Co-Drip - Model QDCO-DL - Flat Dripper Irrigation Pipe Production Line Machine

PLC control whole line, and has Remote guidance and service support system. Extruder would feeding 100% recycling material. 1 layer, 2 layer, or 3 layer irrigation pipe Co-extrusion technology. Online visual Inspection system for Perforation and Dripper spacing check with or without Auto correction facility. Two station Auto Coiler with Synchronised Traversing, Auto pipe cut and auto bobbin change over. Thickness Range: 0.12 mm to 0.9 mm. Perforation unit with perforation capacity 800-3000 Drippers /Min.
Option: 4 Station Gravimetric Blender with Extrusion Process Control. Option: Bimetallic Screw and Barrel ensure stable.
10 cm to 1000 cm spacing setting for different configuration pipe. Uniform spacing/Group spacing/Plain Pipe/Sample features included in PLC.
