SiloMasters - Model CERES Series - Flat Bottom Silos
SILOMASTER S.L.U. designs and produces the CERES Series Flat Bottom Silos, featuring a corrugation with 106 mm length and 13 mm depth. Offering a useful sheet height of 1166 mm and a useful width of 3140 mm, these silos have wall sheet thickness ranging from 0.8 mm to 3.5 mm. For applications requiring greater thickness, a combination of different thicknesses can be employed to meet structural resistance requirements. Galvanized exterior reinforcements on the silo wall help transfer the vertical load of the grain and the silo itself to the foundation. The company emphasizes custom project solutions, allowing for adaptation in diameter and height according to specific needs. Structural design adheres to EUROCODE and ANSI standards, ensuring robust structural assessments.
Our flat bottom silos with corrugated walls are designed to store different types of cereals and/or granulated bulk materials . With diameters from 3 m to 32 m and capacities from 30 m3 to 26,000 m3, our CERES series silos are designed to ensure safe storage for a wide variety of free-flowing products, even over very long periods. The corrugated steel sheets of the silo body are manufactured from pre-galvanised steel coils, which are supplied by approved steel suppliers according to our quality system. The steel used for its manufacture is of quality S450 + Z600 according to EN‐10346 .
The corrugated sheet is made up of 106 mm long and 13 mm deep corrugations, providing a useful sheet height of 1166 mm and a useful length of 3140 mm. The thickness of the wall sheets ranges from 0.8 mm to 3.5 mm. If a greater thickness is required due to calculation requirements, combinations of different thicknesses will be used until the necessary strength is achieved.
Galvanized reinforcements on the exterior of the silo wall transmit the vertical load of the grain and the silo itself to the foundation.
