Egg Collect And Carrying Systems
ESCALATOR- ELEVATOR EGG COLLECTION SYSTEM: Elkators (feed conveyors with plastic rods); the eggs are picked from the cloth tapes, the thin crusts or spirals are separated and the eggs are directed to separate places to synchronize the egg transport onto the elevator carriers. Elevator conveyors are designed to transport eggs in a very gentle way, and the eggs from the escalators are gently moved onto the conveyor conveyor or table by turning them around two separate curved gratings at the bottom and the conveyor conveyor in front. Egg conveying conveyor level can be preset according to the request of the customer.
The standard speed of the egg transfer cloth band is 1.2 m / min. Egg transport belts and elevator-escalator driving units have separate gearbox motors. The automatic system is an optional frequency converter provided with a mechanical start-up switch for a belt speed of 0.6-2 m / min. and can be opened manually with a potentiometer, or can be operated automatically with an egg counting system.
The speed of the escalator-elevators is fixed. With this system, while the ovens carry cloth from the tape to the conveyors very gently at the shortest possible time, thanks to the structure of the system, the cluster tunnel ventilation system is not damaged.
ELEVATOR (LIFE) EGG COLLECTION SYSTEM
In the lift egg collection system, the eggs conveying conveyor in the poultry stacks each layer of egg; from top to bottom, in order. The elevator system is moved with the brake reducer to prevent the conveyor from falling down.
The standard speed of the egg transfer cloth band is 4.5 mt / min. This speed can be slowed down and accelerated by a speed controller depending on demand.
The system is designed to minimize the number of damaged and dirty eggs in general and has been designed to work with minimum maintenance costs for many years. Each floor and row of steel steel scissors locking system has been designed to be a problem for many years and has been gained the satisfaction of the customers.
EGG TRANSPORT SYSTEMS
The flexible rod type egg conveyors allow the eggs to be transported very gently. Egg conveyor line is suitable for long and short distances. The conveyor side channels are very low, allowing the eggs from the elevator or lift system to be transferred gently onto the conveyor. Using a hinged connection, production can be run at different slopes up to 18 ° (32%) without interruption. The conveyor line is suitable for attaching a telescopic shaft. As a standard, the 50 m conveyor is moved by a gearmotor with a power of 0.37 kW. Conveyor constant speed 6mt / min. A speed controller can be connected as required.
