curtain system ripening rooms. The coolers have been optimised for 12.5 °C air-on and 11.5 °C air-off temperature at an evaporating temperature of 7 °C. Arctigo HRCD coolers provide for an even temperature distribution throughout the whole ripening room, guaranteeing that the products ripen as evenly as possible.

Most popular related searches
banana ripening
ripening chamber
ripening
banana
ripening system
  • Coil
  • Cu ripple fin tubing ø 5/8” (smooth tubing for brine)
    Tube pitch 50 x 50 mm square
    Corrugated Alu-fins
  • 3-5 Fans 400/50/3, Ø 508 and 550 mm. Cables are led to the outside of the casing. Enclosed design spray-tight fan motors, protection class IP55. Motors are equipped with a thermal safety device in the windings, connected to separate terminals in the box.
  • Lighting integrated into the cooler casing.
  • Heater elements
  • Corrosion resistant casing material, aluminium/sendzimir, white epoxy coated (RAL 9002).
  • Hinged driptrays
  • Sufficient room for fitting the expansion valve inside.
  • Suitable for dry expansion or pumped system.
  • Delivery in mounting position. Coolers are mounted on wooden beams. Installation can take place with use of a forklift.

For a full overview of all available options and additional technical specifications please refer to the product leaflet.

Alfa LU-VE finned coil air heat exchangers have been designed to achieve an optimized exchange of thermal energy between air and a refrigerant or fluid. The ‘heart’ of our air heat exchangers is the finned coil, built up from a circuit of interconnected tube serpentines and fins to increase the heat exchanging surface. Thanks to the combination of key design variables (coil materials, coil geometry, casing design, fan type), air units are very versatile heat exchangers with a great variety of applications in many industries. Alfa LU-VE supplies finned coil air heat exchanger products for a wide variety of applications.
