Altagri - Model 600 Lt. - Canon Type Turbo Atomizers with Membrane Pump

Turbo Atomizer mounted to the tractors through three point linkage system.  Needed pressure for spraying, provided by membrane pumps. Pump is powered by throughout a rod by tractor PTO. Used standard pump. Used fiberglass tank or polyethylene tank. Turbo Fan is powered by troughout a rod by tractor PTO and provides compressed air around it. Fans are operated by belt – pulley system with one speed. Fans have ungear system for spraying without air compressure. Spraying made by adjustable beam angle spraying nozzles and different size of nozzle head hole. Spraying to left – right or two sides is possible with control valves. 1 water suction apparatus from stream of water to make easier fill up your tank.
