Futura LOGIKA - Central Discharge System

SHARE

Logika Central Discharge can efficiently grade and sort any fruit and vegetable. Thanks to its simplicity, durability and low maintenance costs, Logika is the ideal partner for your business. Infact, it offers the possibility to work with a number of lines that can vary from 2 to 8 (in pairs). The optimal filling rate of our trolleys, which is up to 90-95%, guarantees a very high production capacity. Like any grading system by Futura, Logika Central Discharge caters to a wide range of needs. The flexibility of this line, the attention to the details and the high-quality materials employed ensure a top-quality performance and the gentlest handling of your fruits.

Most popular related searches
fruiting vegetable
bell pepper
citrus fruit
peach
motor grader
pepper
avocado
fruit sorting
apple
mango

Like all of our grading systems, Logika Central Discharge can be adjusted to your needs.

The flexibility of this line, the attention to the details, the high-quality materials and the advanced technologies employed ensure a top-quality performance and the most gentle handling of your fruits.

  • SUPPLY : Synchronized feeding through pre-aligning, V shaped conveyor belts
  • LINE FILLING : Automatic singulation system that offers an optimal line filling (up to 90%), even with non-spherical products such as flat peaches, avocados, bell peppers etc…
  • NUMBER OF LINES : From 2 to 8 grading lines
  • TROLLEYS : Range of trolleys suited for every kind of fruit/vegetable
  • ROLLERS : Range of rollers suited for every kind of fruit/vegetable
  • FOOD CERTIFIED : Certified food contact materials
  • ACCURACY : Reading of minimum, maximum and medium weight. Medium accuracy +/- 1 gr.
  • GRADING TYPE : Optical reading of diameter, colour, shape and volume
  • GRADING PARAMETERS : Weight, Diameter, Colour and External quality
  • WORKABLE PRODUCE : Apples, Pears, Citrus Fruits, Peaches, Flat Peaches, Mangos, Apricots, Avocados, Dragon Fruits, Kiwis, Persimmons, Dates, Plums, Melons, Pomegratanes, Tomatoes, Garlic, Onions, Bell-Peppers, Potatoes.
  • TROLLEYS PITCH : 76 mm, 95 mm, 114 mm , 152 mm
  • ROLLERS PITCH : 76 mm, 90 mm, 114 mm
  • NUMBER OF WORKING LINES : 2, 4, 6, 8
  • WORKING : From 12 to 15 fruits/sec/line
  • TYPE OF DISCHARGE : CENTRAL on a belt by the use of brushes or flaps.
