Jeffrey Rader - Model WB Series -Wood/Bark Hogs
The WB Wood/Bark Hog is designed for more profitable operation, increased productivity, longer life, and easier maintenance. Alloy-steel liners drilled and tapped for easy replacement. Adjustable breaker plate can be moved to compensate for plate wear. Assists with specific product sizing. Drilled rotor shaft allows for hydraulic removal of bearings to keep downtime to a minimum. Double-sealed roller bearings ensure long life and keep contaminants from entering bearings. Bearing fill block allows service and removal of bearing housing without removing rotor. Rugged disc-type rotor: all wood/bark hogs include lugs on disc to assist with processing oversized pieces. New hammer metallurgy and design choices, including the Jeffrey Rader exclusive Duratip with replaceable tips for easy maintenance.
Easily accessible metal traps are standard in every wood hog. Traps help to minimize damage when metal enters hog. Slant-Flow screen grates provide maximum open area and assist flow of material through hog for optimum capacity. Large clean-out doors allow easy access to bottom of hog for scheduled inspections. Extended lower housing provides a full 180° of screen grate area. Rigid frames constructed of heavy plate and reinforced to provide long service life.
