PALMS - Model 5.85 -Forest Crane

Max outreach, m : 8,5. Brutto lifting torque 190 bar, kNm : 56. Brutto lifting torque 215 Bar, kNm : 63. Lifting capacity at 4m, 190 Bar, w/o grapple and rotator, kg : 1050. Lifting capacity at full reach, 190 Bar, w/o grapple and rotator, kg : 450. Lifting capacity at 4m, 215 Bar, w/o grapple and rotator, kg : 1220. Lifting capacity at full reach, 215 Bar, w/o grapple and rotator, kg : 520. Telescopic boom stroke length, m : 3,3. Slewing cylinder amount in slewing housing, pcs : 4. 2/8 Pre-hydraulic,+2x el.propo, Parker P70, 190bar : . Slewing torque, kNm : 17. 2/8 Pre-hydraulic +2x el.propo, LS-comp, 190bar : . Working pressure, bar : 215. Rotator maximum load, kN : 55. Crane weight without support leg and valve block, kg : 900. Pillar slewing angle, degrees : 380. Recommended oil flow, L/min : 50-90. Propo el, display+ministick, Parker L90, LS-comp. : 7500.00.
