Cimarron Showstar - Model SS8G - Gooseneck Livestock Trailer

STANDARD FEATURES

• 6’ – 10” Wide and 6’ - 0” Tall
• Removable Pen system, all aluminum, top of gates is 42” above floor
• Fully insulated roof, ½” think fiberglass structural panel with R3 thermal value.  The ultimate in temperature control.
• Roof Vents- 1 per 2 pens
• Front tack room with dome light, floor mat, hooks, & Plexiglas storage
• 3 Air openings on each side with removable plexiglass
• 18” tall Treadbrite gravel guard on front of bumper pull models
• Exterior walls engineered with extruded Aluminum tongue & groove side slats welded to rectangular tube uprights for maximum strength.

UNDERCARRIAGE

• Dexter Rubber Torsion axles with E-Z Lube hubs & self-adjusting electric brakes

COUPLER & JACKS

• 2 5/16” coupler & safety chains with hooks
• Spring loaded Drop-Leg Gooseneck jack, removable handle
• Top-Wind Bumper Pull jack with removable foot

WHEELS

• Radial tires on Aluminum spoke wheels
• Balanced & Nitrogen filled

WINDOWS

• 15” x 22” in Rear Doors
• 15” x 22” in Tack Room Door

DOORS

• Ramp over sealed Rear Doors w/ windows & Cam lock latches
• All latches keyed alike

HARDWARE

• 60/40 Pens standard, 50/50 or Ajustable Pens (Optional)

LIGHTING

• (2) 16” Awning Lights on the rear of the trailer
• LED Opti-Brite lights in the stall area
