Peterson - Model 5900E - Disc Chipper
The Peterson 5900E disc chipper produces high quality paper chips when used with a Peterson 4800F debarker, or fuel chips as a stand alone fuel wood chipper. The 5900E is powered by a Caterpillar C18, Tier III, 765hp (570kW) engine, which is both fuel efficient and maintenance friendly. The 5900E can be configured with a three or four pocket disc, with several optional sheave sizes to make precisely the chip you need. Chipping production rates from 60 to 100 US tons (54 431to 90 718 kg) can be achieved depending on chip size. The productive 5900E’s large feed throat can accept up to 23 inch (58 cm) diameter trees or multiple smaller stems.
Servicing the 5900E is accessible from the convenient platforms around the engine and chipper. The chipper disc is directly driven from a high-capacity PT-Tech hydraulic clutch and belts. This avoids the maintenance of a gear box. Since 1981, Peterson has specialized in the developing of delivery and processing equipment that turns low-grade organic materials into high value products.
The 5900E’s large infeed target makes feeding easy
The 5900E’s parallel wall feed throat stabilizes logs. Direct drive feed rolls mean no chain and sprocket wear, nor is there ever need for adjustments.
Two chipper disc and knife systems available
Peterson disc chippers come with three or four pocket, 66” (167 cm) diameter chipper discs with traditional babbitted knife systems, or Key Knife™ .
IQAN Operating System
The robust and reliable IQAN operating system is easy to use and is weatherproof for the most extreme environments, providing self-diagnostics and engine and system parameters.
The 5900E with a top load spout.
The 5900E with an end load spout.
Dimensions (Long spout, shown in travel position)
Travel Length 28`-11" (882 cm)
Travel Height 13`-7" (414 cm)
Operating Width 22`-1 3/4" (675 cm)
Operating Length 33`-0" (1006 cm)
Operating Height 17`-3" (526 cm)
Front to 5th Wheel18" (46 cm)
5th Wheel to Center Axle 18`-10 1/2" (575 cm)
5th Wheel to Rear Axle 23` (700 cm)
Axle Spacing 49" (125 cm)
Kingpin to Rear Bumper 26` (792 cm)
5th Wheel Height 4`-1 1/2" (125 cm)
Dimensions (Short Spout, not shown)
Travel Length 31`-3" (952 cm)
Travel Width 9`-6 3/4" (291 cm)
Travel Height 13`-7" (414 cm)
Front to 5th Wheel 18" (46 cm)
5th Wheel to Front Wheel 18`-10 3/4" (575 cm)
5th Wheel to Rear Wheel 23` (700 cm)
5th Wheel to Rear 26`- 1/4" (793 cm)
Front Height 4`-1 1/2" (125 cm)
Weight/Axle/Suspension
Total Weight (approximate) 46,600 lbs (21 133 kg)
5th Wheel Weight (approximate) 17,400 lbs (7890 kg)
Tandem Axle weight (approximate) 29,200 lbs (13 243 kg)
Wheel Base (2 axle) 23` (701 cm)
Chipper
Chipper Disc Three pocket, 66" (167 cm) diameter, standard
Chipper Sheave 53" (134 cm) diameter, standard
Knives Standard three knife configuration
Chip Chute Side loading with hydraulic fold cylinder
Discharge Hydraulic swivel discharge spout
Dirt Separator Removes contaminants, overs, fines and slivers
Powertrain
Engine Caterpillar C18, Tier III
Horsepower 765 hp (570 kW)
Clutch PT Tech HPTO14FX
Fuel Tank Capacity 300 gallon (11 35 L)
Hydraulic Tank Capacity 110 gallon (416 L)
Auto Reversing Fans
Feed System
Floating Upper Direct Drive Feed Roll
Direct Lower Feed Roll 23" (58 cm) Feed Opening
Feed Speed Range Up to 155 ft/min (47 m/min
Chip Size Range 1/4 to 1" (6-25 mm)
Controls
Peterson Adaptive Control System (IQAN), Optional wireless link with Peterson flail
Optional Equipment
Four Pocket Chipper Disk , Chipper Knives (Babbitt or Key Knife™ ), 40", 60", 65" (102, 152, 165 cm) diameter Chipper Sheaves, Auxiliary Air Compressor, Night Operation Lights, Top Loading Spout, Rear Landing Gear, Cold Weather Kit, Export Fifth Wheel Pin, Export Lifting Eyes, Dual Lower Feed Roll
