Munckhof Fruit Tech Innovators

MunckhofFully Automatic Tree Shakers

SHARE

For harvesting fruit for the food industry and harvesting olives and nuts, the tree shaker is a labor-saving and effective harvesting machine. The Fully Automatic tree shaker grabs the trunk, covers it and shakes just as hard as necessary. The collecting cloth is automatically unfolded and closed around the tree. This is precisely why time is being saved.

Most popular related searches
  • Drive 4x4, hydraulic
  • Tyres 26x12.00-12
  • Engine 4 cyl. Kubota diesel/41HP
  • Length 8,40 m
  • Width 1,85 m
  • Height 2,15 m
  • Wheel base 4,20 m
  • Track 1,55 m
  • Weight 3095 KG
  • Steering 4-Wheel, hydraulic
  • Road clearance 0,21 m
  • Electric circuit 24 V
  • Reach shake arm 2,05 - 2,85 m
  • Dimensions canvas 6,34 x 2,55 m
  • Width conveyor belt 0,50 m
  • Free height stem 0,35 m
  • Max. diameter stem 0,30 m
  • Driving speed Stepless 5-15km/hour
  • Shake capacity 80-180 trees per hour
  • Staff 1 on shaker, 1 on counter car, 1 for handling empty/full bins
