Brightstar - Vacuum Wood Grain Heat Transfer Machine

Powder coating and sublimation process

• This method has two processes, used consecutively, to create the look.
• Powder Coating - One of the most common types of aluminum profiles finishes.
• Sublimation - Used to imprint patterns after powder coating.
• After completing these processes you now have a replacement for wood that gives you all the benefits of aluminum extrusions.

Working function

The powder-coated aluminum profiles obtain the clear and whole pattern from wood grain film or paper when it through rated temperature, at the same time the temperature made the printing ink of organic coat sublimed then transfer to the original workpiece.

We are different

• 36 pieces vacuum nozzles wood grain effect heat transfer machine for aluminum profile
• Single piece vacuuming type
• The machine is equipped with a vacuuming device at both ends of the charging slaps.
• The vacuuming is applied during continuous production.
• When aluminum profile is discharged, the blow air pump is used to blowback to take off the wood grain paper.
• Continuous production, high production efficiency and high output.
• The charging skips, made by profile steels, moved into the oven through the track by transmission motor.
• When the heat transfer temperature and time were completed, the furnace door will be lifted automatically, the charging slaps will move into and out of the oven.
• Production processes
• Aluminum profile pretreatment— Powder-coated— Wood grain film—Vacuumizing—Heating transfer—Film removal—Inspection—Packaging and warehouse—Delivery

• Total power about i6kw (for Gas or Oil), For Electricity, about 100KW.
• Single piece vacuuming, 36 pieces vacuum nozzles, max 36 pieces aluminum profiles up to profile shape and dimensions
• Wood grain paper or wood grain film
• Heating transfer temperature: i6o°C-200°C
• Heating timeno-15 minutes
• Max processing size for aluminum profile: L7000mm*W200mm*H200mm
• Can be customized according to the request.
