Terra.Roller ExpertLevelling Bar

SHARE

Pave The Way. The hydraulically adjustable levelling bar has been specially adapted to the TERRA.ROLLER expert professional roller. The tailor-made combination ensures better reconsolidation and crumbling of the soil, thus ensuring optimum seedbed preparation. The optionally available automatic adjustment valves ensure the exact parallel positioning of the three segments each time the bar is folded in. The levelling bar can be mounted as a seedbed preparation tool on new rollers as well as on existing machines.

Most popular related searches
  • The levelling bar’s working depth and angle are individually adjustable
  • Coupled hydraulic cylinders guarantee an even working depth
  • The aligned spring tines prevent undesirable dam formation
  • Working width in m: 6,3 / 7,7 / 8,3 / 9,3
  • Weight in kg: 645 / 750 / 850 / 910
  • Tine dimensions: 10 x 80 mm
  • Wear plate width: 175 mm
  • Tine spacing: 250 mm
  • Connectors: 31 x DW
  • Accessories: Automatic adjustment valves

The working depth can be conveniently adjusted hydraulically.

The levelling bar levels the ground evenly.
