Model M410 - Hillside Combines


Continuous feed and uniform cutting even in difficult conditions.Large -diameter auger: thanks to a large-diameter auger with larger flighting, it allows for increased and improved feeding capacity.Open-profile frame: provides better visibility (facilitating crop flow control) and improves the handling of long-stemmed crops. The frame is designed to simplify hitching and unhitching the cutting header.

Header /machine coupling: the cutting headers are hitched by a centralized multiple coupling system for all electric and hydraulic controls. This makes hitching a quick, simple and precise operation.

Hydrostatically driven pickup reel: it is equipped with newly designed tines, anti-clogging blades (Schumacher system) and simplified drives. This combination of components improves balance and the efficiency of the pickup reel on laid crops and is practically zero maintenance.

Power Flow Cutting Header

The cutting header ensures a consistent head first feed of material of all crop types through the innovation of the powered belt system, for greater threshing ability.

Powered Belt System: the one meter length between the knife and auger, allow for improved performance and visibility. Tall and short crops can be cut and easily transported directly underneath the auger by the revolving power belt at a constant speed, increasing the productivity of the machine.

Reel: the hydraulic reel can be regulated to 3 different positions, high enough to reach taller crops and low enough to allow the reel tines to reach below the knife making it reliable in crop pick-up even in laid conditions. The reel speed adjusts automatically, the Operator can set the speed ratio from inside the cab, so the reel will automatically compensate to the forward speed of the combine for perfect crop flow into the header.

Knife: the exclusive Schumacher system guarantees a higher cutting strength, precision, and a 1,220 rpm working speed even on green or damp crops. The strong and reliable gear box vibrates less therefore, less wear on the cutting header. The blades of the knife are double supported, constantly sharp and self cleaning, therefore more difficult crops like oil seed rape, peas and rye are tackled with ease.

Oil Seed Rape: exclusive design of the Power Belt allows efficient collection of rapeseed without having to employ  an additional kit, but simply installing optional side knives, where the crop dividers attach. A special rape auger (optional) can be easily installed above the main auger and can boost productivity when harvesting long stemmed oil seed rape.

Crop Dividers: the  standard Torpedo foldable crop dividers were engineered for all types of crops and conditions. The assembly is quick and simple, not requiring the use of any tools. The unique design make it possible to fold the dividers making it easier to transport on the road.
