Addfield - Model A500 - High Capacity Animal Disposal Machine

• Variant #1 is a high capacity 500kg/hr animal disposal machine (A500)
• Variant #2 is a high capacity 500kg/hr animal and pathological disposal machine. (A500)

The animal variant (A500) is a front loading machine, that is equipped with a with a chamber size of 13.61m3, and an incineration thermal capacity of 1,112,500Kcal/hr.

Suitable for animal-by-product disposal, the A500 (animal) disposal machine is ideal for hatcheries, broiler facilities, abattoirs and slaughterhouses.

The A500 (animal-pathological variant) incinerator boasts additional features including:

• A bin tipper for any waste contained in wheelie bin.
• An increase refractory rating to deal with higher compliance temperate.
• A secondary after-chamber operating at 1100C.

Both variations are compatible with an optional ram feeding system and off-gas options.

One of the most effective, high capacity incineration machines, sold worldwide.

Want to find out more about our animal pathological machines?

Read the case study about the:

• UK Animal Health Veterinary Laboratory using the Addfields animal-pathological machines.
• High Tech Dairy Farms and their 500kg/hr-1000kg/hr Animal Pathological Plant.

Parameters: Value

• Volume: 13.61 m³
• Loading Chambers Size: 4.8m x 1.9m x 1.9m
• Loading Method: Front
• Load Capacity: 500 kg
• Refactory Thickness: 191mm - 226mm
• Gas Retention Time: 2 Seconds
• Fuel Options: Diesel, LPG, Natural Gas, Bio Fuel, Dual Fuel
• Afterburn Complies with EU Legislation: Yes
• CE Certified: Yes

Parameters: Value

• Volume: 13.61 m3 4.8m x 1.9m x 1.9m Front
• Loading Chambers Size:
• Loading Method:
• Load Capacity: 500 kg 191mm -226mm
• Refactory Thickness:
• Gas Retention Time: 2 Seconds
• Fuel Options: Diesel, LPG, Natural Gas, Bio Fuel, Dual Fuel
• Afterburn Complies with EU Legislation: Yes
• CE Certified: Yes
