Charlie - Boom Sprayer

Pump :

• Type Charlie® Triplex plunger pumping unit (Diaphragm Optional)
• Capacity 50 litter per minute (70 liter optional )
• Working pressure 40 bars or 600 PSI
• Recommended working pressure 1-10 bars or 15-300 PSI
• RPM 900

Filter :

• Capacity 60 litters/minute
• Mesh size 50 mesh
• Flush out Manually

Control Unit :

• Manifold 3 sections operated with Pressure gage, Pressure regulator valve

Boom :

• Width 6 meters / 20’ feet
• Height Adjustment Manually up to 24” inches (61 cm)
• Type Wet Boom
• Actuation Manual
• Nozzle spacing 20 inches (50 CM)
• Number of nozzles 12 nozzles
• Nozzle Tip Brand& Material Teejet® & Polymer (ceramic Optional in this model)
• Working speed 2-6 km/hour
• Extra Accessories 3 no. of nozzles tips, tip filters, Pump Kit, Tool Box, Gas Kit Etc.

Dimensions :

• Length x Width x height 53” x 88” 59” (135 x 224 x 150 cm)
• Weight 165 kg
