Fan-Way - Model FY-FJ -Groove Type Compost Turner

1. The operation span of the Lane Turner is four to twelve meters and the fermentation period is about fifteen days. The length of the fermentation groove depends on the particular condition. The feeding and discharging of the material can be done at the same time. The compost turner can raise the augers and fast move to another working area after it finishes one section.
2. The innovation point of this compost making machine is to take full advantage of underground space to design deep tank and adopt long-distance composting technology. It makes large-scale innocent treatment of organic waste in limited space come true.
3. It has a compact structure and advanced technology. It adopts unique groove type continuous aerobic fermentation technology to decompose, anhydrate, sterilize and deodorize organic waste and achieve innocent treatment, resourceful treatment and minimization treatment. Besides, it has advantages such as stable product quality and low energy consumption and so on.
4. The groove type compost turning processing of the fermentative material is under intelligentialized auto-control. With the action of lengthways and sideways walking gear, fermentative material is turned over in the tank so that the aerobic fermentation can be completed well.
5. groove type hydraulic compost turner5.The electronic control system of the organic fertilizer compost windrow turner is advanced and reliable. It is easy to operate and equipped with remote control. After the main engine runs, turn spin button to “automatic”, the compost turner will start to work. When it sideways moves to one side, the compost turner will stop moving after touching the limit switch. The compost turner lengthways moves three to five seconds, then sideways moves to the opposite side. This cyclic process achieves the desired effect for compost turning and oxygenating.

As for the groove type hydraulic compost windrow turner, except for all features mentioned above, it is manufactured with an additional hydraulic pressure device, with advantages as follows:

• Hydraulic control system is adopted when manufacturing, by which the organic materials are turned up and down, and mixed with microbial agents more evenly. To some extent, it ensures that every detailed parts in the organic materials are fully contacted with air, hastening the decomposition speed.
• Electricity saving, and long service life. In some areas, the power shortage situation still hasn’t been eased, so customers are prone to choose a more electricity-saving compost turner. Then our groove type hydraulic organic fertilizer compost turner machine will be your best choice.

1. This organic fertilizer compost turner adopts an integrated structure which consists of reduction drive, material throwing device, walking wheels, materials compostingwalking vehicle. The stand-by work unit is placed on the walking vehicle. There are walking tracks on the fermentation tank. When the machines start to work, the walking vehicle carries the work unit to the fermentation tank to deal with the material. The groove type compost turner is equipped with manual or intelligent time control system to control the work unit.
2. Under the operation of vertically and horizontally walking gear, the high-speed disc harrows throw the fermentative materials up, then fall to the ground and the material shift. The fermented material is carried away and the space is cleared for the material requiring fermentation. Thus a complete fermentation process is formed.
3. The electromotor of the organic fertilizer compost turner machine transfers the power to cycloidal pin wheel speed reducer then to the roller. The stirring blades in the roller are spiral so that the materials in the fermentation tank can be enough stirred and shifted which makes the materials fully catch air and the ferment effect will be better.
