Chandler - Model AT-FTLH-EXW - Fertilizer and Lime Spreaders
The AT-FTLH EXW is part of the EXW Line of spreaders which has the Grower/applicator in mind. The AT-FTLH EXW has a 4-blade design with adjustability and accuracy giving the AT-FTLH EXW the ability of our new Widespread pattern that has the accuracy our customers have grown accustomed to and expect. The AT-FTLH EXW has the capacity to hold 10 Tons of Fertilizer and 12 Tons of lime and get down to 50# per acre to as much as 4 tons an acre of lime with ground speeds up to 12 MPH. The AT-FTLH EXW comes standard with an Adjustable Axle that will extend out to 120”. The AT-FTLH EXW is ISO capable which will save the End user Time and Money.
Most popular related searches
fertilizer and lime spreader
lime fertilizer
lime spreader
row crop tractor
fertilizer
lime fertilizer spreader
agriculture tire
row crop
fertilizer spreader
lime fertilization
- Hopper Width 102” (8’ 6”)
- Hopper Length 144” (12’)
- Hopper Height 56 1/2” (4’ 8 1/2”)
- Total Length of Spreader 260” (21’ 8”)
- Capacity 280 Cu. Ft (struck level) (9 Ton Fertilizer Capacity based on 65# material)
- Hopper Loading Height 108” (9’) (Mounted on 380/90R - 46 Tires)
- Chain Type 24” 304L Stainless Steel Chain
- Tire/Wheel 380/90R - 46 Tires
- Hitch Pin – Clevis Type
- Jack 12000# Jack
- Axle Adjustable Axle from 72” – 120” Track
- Hopper Options
- Mild Steel, 409 Stainless, 304 Stainless
- Ladder
- Extension Brackets and 10” Boards
- Spinner Options
- 304 Stainless Steel Spinners Dishes and Blades
- Stainless Steel Spinner Assembly
- Raven Spinner Speed Control (Requires Capable Control System)
- Conveyor
- Bar Type Chain – D88K with Bars Every Other Link
- Belt – Over Bar Type Chain (Manual Chain Oiler is Standard)
- Raven Supplied Valves
- Self-Contained Hydraulic Drive – Tandem Pump with 1000 RPM Constant Velocity Shaft (1 3/8” – 21 Spline)
- Frame Options
- Bull Pull CAT-4 Hitch
- Pintle Hitch
- Tarp Options
- Agri-Cover SRT-2 Roll Tarp System
- Electronics
- Rate Control
- Variable Rate Capability
- ISO Ready
- Scale System
- Mild Steel Hoper with 304 Stainless Steel Floor, Gate and Gate Slides
- 45 Degree Sloped Sides
- 24”-1”X1” 304 Stainless Steel Mesh Type Chain
- Hydraulic Drive – Plug to Tractor (requires 35 – 40 GPM)
- M-2500 – 2” Double Bearing Spinner Motors
- Tandem Motor Gear Case on Conveyor
- Tail Light Kit (Ag Style plug)
- Safety Chains
- 12’ Long x 102” Wide Hopper
- 280 Cubic Ft. Capacity
- 70’ Swath – Fertilizer and 50’ Swath – Lime
- Specially Designed Dished Type Spinner Disc with 4 Heat Treated Blades
- Inverted “V” (Adjustable and Removable)
- 304L Stainless Steel Mesh Chain
- Adjustable Axle (72” – 120” Track) with Row Crop Tractor Tires (380/90R 46) and G-900 – 10 Bolt Hubs
- 33” Ground Clearance
