Aquamonix - Hybrid Multi-Purpose Controller
Aquamonix’s Hybrid Irrigation Controller is a versatile irrigation controller and helps in irrigation automation that allows you for multiple control methods and can be stand alone or networked to the Aquamonix Micro Central Control System. The Aquamonix irrigation Controller operates with a range of power inputs, and is suitable for mains AC powered, AC or DC powered generators or solar DC powered sites.
Hybrid irrigation controller also allows for multiple output methods, being able to support AC or DC Multipath, AC Two Wire and DC Radio Link to field valves; combinations of these methods can be supported on one controller.
The Hybrid Irrigation Controller can be supplied in several easy to specify formats, and can also be supplied in pre-built, pre-tested Project Packs. It can also be helpful in water controllers and manage water flow controlling for the flow meters.
The controller is suitable for almost any application to automate irrigation system and is typically used for,
- Municipal Park Irrigation
- Sportsfield Irrigation
- Golf Course Irrigation
- Landscape Irrigation
- Vineyard Irrigation
- Greenhouse Irrigation
- Agricultural Irrigation
- Dust Suppression Systems
- Mains or Solar Powered
- 15 Irrigation Programs
- 6 Smart Programs
- 4 x Communications Ports
- 96 Max Outputs
- 40 Max Inputs
- Two wire and multi wire compatible
- 4-20mA Analogue Inputs
- Pulse Counter Inputs
- Digital Inputs
- Multiple Mounting Options
- Modular and Expandable
- Central Control Compatible
- Customizable
- Minimal Maintenance
- Easy to Use
- Long term reliability
- Power Supply: 12-24VDC or 24VAC
- Output Power: 12-24VDC or 24VAC
- Digital Outputs: Max 3A current supply
- Analogue Inputs: 4-20mA, loop powered of device powered
- Digital Inputs: 4V up to 12mA designed for voltage free digital inputs
- Pulse Inputs: support a minimum pulse width of 10ms and a maximum of 50 pulses per second Pulse
- Frequency Inputs: supports a sine wave frequency range of 1 to 450Hz
- Serial Ports: 232/485 selectable 15kV ESD Protected
- Operating Temperature: -10-70°C
- Compliance: RoHS Compliant
