Model Farmtrac 22 -Compact Series
Farmtrac Compact 22 is a tractor with compact looks that offers power-packed performance. Powered by environment-friendly 3-cylinder 22 HP engine from Mitsubishi with the latest emission compliant, it is high on power and efficiency. The tractor has been designed with MITA-make hydraulic lift that allows a lifting capacity of up to 75 kg, that further enhances its productivity. Adding to its utility is its agility. The tractor has a small wheelbase and hydrostatic steering with excellent turning radius, which makes it suitable for use in vineyards and orchard. Its 9F+3R constant mesh transmission further provides the operator with much comfort during operation. Get Farmtrac Compact 22 and give yourself a hassle-free farming experience.
PARAMETERS: FT 20
Platform: ROPS
Emission Norms: Stage V
ENGINE
Power at Rated ERPM, HP (KW): 21.3HP@3000
Type - NA/ TC/TCI/CRDI: NA
Swept Volume (cc): 952
No of Cylinders: 3
Max. Torque, Nm (+/- 100-200 rpm): 50 NM@1900
PTO
PTO speed- Std.: 540/540E
PTO RPM @ Engine RPM: PTO 1: 540 @ 2504 ERPM PTO 2: 540E @ 2035 ERPM
TRANSMISSION
Type: Constant mesh
No. of Gears: 9F+3R
Rear Axle Reduction Type: Bull Gear reduction
Differential Lock: Yes
CLUTCH
Type: Single
BRAKES
Type: OIB
Hand Brake: Yes
3-POINT LINKAGES
3 point linkage (Geometry) category I / II: Cat 1N
Swinging Drawbar: Yes
HYDRAULICS
Functions: Position Control
Type & Lift Capacity (Kg): 750 Kg At hitch point
Auxiliary Valve: 1 DA
STEERING
Steering: Power Steering
FRONT AXLE
Front Axle: 4WD
TYRE
Front Tyre: 5×12
Rear Tyre: 8×18
VEHICLE
Air Cleaner type: Dry Air Cleaner
CAPACITIES (+/-5%)
Fuel Tank capacity, ltr.: 24
DIMENSIONS (+/-5%)
Length, mm: 2674
Width, mm: 1041
Height with ROPS, mm: 1965mm 2162 wirh Beacon
SAFETY FEATURES
OPERATOR PRESENCE SWITCH BATTERY CUT-OFF SWITCH BEACON LAMP NEUTRAL, CLUTCH & PTO SAFETY SWITCH
OTHER OPTIONAL FEATURES
2wd variant
Turf Tires
Industrial Tires
Front Loader
Joystick with 3rd function
