Model Ultris X20 Plus - Dual-Sensor Camera for Drone Applications

SHARE

The ULTRIS X20 Plus increases the spatial resolution of the ULTRIS X20, giving incredibly detailed images. The X20 is extended with a second camera sensor: panchromatic – just one band, high resolution. We use this data to increase the spatial resolution of the spectral camera to 1880 x 1880 pixel, giving incredibly detailed images.

Most popular related searches
leaf vegetable
vegetation level

The X20 is extended with a second camera sensor: panchromatic – just one band, high resolution. We use this data to increase the spatial resolution of the spectral camera to 1880 x 1880 pixel, giving incredibly detailed images.

The extra data provided by the second camera on the ULTRIS X20 Plus allows us to use a technique called pansharpening or image fusion – a version of which we have developed inhouse – to enhance the images even further. This enables analysis at the leaf level of vegetation even from a UAV, helping to detect diseases and other issues that require action at an early stage.

Each ULTRIS X20 Plus comes with a high standard 95% white reference target, a distance target, and all accessories necessary to immediately start measurements.

The ULTRIS X20 Plus is compatible with any drone. For recording data the camera can work in time lapse mode or be triggered directly from the UAV. The image shows the camera onboard a DJI Matrice M300 RTK. It is mounted on a gimbal containing a Windows-based mini computer which runs the Cubert CUVIS software and records the data. The gimbal is connected via DJI-Skyport to the UAV, which triggers the camera automatically during the flight and provides the RTK GPS signal for each single data file.
