Disc Granulator (Pan Granulator)
This series disc granulator is a new type of tilting disc granulation equipment: it’s granulation rate can reach more than 95%. The main gear of granulator is using high frequency quenching, and its service life is doubled. The disc of the disc granulation machine has a circular arc structure, which is lined with high strength glass steel, and the bottom of the disc is strengthened by a number of radiated steel plates. It is durable and never deformed. The design of the thickened, heavier and stronger base does not need to be fixed with anchor bolts, and operates smoothly. The granulation disc of the disc granulator has three discharge ports, which is convenient for intermittent production operations, greatly reduces labor intensity and improves labor efficiency. The reducer and motor are driven by flexible belt, starting smoothly, slowing down the impact force and improving the service life of the equipment.
The main motor of disc fertilizer granulator drives the pulley and the belt to drive the pinion through the reducer, and the pinion is mutually engaged with the large gear fixed on the bottom of the disc, and works in opposite directions. The big gear are specially designed to fit on the spindle mounted on the rack adjustment disc to support the work of the entire granulator (used in conjunction with the sprayer). After entering the granulation tray, the material is continuously rotated and sprayed by the granulation plate to make the material stick together to form spherical pellets. We have designed an automatic cleaning device in the upper part of the pilling disc to prevent the material sticking to the wall, thus greatly improving the service life of the disc granulator. With the continuous rotation of motor and continuous entry of materials, mass production is can be achieved.
